Clevertronics Trade Series Installation And Maintenance Instruction

Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
• For the first test, the emergency lamp must remain illuminated for at least 2 hours after
disconnection from the mains supply.
Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
•
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails
to remain illuminated for the requisite time, remedial action must be taken to repair the situation
and once completed, the unit must pass a subsequent test. For more specific information, please
refer to the current edition of the AS 2293.3 Standard.
• Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
• Release the Test Button or Switch On Mains Supply, check that the emergency is Off (Non-
maintained operation)
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected.
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp Head is correctly connected.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Fault: Green LED flashes once every 5 seconds-Battery in disconnected
Check: Battery is connected.
Fault: Green LED blinks off once every 5 seconds- Charging very flat battery
Allow 20min to recover battery then recheck
Fault: Green LED flashes at 2Hz (Fast flash)- Faulty battery
Replace battery
Battery Replacement:
1. Prior to any work, isolate the power to the luminaire that requires battery replacement
2. Open the fitting by following step 2 and 3 from installation section.
3. Remove the Battery Connector from the Emergency Driver.
4. Remove the battery from the EM Driver slot.
5. Place the new Battery in designated clip and reconnect it to the EM Driver
6. Close the batten by following the last two steps from installation instruction.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or "cycled". The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
If flexible wiring is connected to this luminaire and is within arm's reach, the wiring shall be effectively
fixed to the wall to reduce the risk of strangulation.
Instruction Sheet Template - V1.2 – Updated 06/10/2021
Trade Series 1200mm EPIC LED Batten
Installation & Maintenance Instruction Leaflet
Designed in Australia to comply with the requirements of
AS2293.3: 2005 and AS/NZS CISPR15: 2017
Models: EPIC-1200-xx-yy-EM
Options:
Microwave Sensor (HI/LO) xx = SEN
DALI Driver yy = DD
Spare Parts:
1330088 LED Driver - 40w Stallion, SP2
1330089 LED Driver - 40w Stallion, MS-HL2 (SEN version only)
1330056 LED Driver - LCA 50w 350-1050mA, one4all Ip PRE (DD only)
AUM03670010001 ELIFE-X-LI-CKIT-2LED-SL2-NP, Lifelight: Eco, LED, NM, Controller, 2LED, SL2, NP
1560150 BATT:EcoLith 3.2V 3.0Ah 70mm lead,noBRKT
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
