Wilcoxon P704B Manual

○ ○ ○ ○ ○ ○
FEATURES:
• Powers most 700 Series Accelerometers
• Battery powered (line adaptor optional)
• Portable and lightweight
• Battery condition light
• Uses readily available 9 VDC transistor
batteries
NOTES: 1 25 VDC when using NiCad batteries.
2 For extended operation the NC3 NiCad Battery Kit should be used (see accessories section).
ACCESSORIES SUPPLIED:
ACCESSORIES AVAILABLE:
Due to continued research and development, Wilcoxon Research reserves the right to amend this specification without notice.
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
21 Firstfield Road, Gaithersburg, MD 20878 • Tel 301-330-8811 • Fax 301-330-8873 •1-800-WILCOXON • Email sensors@wilcoxon.com • Web www.wilcoxon.com
All manuals and user guides at all-guides.com
SPECIFICATIONS
INPUT CHARACTERISTICS
Voltage to Transducer ....................................................
Current to Transducer, ±20% ........................................
OUTPUT CHARACTERISTICS
Output Impedance .........................................................
Recommended Load Impedance ...................................
Decoupling Cap .............................................................
TRANSFER CHARACTERISTICS
Frequency Response .....................................................
BATTERY TEST CIRCUIT
LED Lights .....................................................................
Battery Life .....................................................................
POWER REQUIREMENTS
Batteries
ENVIRONMENT
Temperature Range .......................................................
PHYSICAL CHARACTERISTICS
Size ...............................................................................
Weight ............................................................................
Connectors:
(3) 9V alkaline batteries
NC3 Ni-Cad Battery Kit; LA704B (110V) Line Adaptor; LA704B-220 (220V) Line Adaptor; BNC Series adaptors
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
2 ........................................................................
Signal Input ............................................................
Signal Output .........................................................
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Model P704B
General Purpose Power Unit
1
27 VDC
2.4 mA DC
same as transducer
>100 kΩ
22 µV, 35 VDC
same as transducer
>18 VDC
>120 hours
(3) 9V alkaline
0 to 55°C
3" W x 2.4" H x 4" D
0.84 lb.
BNC
BNC
○ ○ ○ ○ ○ ○ ○ ○ ○
98450 Rev.A 9/01
