CD RDS RECEIVER
DEH-6310SD
DEH-6300UB
DEH-63UB
This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-3269
CRT4488
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2010
/XSUC
Mech. Module
S11.1STD-DOUT
CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
DEH-6310SD/XSUR
/XSUC
Remarks
ORDER NO.
CRT4642
/XSUR
K-ZZZ NOV. 2010 Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEH-6310SD/XSUR and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer DEH-6310SD/XSUR

Summary of Contents for Pioneer DEH-6310SD/XSUR

  • Page 1 PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2010 K-ZZZ NOV.

  • Page 2: Safety Information

    The AEL (accessible emission level )of the laser power output is less than CLASS 1 but the laser component is capable of emitting radiation exceeding the limit for CLASS 1. A specially instructed person should do servicing operation of the apparatus. DEH-6310SD/XSUR...
  • Page 3 CAUTION Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type recommended by the manufacture. Discord used batteries according to the manufacture's instructions. DEH-6310SD/XSUR...
  • Page 4 To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. DEH-6310SD/XSUR...

  • Page 5: Table Of Contents

    10.4 CD CORE UNIT (S11.1STD-DOUT) ......................62 10.5 SD UNIT ..............................64 10.6 WAVEFORMS............................65 11. PCB CONNECTION DIAGRAM ........................68 11.1 TUNER AMP UNIT ..........................68 11.2 KEYBOARD UNIT ..........................72 11.3 CD CORE UNIT (S11.1STD-DOUT) ......................74 11.4 SD UNIT ..............................76 12. ELECTRICAL PARTS LIST ...........................77 DEH-6310SD/XSUR...

  • Page 6: Service Precautions

    If the lead is bent, please correct the angle between the lead and the light receiving part to be 90 degrees or replace the infrared deteching unit for remote control (GP1UXC14RK). DEH-6310SD/XSUR...

  • Page 7: Notes On Soldering

    Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting temperatures (hard to melt/easy to harden). The following lead-free solders are available as service parts: Parts numbers of lead-free solder: GYP1006 1.0 in dia. GYP1007 0.6 in dia. GYP1008 0.3 in dia. DEH-6310SD/XSUR...

  • Page 8: Specifications

    WMA decoding format ..Ver. 7, 7.1, 8, 9, 10, 11, 12 (2ch audio) (Windows Media Player) AAC decoding format ..MPEG-4 AAC (iTunes encoded only) (Ver. 9.2 and earlier) WAV signal format ...Linear PCM & MS ADPCM (Non-compressed) DEH-6310SD/XSUR...
  • Page 9 • DEH-6310SD/XSUR Backup current ....5.0 mA or less DEH-6310SD/XSUR...

  • Page 10: Disc/Content Format

    2.2 DISC/CONTENT FORMAT DEH-6310SD/XSUR...

  • Page 11: Panel Facilities

    BAND/ESC  (eject) SRC/OFF USB port /DISP/SCRL CAUTION Use an optional Pioneer USB cable (CD-U50E) Indicator State to connect the USB audio player/USB memory as any device connected directly to the unit will Informa- protrude out from the unit and may be danger-...
  • Page 12 • DEH-6310SD/XSUR DEH-6310SD/XSUR...
  • Page 13 • DEH-6310SD/XSUR DEH-6310SD/XSUR...

  • Page 14: Connection Diagram

    6 White If you do not plan to detach the front panel, 7 White/black the front panel can be fastened with the supplied 8 Gray screw. 9 Gray/black a Green b Green/black Screw c Violet UC : BPZ20P060FTC d Violet/black DEH-6310SD/XSUR...
  • Page 15 • DEH-6310SD/XSUR DEH-6310SD/XSUR...
  • Page 16 • DEH-6310SD/XSUR Fastening the front panel If you do not plan to detach the front panel, the front panel can be fastened with the supplied screw. Screw UR : XXX7020 DEH-6310SD/XSUR...

  • Page 17: Basic Items For Service

    See the table below for the items to be checked regarding audio: Item to be checked regarding audio Distortion Noise Volume too low Volume too high Volume fluctuating Sound interrupted 3.2 PCB LOCATIONS A:DEH-6310SD/XSUR B:DEH-6300UB/XSUC C:DEH-63UB/XSUC Unit Number : YWM5502(A) : YWM5504(B,C) Unit Name : Tuner Amp Unit Unit Number...

