VACUUM CLEANER
SERVICE MANUAL
MODEL : V-CC162HT, V-CC172HT
CAUTION
BEFORE SERVICING THE UNIT, READ THE
"SAFETY PRECAUTIONS" IN THIS MANUAL.
P/NO : 3828Fi5897D
V-CC180HTR, VC5872R
V-CC102HT
Website http://biz.lgservice.com
October, 2007
Printed in Korea

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-CC162HT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG V-CC162HT

Summary of Contents for LG V-CC162HT

  • Page 1 Website http://biz.lgservice.com VACUUM CLEANER SERVICE MANUAL MODEL : V-CC162HT, V-CC172HT V-CC180HTR, VC5872R V-CC102HT CAUTION BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS" IN THIS MANUAL. October, 2007 Printed in Korea P/NO : 3828Fi5897D...

  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS..........................3 CAUTIONS ..............................3 DESCRIPTION..............................4 SPECIFICATIONS ............................4 DISASSEMBLY ............................5~6 TROUBLE SHOOTING GUIDE........................7~9 SCHEMATIC DIAGRAM........................10~11 CIRCUIT DIAGRAM ..........................10~11 EXPLODED VIEW ..........................12~15 REPLACEMENT PARTS LIST......................16~33...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS BEFORE OPERATING THIS VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND OBSERVE EACH POINT CAREFULLY. 1. Motor filter(Air Cleaner) 3. Avoid suction such materials as : 1) This filter is reusable. 1) Liquid or wet dust : 2) Never use the vacuum cleaner without filter. Clogs the ventilation holes, reduces the suction It may damage the motor.

  • Page 4: Description

    DESCRIPTION Hose Assembly,Flexible Cord Reel Button Telesscopic Pipe Assembly Dust Tank Power Cord Body Cover ATTACHMENTS NOZZLE ASSEMBLY, BRUSH ASSEMBLY, CREVICE TOOL DUST UPHOLSTERY SPECIFICATIONS • MODEL : REFER TO THE COVER PAGE • NET DIMENSION : 319 398 273 (W D H)mm •...

  • Page 5: Disassembly

    DISASSEMBLY NOTE : Before attempting to service or adjust any part of the vacuum cleaner, disconnect the electrical power supply cord from the wall outlet. • Almost all of the parts of this vacuum cleaner can be 3) Disassemble the body cover, raising the body cover. disassembled with a screw driver and each connecting component easily fits each other.
  • Page 6 3. Cord Reel Assembly Replacement 5. Disassembly of Body Base Assembly 1) Lift the cord reel assembly from body base. 1) Remove the two screws fastening, the motor housing cover. 4. Disassembly of Top Cover 1) Remove the three screws fastening the body cover and top cover.

  • Page 7: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE 1. SWITCH ON BUT MOTOR DOSE NOT TURN. CHECKING CAUSE SOLUTION CHECK THE POWER The fuse is melt down Exchange the fuse SOURCE in the coverknife switch Poor plug insertion Insert again Power cord cut Repair or exchange Interior lead wire cut Exchange the lead wire Motor(stator armature) coil cut...
  • Page 8 3. SWITCH OFF BUT MOTOR TURNS Poor connection Repair. 4. WEAK SUCTION POWER Motor armature cut Exchange the motor Foreign matters attached to Low rotation speed Remove the foreign matters the impeller Inquire to the power utility Low voltage company Hose and extension wands Remove the foreign matters are clogged with foreign matters...
  • Page 9 5. VIBRATION NOISES Loose parts Secure firmly Unbalanced motor assembly Exchange or repair the motor Foreign matters are attached Remove the foreign matters to the impeller Armature is cut or foreign Exchange the motor matters attached Remove foreign matters 6. RADIO, TV RECEPTION DISTURBANCE Poor cord, lead wire Exchange cord, lead wire Poor electric connector or...

  • Page 10: Schematic Diagram

    SCHEMATIC DIAGRAM CIRCUIT DIAGRAM -10-...
  • Page 11 SCHEMATIC DIAGRAM CIRCUIT DIAGRAM -11-...

