Panasonic MS-DP1-4 Instruction Manual

Thank you very much for purchasing
Panasonic products. Read this Instruction
Manual carefully and thoroughly for the
correct and optimum use of this product.
Kindly keep this manual in a convenient
place for quick reference.
1
DIMENSIONS OF PANEL
CUT-OUTS
- Thickness of panel wall: 1 mm to 3.2 mm
- Size of cut-out: 36
- Make clearance between cut-outs equal
to or more than the value shown below.
80
2
MOUNTING
1. Mount the
spacer on the
rear side of
the sensor.
The tightning
torque should
be 0.5 N·m or
less.
2. Insert the
sensor from
the rear side
of the main
bracket.
MJE-MSDP14 No.0102-69V
+0.5 +0.5
mm×36 mm
0 0
56
+0.5
36
0
36 +0.5
0
(Unit : mm)
3. Attach the bracket to the rear side of the
main bracket by fitting its part
main bracket.
4. Fit part of the panel mounting bracket
on the side hook of the main bracket.
5. Push the bracket and set it to the main
bracket by fitting its part
hook.
6. Insert the main
bracket to the
front of the
panel hole to
be fixed.
7. The front
protection
cover DPX-04
(optional) is
attachable.
* For dismantling, using
a flathead screwdriver,
etc., to remove the
bracket from each
three hook.
Panasonic Industry Co., Ltd.
1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8506, Japan
https://industry.panasonic.com/
Please visit our website for inquiries and about our sales network.
Panasonic Industry Co., Ltd. 2024
April, 2024
on the
on the upper
PRINTED IN JAPAN