  • Page 18: Jigs List

    CD Mechanism Module 3.4 CLEANING Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools CD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 DEH-6310SD/XSUR...
  • Page 19 DEH-6310SD/XSUR...

  • Page 20: Block Diagram

    VO1- MECHA VD VO2+ Q751 VO2- Q752 VO3+ SPINDLE LOEJ MOTOR LDIN VO3- CLCONT LCOM VO4+ MUTE LOADING/CARRIAGE CONT LCOP MOTOR VO4- RESET RESET RESET DSCSNS CD DATA (CDSRQ,CDSTBY,SKIP, CD DATA (CDSRQ,CDSTBY,SKIP, HOME SCL,SDA,DATA,BCLK,LRCK,WAIT) SCL,SDA,DATA,BCLK,LRCK,WAIT) S903 S901 DSCSNS HOME DEH-6310SD/XSUR...
  • Page 21 Q591 SW5V MEDRST SWVDD MED33V SDCTL SD_WP 115 VBUS(US5V) CPPWR MED33V USB5V CP_SCL CP_SDA CPRST FLASH ROM :DEH-6310SD/XSUR IC571 CWW2867 :DEH-6300UB/XSUC RESET RESET :DEH-63UB/XSUC VDSENS FLASH ROM IC461 SST25V040BIS SD UNIT CN781 CN1202 JA1203 SD DATA (DATA0 - DATA3, CLK, CMD) SD33V REG.
  • Page 22 GREEN (2/2) BLUE (1/2) (2/2) (1/2) (2/2) (1/2) (2/2) (1/2) (2/2) (1/2) (2/2) (1/2) (2/2) (1/2) (2/2) (1/2) (2/2) (2/2) (1/2) (2/2) (1/2) ILM+B ILM+B ILM+B ILM+B ILM+B GREEN (2/2) BLUE (1/2) (1/2) (1/2) (2/2) (2/2) ILM+B VBUS(US5V) VBUS(US5V) DEH-6310SD/XSUR...

  • Page 23: Diagnosis

    In case of the above signal, the communication Source keys with Grille microcomputer may fail. operative If the time interval is not 500 msec, the oscillator may be defective. Source ON SYSPW <- H Pin 46 Completes power-on operation. (After that, proceed to each source operation) DEH-6310SD/XSUR...

  • Page 24: Error Code List

    • How to restore from each error is shown below. classification, shown below. 0x, 1x and 3x: ACC-OFF then ON, CD-OFF then ON, 0x: Servo-related errors Disc ejection 1x: Servo-related errors 5X: ACC-OFF then ON, Disc ejection, Disc reloading 3x: Servo-related errors 5x: Mechanism-related errors DEH-6310SD/XSUR...
  • Page 25 ERROR-23 USB storage de- USB storage de- vice was not for- vice should be for- matted with matted with FAT12, FAT16 or FAT12, FAT16 or FAT32 FAT32. DEH-6310SD/XSUR...
  • Page 26 VICE message dis- iPod/iPhone. played in Pandora Appli- cation. Unable to play music from Pandora. NO STATION No station Create a station found. in the Pandora application on your iPod/iPhone. NO ACTIVE No station se- Select a station. lected. DEH-6310SD/XSUR...
  • Page 27 • DEH-6310SD/XSUR DEH-6310SD/XSUR...
  • Page 28 DEH-6310SD/XSUR...

  • Page 29: Connector Function Description

    6 RR+ 14 B.REM 7 RL- 15 B.UP 16 GND 8 RR- FRONT REAR OUTPUT OUTPUT DEH-6310SD/XSUR ANTENNA WIRED SUBWOOFER REMOTE OUTPUT 15 13 11 9 7 5 3 1 CONTROL 16 14 12 10 8 6 4 2 1 FL+...

  • Page 30: Service Mode

    Usual product operation is implemented to outward appearances. Display update is stopped The screen gets still when entering this item. Every segment lights up Every segment including icons lights up. Every segment goes out Every segment including icons goes out. DEH-6310SD/XSUR...

  • Page 31: Cd Test Mode

    When the power is turned on/off the gain of the RFAMP is reset to 0 dB. At the same time all the self-adjusting values shall return to the default setting. Do not do Tracking Servo Close before doing Focus Servo Close. (Because the overcurrent flows) DEH-6310SD/XSUR...

