Summary of Contents for CSL RUT200

  • Page 1 RUT200 RUT200...

  • Page 2: Technical Specifications

    RUT200 Technical Specifications 4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up Mobile module to 42 Mbps, 2G – Up to 236.8 kbps IEEE 802.11b/g/n, Access Point (AP), Wireless mode Station (STA) Power Connector 4-pin industrial DC power socket 9 –...

  • Page 3: Rear View

    Rear View Power Socket Pinout...
  • Page 5 RUT200 Quick Guide 1. Push the SIM holder button. 2. Pull out the SIM holder. 3. Insert your SIM card into the SIM holder.
  • Page 6 4. Slide the SIM holder back in to the router. 5. Attach both the MAIN and AUX mobile antenna connectors labelled "Mobile".
  • Page 7 6. Attach Wifi antenna to the connector labelled "Wifi". 7. Connect the 4-pin connector to the power socket on the front of the device, then plug the power adaptor into an electricity outlet.
  • Page 9 RUT200 Configure Your Computer LAN (Windows) 1. Ensure the Network connection is Enabled. Go to Start — Control Panel — Network and Internet — Network and Sharing Center. Click on the Change adapter settings in the left panel, then right-click on Network Adapter, and select Enable.
  • Page 11 RUT200 Configure your computer Wi-Fi (Windows) 1. Ensure the Wireless network connection is Enabled. Go to Start — Control Panel — Network and Internet — Network and Sharing Center. Click on the Change adapter settings in the left panel, then right-click on Wireless Network Adapter, and select Enable.
  • Page 12 4. Connect to a wireless network by right-clicking on Wireless Network Adapter and selecting Connect. 5. Choose the wireless network RUT200 **** from the list and click Connect. Enter the Wi-Fi password located on the device's label.

  • Page 13: Login To Device

    RUT200 Login to Device 1. To enter the router's Web interface (WebUI), type http://192.168.1.1 into the URL field of your Internet browser. 2. When prompted for authentication enter the username admin and enter the password located on the device information label/engraving.
  • Page 14 To achieve the best signal conditions and maximize cellular performance, try adjusting the antennas or changing the location of your device.
