Summary of Contents for CSL TRB500
- Page 1 TRB500 TRB500...
-
Page 2: Technical Specifications
TRB500 Technical Specifications 5G Sub-6Ghz SA/NSA 2.1/3.3Gbps DL (4x4 MIMO), 900/600 Mbps UL (2x2); 4G (LTE) – Mobile module LTE Cat 20 2.0Gbps DL, 200Mbps UL; 3G – 42 Mbps DL, 5.76Mbps UL Power Connector 4-pin industrial DC power socket 9 –... - Page 3 Power Socket Pinout...
- Page 4 TRB500 Quick Guide 1. Locate the SIM adaptor kit. 2. Push the SIM hjolder button with the SIM needle. 3. Pull out the SIM holder.
- Page 5 4. Insert your SIM card into the SIM holder. 5. Slide the SIM holder back into the router.
- Page 6 6. Attach all mobile antennas to connectors labelled "Mobile". 7. Connect the 4-pin connector to the power socket on the front of the device. Then plug the power adapter into an electric outlet.
- Page 8 TRB500 Configure your computer LAN (Windows) 1. Ensure the Network connection is Enabled. Go to Start — Control Panel — Network and Internet — Network and Sharing Center. Click on the Change adapter settings in the left panel, then right-click on Network Adapter, and select Enable.
-
Page 9: Login To Device
TRB500 Login to Device 1. To enter the gateway's Web interface (WebUI), type http://192.168.2.1 into the URL field of your Internet browser. 2. When prompted for authentication enter the username admin and enter the password located on the device information label/engraving. - Page 10 To achieve the best signal conditions and maximize cellular performance, try adjusting the antennas or changing the location of your device. You can find information on signal strength recommendations here.