  • Page 32: Disassembly

    Lift off the Tuner Amp Assy from the Heat sink side. The Tuner Amp Assy is fixed into the ditch. Disconnect the FFC and then remove the CD Mechanism Module. Fig.4 CD Mechanism Module DEH-6310SD/XSUR...
  • Page 33 Remove the two screws. Straighten the three tabs Fig.5 at two locations indicated and then remove the Tuner Amp Unit. Tuner Amp Unit Attention of removing (Fig.6) Don't remove this screws excluding the dismantlement of the CD Mechanism Module. Fig.6 DEH-6310SD/XSUR...
  • Page 34 1. Attach the button from the front side of the panel. Fig.9 2. Attach the spring to the arm as shown in the figure. The bended tip of the spring is set to this side. Hitch the spring to the groove. Fig.10 DEH-6310SD/XSUR...
  • Page 35 4. Fit the boss on the lower side of the arm in the lower hole of the panel, and then warp the rib on the panel in the direction shown in the figure and fit the boss of the arm in the panel. Fig.11 DEH-6310SD/XSUR...
  • Page 36 2. Be careful not to hold the solid line portions or the CRG mecha part or insert foreign substances, to prevent distortion. 3. When holding the sides of the upper chassis, do not apply excessive force to prevent distortion. (Approx. 8N or less) Correct way of holding the unit Incorrect way of holding the unit DEH-6310SD/XSUR...
  • Page 37 1. Create an empty clamp state according to “How to create empty clamp state of mecha module”. 2. Apply 1.5 V to the CRG motor and move the PU to the outer circumference. (Caution) After moving the PU to the outer circumference and performing necessary treatment, make sure to solder the lead wires. DEH-6310SD/XSUR...

  • Page 38: Each Setting And Adjustment

    1k ohms in series. The load and eject operation is not guarantied with the mechanism upside down. If the mechanism is blocked due to mistaken eject operation, reset the product or turn off and on the ACC to restore it. DEH-6310SD/XSUR...

  • Page 39: Checking The Grating After Changing The Pickup Unit

    Because of eccentricity in the disc and a slight misalignment of the clamping center the grating waveform may be seen to "wobble" ( the phase difference changes as the disc rotates). The angle specified above indicates the average angle. Hint Reloading the disc changes the clamp position and may decrease the "wobble". DEH-6310SD/XSUR...
  • Page 40 Grating waveform Ech -> Xch 20 mV/div, AC Fch -> Ych 20 mV/div, AC 0 degrees 30 degrees 45 degrees 60 degrees 75 degrees 90 degrees DEH-6310SD/XSUR...

  • Page 41: Pcl Output Confirmation

    The frequency of the clock signal is 625.0 kHz that is one 32th of the fundamental frequency (20 MHz). The clock signal should be 625.0 kHz(- 10 Hz, + 15 Hz). If the clock signal is out of the range, the X'tal (X601) should be replaced with new one. DEH-6310SD/XSUR...

  • Page 42: Exploded Views And Parts List

    9. EXPLODED VIEWS AND PARTS LIST 9.1 PACKING 6300UC 63UC 6300UC 63UC 63UC 6300UC DEH-6310SD/XSUR...
  • Page 43 PACKING SECTION PARTS LIST Mark Description DEH-6310SD/XSUR DEH-6300UB/XSUC DEH-63UB/XSUC Cord Assy QDP3012 QDP3013 QDP3013 Polyethylene Bag QEG3001 CEG1173 CEG1173 Protector QHP3016 QHP3016 CHP4103 Protector QHP3016 QHP3016 CHP4104 Handle QNC3021 Not used Not used Remote Control Unit Not used CXE3669 CXE3669...

  • Page 44: Exterior

    9.2 EXTERIOR DEH-6310SD/XSUR...
  • Page 45 Button(SRC, BAND) YAC5427 Case See Contrast table (2) Button(TA(UR), TAG(UC)) YAC5428 Panel YNS5625 Button(EJECT) YAC5429 (2) CONTRAST TABLE DEH-6310SD/XSUR, DEH-6300UB/XSUC and DEH-63UB/XSUC are constructed the same except for the follow- ing: Mark Description DEH-6310SD/XSUR DEH-6300UB/XSUC DEH-63UB/XSUC Cord Assy QDP3012 QDP3013 QDP3013...