  • Page 12: Exploded View

    #EV# EXPLODED VIEW BASE ASSEMBLY, BODY V-CC162HT(V-CC162HT.ABTRDTH) V-CC162HT(V-CC162HT.ABTQERO) V-CC172HT(V-CC172HT.AABPNAG) V-CC172HT(V-CC172HT.ARNPNAG) V-CC162HT(V-CC162HT.ATVPECL) V-CC172HT(V-CC172HT.AABPLMD) V-CC180HTR(V-CC182HT.AXRQGSF) VC5872R(V-CC102HT.AXRQGSF) V-CC102HT(V-CC102HT.AXBQGSF) AHDBR1 MCQBM1 EAUBA1 MCQBA1 ACVBA1 MDSBA1 EBFBP1 EADBS1 MCKBZ1 MDSBA2 MDSBA3 MDJBM1 MCKBE1 MEKBM1 ADQBE1 MEABE1 MDJBE1 EBRBM1 MAMBB1 AJWBA1 AHJBA1 MCKBD1 -12-...
  • Page 13 #EV# COVER ASSEMBLY MBGCS1 MKCCL1 MCKCT1 MEBCC1 EBRCD1 EADCS1 MCKCH1 MCKCB1 MFCCC1 MHYCC1 MCKCS1 MDSCA1 MGECC1 MCKCZ1 -13-...
  • Page 14 #EV# TANK ASSEMBLY, DUST AJLTD1 ABNTA1 ADQTC1 ADQTA1 ADVTF1 MFGTA1 MHYTC1 MGJTCR MGJTCL MJHTB1 MJMTD1 MCKTH1 MEBTC1 -14-...
  • Page 15 #EV# ACCESSORIES AGBN41 AEMAF1 ABCAD1 MFVAC1 AGRPT1 AGBNU1 -15-...

