ASROCK AD425PV3 Specifications

AD425PV3
® TM
Intel Atom D425 CPU + NM10 Express Chipset
DDR3 800
Product Brief
- Intel Atom Processor D425 (1.8 GHz)
® TM
- Solid Capacitor for CPU power
- Supports Dual Channel DDR3 800
- Intel GMA 3150, DirectX 9.0 and Max. shared
®
memory 384MB
- 1 x PCI slot, 2 x SATAII 3.0 Gb/s connectors,
PCIE Gigabit LAN
- Supports ASRock Instant Boot, Instant Flash,
OC Tuner, OC DNA, AIWI, APP Charger,
SmartView
- ErP/EuP Ready
- Free Software : CyberLink DVD Suite - OEM and
Trial; Creative Sound Blaster X-Fi MB - Trial
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Intel
Atom
D425
CPU
w w w. a s ro ck . c o m
Detail Specification
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
Platform
- Solid Capacitor for CPU power
- Intel Atom
® TM
CPU
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Southbridge: Intel
Chipset
- 2 x DDR3 DIMM slots
Memory
- Supports DDR3 800 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI slot
Expansion Slot
- Intel Graphics Media Accelerator 3150
®
Graphics
- Pixel Shader 2.0, DirectX 9.0
- Max. shared memory 384MB
- Supports D-Sub with max. resolution up to 2048x1536
@ 60Hz
- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
Audio
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
LAN
- Atheros AR8151
®
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Parallel Port (ECP/EPP Support)
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
- 2 x SATAII 3.0 Gb/s connectors, support NCQ, AHCI and
Connector
Hot Plug functions
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 4Mb AMI BIOS
BIOS Feature
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- VCCM, SB Voltage Multi-adjustment
- Drivers, Utilities, AntiVirus Software (Trial Version),
Support CD
ASRock Software Suite (CyberLink DVD Suite - OEM
and Trial; Creative Sound Blaster X-Fi MB - Trial)
- ASRock OC Tuner
Unique Feature
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- ASRock AIWI
- ASRock APP Charger
- SmartView
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft Windows
®
OS
XP / XP 64-bit compliant
- FCC, CE, WHQL
Certifications
- ErP/EuP Ready (ErP/EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- 2 x SATA Data Cables (Optional)
Processor D425 (1.8 GHz)
NM10 Express
®
7 / 7 64-bit / Vista / Vista
® TM TM
64-bit /