  • Page 46: Cd Mechanism Module

    ( C ) ( A ) ( A ) ( A ) ( C ) ( C ) ( A ) : GEM1045 ( B ) : GEM1038 ( C ) : GEM1024 ( C ) ( D ) : GEM1043 DEH-6310SD/XSUR...
  • Page 47 CNV8342 Guide CNW1171 Roller CNW1172 CNW2157 CNW1174 Roller CNW1175 Lever CNW1176 CNW1177 CNW1178 Gear CNW1180 Gear CNW1181 ..Gear CNW1183 Rack CNW1184 Gear CNW1185 Gear CNW1186 Gear CNW1187 Gear CNW1188 Clamper CNW1190 CNW1192 Holder CNW1193 Holder CNW1194 Damper CNW1197 DEH-6310SD/XSUR...

  • Page 48: Schematic Diagram

    R814 L450 0.01u/16 C453 R810 L418 AUXG AUXG AUXG 0.01u/50 L801 1608 VOUT 1/4W C452 AUXR R410 R412 AUXR AUXR 1/4W CCG1201-A 4.7u/10 USBG R816 100 USBG C451 L411 DSENS R801 2.2k DSENS R422 1608 R809 100k TUNER5V REG DEH-6310SD/XSUR...
  • Page 49 1608 R809 100k C2 3 100k discrete resistors. 1.8k B1 2 5 B2 (1/4W) Symbol indicates a capacitor. E1 1 6 C1 Q824 No differentiation is made between chip capacitors and NM : No Mount RGB ILM discrete capacitors. DEH-6310SD/XSUR...
  • Page 50 DEH-6310SD/XSUR...
  • Page 51 DEH-6310SD/XSUR...
  • Page 52 DEH-6310SD/XSUR...
  • Page 53 DEH-6310SD/XSUR...

  • Page 54: Tuner Amp Unit (2/2) (Guide Page)

    DAC & LPF 461 - 470 TAGGING 701 - 750 MECHA 751 - 780 MECHA VD 501 - 570 MEDIA uCOM 781 - 800 SD CONNECT 571 - 580 FLASH ROM WE0/DQML 581 - 590 MED3.3V & MED1.2V MEDRST2 SPAN DEH-6310SD/XSUR...
  • Page 55 R502 100 MEDRST MEDRST2 C572 IC571 0.1u/10 /BYTE Vss2 PD15 DQ15_A-1 R575 PD14 DQ14 PD13 DQ13 R576 PD12 DQ12 WE0/DQML MEDRST2 /RESET PD11 DQ11 R577 PD10 RY_/BY DQ10 R578 Vss1 FLCS R574 R572 CWW2867 4.7k 4.7k FLASH ROM SPANSION 16Mbit DEH-6310SD/XSUR...
  • Page 56 DEH-6310SD/XSUR...
  • Page 57 DEH-6310SD/XSUR...
  • Page 58 DEH-6310SD/XSUR...
  • Page 59 DEH-6310SD/XSUR...

  • Page 60: Keyboard Unit

    KDT4 SEG22 SEG22 ROUT3 SEG21 IMLCLR1 SEG21 ROUT2 SEG20 SEG20 SEG19 5.000MHz SEG19 SEG18 CSS1547-A SEG18 SEG17 SEG17 SEG16 SEG16 RESET SEG15 MOD1 SEG15 SEG14 MOD0 DGND SEG14 DGND DGND HN1C01FU(YGR) HN1C01FU LCD1 YAW5109-A ILMGND HN1C01FU(YGR) HN1C01FU(YGR) HN1C01 ILMGND DEH-6310SD/XSUR...
  • Page 61 JOYST DGND ROT0 2.7k ILM+B CN801 2.7k 2.7k VBUS(US5V) 1u/10 AUXL AUXG AUXR USBG DSEN 100p/50 1000p/50 0.01u/50 DGND DGND YKS5039-A HN1C01FU(YGR) FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) ILMGND USB:+2.00 dBs FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) HN1C01FU(YGR) NSSM038A-6430 NSSM038A-6430 DEH-6310SD/XSUR...