  • Page 16: Replacement Parts List

    REPLACEMENT PARTS LIST V-CC162HT(V-CC162HT.ABTRDTH) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2855A Manual,Owners 3828FI5897D Manual,Service 3890FG1230A ABCAD1 5203FI2072S Brush Assembly,Dust ABNTA1 5007FI2001D Cap Assembly ACVBA1 4901FI2001L Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean...
  • Page 17 LOC. NO. PART NO. DESCRIPTION REMARK MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522A Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCCC1 4510FI3623A Lever,Cord Reel MFGTA1 4026FI3698A Locker MFVAC1 5058FI3592D Nozzle,Crevice MGECC1 5200FI1232A Pipe,Connector MGJTCL 3300FI2287A Plate,Cover MGJTCR 3300FI2286A Plate,Cover MHYCC1 4970FI4511K Spring,Coil...
  • Page 18 REPLACEMENT PARTS LIST V-CC162HT(V-CC162HT.ABTQERO) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2855L Manual,Owners 3828FI5897D Manual,Service 3890FG1230A ABCAD1 5203FI2072S Brush Assembly,Dust ABNTA1 5007FI2001D Cap Assembly ACVBA1 4901FI2001B Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean...
  • Page 19 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA2 3920FI3872A Gasket MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522A Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCCC1 4510FI3623A Lever,Cord Reel MFGTA1 4026FI3698A Locker MFVAC1 5058FI3592D Nozzle,Crevice MGECC1 5200FI1232A Pipe,Connector MGJTCL 3300FI2287A Plate,Cover...
  • Page 20 REPLACEMENT PARTS LIST V-CC172HT(V-CC172HT.AABPNAG) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2855J Manual,Owners 3828FI5897D Manual,Service 3890FG1230A ABCAD1 5203FI2072S Brush Assembly,Dust ABNTA1 5007FI2001M Cap Assembly ACVBA1 4901FI2001B Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean ADVTF1 3211FI3707A Frame Assembly,Filter...
  • Page 21 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA2 3920FI3872A Gasket MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522C Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCCC1 4510FI3623A Lever,Cord Reel MFGTA1 4026FI3698A Locker MFVAC1 5058FI3592D Nozzle,Crevice MGECC1 5200FI1232A Pipe,Connector MGJTCL 3300FI2287A Plate,Cover...
  • Page 22 REPLACEMENT PARTS LIST V-CC172HT(V-CC172HT.ARNPNAG) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2855J Manual,Owners 3828FI5897D Manual,Service 3890FG1230A ABCAD1 5203FI2072S Brush Assembly,Dust ABNTA1 5007FI2001K Cap Assembly ACVBA1 4901FI2001B Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean ADVTF1 3211FI3707A Frame Assembly,Filter...
  • Page 23 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA2 3920FI3872A Gasket MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522B Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCCC1 4510FI3623B Lever,Cord Reel MFGTA1 4026FI3698B Locker MFVAC1 5058FI3592D Nozzle,Crevice MGECC1 5200FI1232A Pipe,Connector MGJTCL 3300FI2287A Plate,Cover...
  • Page 24 REPLACEMENT PARTS LIST V-CC162HT(V-CC162HT.ATVPECL) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2855X Manual,Owners 3828FI5897D Manual,Service 3890FG1230A ABCAD1 5203FI2072N Brush Assembly,Dust ABNTA1 5007FI2001E Cap Assembly ACVBA1 4901FI2001B Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean...
  • Page 25 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA2 3920FI3872A Gasket MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522D Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCCC1 4510FI3623A Lever,Cord Reel MFGTA1 4026FI3698A Locker MFVAC1 5058FI3592C Nozzle,Crevice MGECC1 5200FI1232B Pipe,Connector MGJTCL 3300FI2287A Plate,Cover...
  • Page 26 REPLACEMENT PARTS LIST V-CC172HT(V-CC172HT.AABPLMD) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2855R Manual,Owners 3828FI5897D Manual,Service 3890FG1230A ABCAD1 5203FI2072S Brush Assembly,Dust ABNTA1 5007FI2001M Cap Assembly ACVBA1 4901FI2001B Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean ADVTF1 3211FI3707A Frame Assembly,Filter...
  • Page 27 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA2 3920FI3872A Gasket MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522C Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCCC1 4510FI3623A Lever,Cord Reel MFGTA1 4026FI3698A Locker MFVAC1 5058FI3592D Nozzle,Crevice MGECC1 5200FI1232A Pipe,Connector MGJTCL 3300FI2287A Plate,Cover...
  • Page 28 REPLACEMENT PARTS LIST V-CC180HTR(V-CC182HT.AXRQGSF) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2855D Manual,Owners 3828FI5897D Manual,Service 3890FG1230A ABCAD1 5203FI2072N Brush Assembly,Dust ABNTA1 5007FI2001G Cap Assembly ACVBA1 4901FI2001H Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean ADVTF1 3211FI3707A Frame Assembly,Filter...
  • Page 29 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA1 3920FI4653B Gasket MDSBA2 3920FI3872A Gasket MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522F Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCCC1 4510FI3623B Lever,Cord Reel MFGTA1 4026FI3698B Locker MFVAC1 5058FI3592C Nozzle,Crevice MGECC1 5200FI1232B Pipe,Connector...
  • Page 30 REPLACEMENT PARTS LIST VC5872R(V-CC102HT.AXRQGSF) LOC. NO. PART NO. DESCRIPTION REMARK 3828FI2872F Manual,Owners MAY38054901 ABCAD1 5203FI2072N Brush Assembly,Dust ABNBA1 5007FI2001G Cap Assembly ACVBA1 4901FI2001H Damper Assembly ADQAC1 5231FI2510B Filter Assembly,Clean ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADVTF1 3211FI3707A Frame Assembly,Filter AEMAF1 5215FI1353M...
  • Page 31 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA2 3920FI3872A Gasket MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522F Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCBC1 4510FI3586A Lever,Cord Reel MFCCC1 4510FI3623B Lever,Cord Reel MFGTA1 4026FI3698B Locker MFVAC1 5058FI3592C Nozzle,Crevice MGECC1 5200FI1232B...
  • Page 32 REPLACEMENT PARTS LIST V-CC102HT(V-CC102HT.AXBQGSF) LOC. NO. PART NO. DESCRIPTION REMARK ABCAD1 5203FI2072N Brush Assembly,Dust ABNTA1 5007FI2001Q Cap Assembly ACVBA1 4901FI2001H Damper Assembly ADQBE1 5231FI2484A Filter Assembly,Exhaust ADQTA1 5231FI2513A Filter Assembly,Air Cleaner ADQTC1 5231FI2510B Filter Assembly,Clean ADVTF1 3211FI3707A Frame Assembly,Filter AEMAF1 AEM30748006 Hose Assembly,Flexible AGBN41...
  • Page 33 LOC. NO. PART NO. DESCRIPTION REMARK MDSBA3 7526FI4727K Gasket MDSCA1 3920FI3788A Gasket MEABE1 4974FI1010A Guide,Exhaust MEBCC1 3650FI1522H Handle,Carrier MEBTC1 3650FI2426A Handle,Carrier MEKBM1 3660FI1246A Housing,Motor MFCBC1 4510FI3586A Lever,Cord Reel MFCCC1 4510FI3623A Lever,Cord Reel MFGTA1 4026FI3698A Locker MFL552 3828FI2872G Manual,Owners MFVAC1 5058FI3592C Nozzle,Crevice MGECC1 5200FI1232B...
