USER´S MANUAL
LDST40 - Stand for LDRB65 and LDRB65HS
SAFTY INFORMATION
1. Please read these instructions carefully before you start installation and assembly.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Be attentive when setting up the product and protect yourself from injury.
6. A level surface is required, otherwise there is a high risk that it could fall over.
7. This product is intended for indoor use only. Using it outdoors could lead to product failure and personal injury.
8. Do not modify this equipment.
9. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate
plastic and paper/cardboard.
10. Plastic bags must be kept out of reach of children.
11. If you have any questions refering to this instruction or any warnings, please contact your local distributor.
MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at: http://www.adamhall.com/media/shop/
downloads/documents/manufacturersdeclarations.pdf
To request warranty service for a product, please contact Adam Hall GmbH, Daimler Straße 9, 61267 Neu Ans-
pach / Email Info@adamhall.com / 49 (0) 6081 / 9419-0
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that this appliance may not
be treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled
waste disposal. Please dispose of this product separately from other waste and have it recycled to promote
sustainable economic activity.
FEATURES
Speaker stand for 16 mm pole mounts
12 kg load capacity
Set screw plus safety pin height adjustment from 120 – 200 cm
Made of black painted heavy duty steel
Ideal for LD Systems Roadboy LDRB65 and LDRB65HS
OPERATION
Place the tube into the desired height and then gently fix the clamp by locking knob
Insert the locking pin
Always insert the safety pin to secure the height adjustment!
Tighten the clamp again by hand - not too tight – then place the speaker on the secured tripod.
SPECIFICATIONS
Adam Hall GmbH · Daimlerstr. 9 · 61267 Neu-Anspach · Germany
Tel.: (+49) 60 81 / 94 19 0 · Fax: (+49) 60 81 / 94 19 1000 · eMail: mail@adamhall.com
B
, slightly loosen the clamp and lower the pipe until it rests on the locking pin - Caution:
Model number:
Product type
Tube material
Tube colour
Tube surface
Min. Height
Max. Height
Transport length
Joint material
Tube Ø
Max. load
Weight
A
A
.
LDST40
speaker stand
steel
black
painted
1200 mm
2000 mm
1100 mm
plastic
25/30 mm
12 kg
3.2 kg
B