  • Page 62: Cd Core Unit (S11.1Std-Dout)

    MOTOR DRIVER LOGIC TABLE PowVcc2 1u/10 VO1- VO4- LOAD PLAY (1608) (1608) VO1+ VO4+ CLCONT VO2- VO3- LOEJ SWITCHES: CD CORE UNIT VO2+ VO3+ CONT S901:HOME SWITCH..ON-OFF IC301 S903:DSCSNS SWITCH..ON-OFF BA5839FP S905:8EJ SWITCH....ON-OFF The underlined indicates the switch position. PGND DEH-6310SD/XSUR...
  • Page 63 3.3V LRCK 10 GND R606 BCLK DATA 11 DATA NM (1608) DATA BCLK 12 BCLK LRCK 13 LRCK AAGND1 AAGND2 14 GND 15 PGND /WAIT 16 WAIT i h g PGND NO MOUNT PARTS (NM) Land for manual soldering DEH-6310SD/XSUR...

  • Page 64: Sd Unit

    10.5 SD UNIT SD UNIT (only UR) CN1202 VKN1302-A SD_DATA1 SD_DATA0 SD_CLK SD33V SD_CMD CN781 SD_DATA3 SD_DATA2 SD_WP SD_CD JA1203 YKS5040-A DEH-6310SD/XSUR...

  • Page 65: Waveforms

    1 V/div fRFAGC 500 mV/div 500 mV/div 500 mV/div 9TIN 500 mV/div Focus Search waveform Track Open waveform 100 Track Jump waveform (32 Track Jump x 3) Ref.: Ref.: Ref.: REFO REFO REFO Mode: Mode: Mode: TEST TEST TEST DEH-6310SD/XSUR...
  • Page 66 12 cm CD Eject operation Ref.: Ref.: Ref.: REFO AGND Mode: Mode: Mode: Normal Normal Normal 500 μs/div fRFAGC 1 V/div 9TIN 1 V/div 1 V/div aFIN 1 V/div μ Black Dot (800 m) during play Ref.: REFO Mode: Normal DEH-6310SD/XSUR...
  • Page 67 DEH-6310SD/XSUR...

  • Page 68: Pcb Connection Diagram

    R194 C195 Q782 R796 R193 C781 IC151 C151 L781 R794 Q783 R831 C152 R832 Q832 L151 C166 C831 C832 Q831 C206 L202 L831 Q201 D201 C204 R209 D832 C839 C835 C833 CN1202 C838 IC831 (only UR) R836 C836 CN701 DEH-6310SD/XSUR...
  • Page 69 C563 R575 C705 R704 R465 Q841 R464 R703 Q591 L841 R843 IC801 R467 R803 R812 R820 R813 R592 C461 Q842 R815 L591 R593 C803 R595 R597 R802 L801 R531 IC591 IC461 VA812 C591 C592 C802 R600 CN801 C801 FRONT DEH-6310SD/XSUR...
  • Page 70 TUNER AMP UNIT TEST1 PCL1 DEH-6310SD/XSUR...
  • Page 71 SIDE B DEH-6310SD/XSUR...

  • Page 72: Keyboard Unit

    11.2 KEYBOARD UNIT KEYBOARD UNIT SIDE A DEH-6310SD/XSUR...
  • Page 73 KEYBOARD UNIT SIDE B CN801 DEH-6310SD/XSUR...

  • Page 74: Cd Core Unit (S11.1Std-Dout)

    C213 C214 R215 R306 C215 R308 C305 C304 C203 C238 C307 C212 C240 C299 IC201 R307 R305 C207 C204 R707 C209 X201 R294 IC301 R264 C702 R225 R282 C211 R708 C210 R232 R709 R281 C306 R710 C701 CN701 CN701 DEH-6310SD/XSUR...
  • Page 75 C231 C232 S905 C233 R237 R723 R721 R722 R260 R702 R297 R701 R283 R242 R602 C283 C281 C602 R292 R291 C282 R243 R606 R604 DSCSNS R299 R601 R706 C708 R293 C601 S903 C705 C703 R603 C710 C284 C707 R711 DEH-6310SD/XSUR...

