Airversa SCENTA+ Purifier Manual

Overview

With the latest cold diffusion technology, our waterless essential oil aroma diffuser converts essential oil into nano vapor to approximately 1-3 microns without using heat or water. The diffusing process does not damage the molecular structure, therefore maintaining its therapeutic properties for easier absorption into the body. It is easier, more hygienic and safer. We make it compact enough for you to fit it into your car cup holders so that you may take it with you wherever you go.

As it is compatible with the majority of essential oils available, it gives you the freedom to choose from a wide range of fragrances that soothe you, relax you, or refresh you in a variety of situations. Using it with sanitizing essential oils can improve unpleasant odors and help purify the air around it.

What's in the Box

Touch Button and Info Display

• Press & Hold the power button to turn on the device.
  Tap power button to adjust mist level.


1. Nozzle
2. Mist Indicator
3. Power Button
   • Press & hold: turn on/off
   • Tap: set mist level (L/M/H)
4. Light Button
   • Press & hold: turn on/off
   • Tap: rotate through light effects (Fade/Gradient/Constant)
5. Timer indicator
6. Timer settings:
   • 1/2/3H & Continuous mode.
   • Tap: set a timer; in Continuous Mode the timer indicator remains off, and the device stays on until it runs out of battery.
   • When time is up, the diffuser will automatically turn off. Press & hold power button to turn it back on.

Mist Level Explained

Level L
15 seconds of diffusing, then a pause of 165s

Level M
30 seconds of diffusing, then a pause of 150s

Level H
90 seconds of diffusing, then a pause of 90s

• The green LED remains on when the device is diffusing the oil, and flashes when diffusing is paused.

Bottle Installation

• The capacity of the essential oil bottle is 100 ml.
• This device is compatible with 5/10 ml standard oil bottles.

Removal:
Screw the bottle clockwise to remove the bottle, and then fill in the essential oil.

Installation:
Screw the bottle counter-clock wise to fix the bottle.

Charging

Normal charging time: approx. 3 hours. If the charging current is below 1A, it will take longer to fully charge the device.

Fully charge this diffuser before using it the first time.

As charging cycles increase, battery life will decrease.

• You may charge from a 5V adapter, PC/MAC USB port, or USB interface within your vehicle. Please ensure the use of safety-certified charging accessories.


Specifications

Max. Oil Capacity: 100 ml

Battery Capacity: 1400 mAh

Size: 70 x 128 mm | 2.76 x 5.04 in

Net Weight: 400 g|14 oz

Input: DC-5 V/1 A

Rated Power: 1.5 W

FAQ

Q1: How to select the right essential oil?
Use 100% pure essential oils. Resin and thick oil are not recommended. Camphor tree, dried orange peel, eaglewood and mixed oils are prohibited.

Q2: When I change to a new oil, there is mixed smell coming from my previous oil. How do I clean the nozzle and the bottle?
Fill the empty bottle with 30ml of 99% ethyl/ethanol alcohol. Shake to fully rinse the inner surface of the bottle and then run the device 10-15 minutes. Empty the rest alcohol in the bottle at last.

Q3: I feel like it stops running sometimes, what has happened?
Please refer to section 5 for 'mist level explained'. The device is able to automatically optimize atomizing/pausing according to mist level, which intermittently operates.

Q4: How long does it take to fully charge the device?
Normally around 3 hours.

Q5: Can I mix my 100% essential oil with water?
No. This will cause failing to atomize (mist not visible).

Q6: Why is the green light above the mist level flashing?
The mist output is pausing as it is intermittent.

CUSTOMER SUPPORT

support@airversa.com
www.airversa.com

If you have any questions or concerns about your new product, please feel free to contact our Customer Service Team.

Warning

Improper placement of the diffuser when an essential oil bottle is installed might cause oil leakage (eg. when the unit is tilted at an angle larger than 45°).

• DO NOT invert or tilt the device once the oil bottle is installed.
• DO NOT use it with camphor tree, dried orange peel, eaglewood and mixed oils.
• DO NOT mix your 100% essential oil with WATER when the device is in use. This will cause failing to atomize (mist not visible).
• DO NOT attempt to disassemble the device.
• If the mist output reduces noticeably, please clean the diffuser according to our instructions.
• For more quiet use, ensure the device is 6 feet away.
• Keep the device away from children and pets.
• The thicker the oil, the less diffusing capability.
• lf you do not plan to use this device for an extended period of time, please fully charge it at least once in every 3 months.
• Working Temperature: 4°–104°F / 0 – 40°C
• Suggested room size: 300-500 sq. ft.