  • Page 76: Sd Unit

    11.4 SD UNIT SD UNIT SIDE A (only UR) CN1202 CN781 JA1203 SD UNIT SIDE B (only UR) DEH-6310SD/XSUR...

  • Page 77: Electrical Parts List

    12. ELECTRICAL PARTS LIST Circuit Symbol and No. Part No. Circuit Symbol and No. Part No. IC 581 (A,42,103) Regulator IC S-1172B33-E6 A:DEH-6310SD/XSUR IC 583 (A,43,95) IC BH12PB3WHFV B:DEH-6300UB/XSUC IC 591 (A,130,14) IC 341S2162 IC 601 (A,122,96) IC(A) PEG729A8 C:DEH-63UB/XSUC...
  • Page 78 (A,88,129) Chip Coil(A) BTH1101 (A,23,130) (B,C) RS1/16SS821J L 981 (A,113,142) Choke Coil 600 uH CTH1432 R 306 (A,28,130) (A) RS1/16SS820J X 401 (A,164,93) Oscillator 36.48 MHz CSS1805 (A,28,130) (B,C) RS1/16SS821J R 307 (A,6,132) RS1/16SS223J X 501 (A,121,68) Oscillator 48.000 MHz CSS1760 DEH-6310SD/XSUR...
  • Page 79 R 469 (A,83,115) RS1/16SS102J R 643 (A,149,75) RS1/16SS104J R 501 (A,131,63) RS1/16SS473J R 651 (A,75,102) RS1/16SS104J R 502 (A,133,61) RS1/16SS101J R 652 (A,75,104) RS1/16SS152J R 504 (A,129,65) RS1/16SS473J R 661 (A,50,135) RS1/10SR102J R 662 (A,49,135) RS1/10SR102J R 505 (A,128,65) RS1/16SS473J DEH-6310SD/XSUR...
  • Page 80 R 832 (A,7,86) (A) RS1/10SR122J C 218 (A,72,126) 10 uF CCG1192 R 833 (A,14,83) (A) RS1/16SS1R0J C 219 (A,57,120) CKSRYB105K10 R 835 (A,19,55) (A) RS1/10SR821J C 220 (A,68,117) CKSRYB105K10 R 836 (A,8,55) (A) RS1/10SR153J R 837 (A,12,55) (A) RS1/10SR332J DEH-6310SD/XSUR...
  • Page 81 C 422 (A,145,102) CKSSYB104K16 C 535 (A,101,48) CKSRYB104K16 C 423 (A,139,101) CKSSYB103K16 C 536 (A,103,44) CKSRYB104K16 C 424 (A,165,97) CKSSYB472K25 C 425 (A,165,98) CKSSYB472K25 C 537 (A,103,40) CKSSYB104K10 C 426 (A,162,96) CKSSYB104K16 C 538 (A,103,39) CKSSYB104K10 C 539 (A,112,35) CKSSYB104K10 DEH-6310SD/XSUR...
  • Page 82 (A,154,11) Jack YKN5006 YAW5110 C 921 (A,115,128) CKSSYB104K16 C 941 (A,102,128) CKSRYB473K50 C 951 (A,90,130) (A) CKSSYB104K16 RESISTORS (B,102,18) RS1/16S222J Unit Number : (A) (B,103,20) RS1/16S222J (B,7,10) RS1/4SA221J : (B,C) (B,11,10) RS1/4SA181J Unit Name : Keyboard Unit (B,51,31) RS1/4SA181J DEH-6310SD/XSUR...
  • Page 83 R 76 (B,38,19) RS1/4SA471J R 235 (A,45,32) RS1/16SS103J R 236 (A,46,32) RS1/16SS103J CAPACITORS R 237 (B,24,25) RS1/16SS221J R 240 (B,26,30) RS1/16SS473J R 245 (B,28,30) RS1/16SS104J (B,116,20) 10 uF CCG1192 R 254 (B,29,30) RS1/16SS104J (B,110,19) CKSRYB474K16 R 260 (B,41,21) RS1/16SS103J DEH-6310SD/XSUR...
  • Page 84 C 232 (B,45,28) CKSSYB102K50 C 233 (B,25,25) CKSSYB103K16 C 236 (B,26,41) CKSSYB104K10 C 238 (A,15,35) CKSRYB104K16 C 299 (A,17,33) CKSSYB104K10 C 304 (A,60,35) CKSSYB472K25 C 305 (A,58,35) CKSSYB223K16 C 306 (A,68,20) CKSRYB105K10 C 710 (B,43,10) CKSSYB102K50 Unit Number : YWM5516(A) DEH-6310SD/XSUR...
