- Page 1 OPERATION MANUAL GARDEN PRODUCTS LAWN M O W E R GZ132 GZ149 GZ-X196...
- Page 2 WARNING! Read this manual carefully before using your lawn mower and keep it in a safe place for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS DESCRIPTION OF PRODUCT PARTS TECHNICAL SPECIFICATIONS INTENDED USE SAFETY INFORMATION ASSEMBLY PREPARING THE ENGINE ADJUSTMENT OPERATION MAINTENANCE AND STORAGE TROUBLESHOOTING WARRANTY... -
Page 4: Description Of Product Parts
DESCRIPTION OF PRODUCT PARTS As shown below 1. Throttle lever 10. Rear wheel 2. Upper handle 11. Oil filler cap and dipstick 3. Fast clip 12. Central height adjustment handle 4. Cable clip 13. Fixing knob 5. Lower handle 14. Engine starter handle 6. - Page 5 DESCRIPTION OF PRODUCT PARTS Check the delivery parts As shown below Carefully remove the lawn mower from its packaging and check as the following parts are complete: Lower handle B. Main unit with upper handle C. Mulching plug D. Lower grass catcher Upper grass catcher Grass catcher cover G.
-
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Model GZ132 GZ149 GZ-X196 Engine model NP130 NP150 XP200 Engine displacement 132 cc 149 cc 196 cc Cutting width 460 mm 460 mm 460 mm Cutting blade Oval disc + Round disc + Round disc +... -
Page 7: Safety Information
DESCRIPTION OF PRODUCT PARTS SAFETY INFORMATION WARNING! To reduce the risk of injury, user must read and understand the instruction manual before using the mower WARNING! Beware of thrown objects Keep bystanders away WARNING! Keep hands and feet away from the blades Unplug the spark plug before maintenance Risk of fire Never refuel while the engine is running... - Page 8 GENERAL SAFETY WARNINGS GENERAL SAFETY WARNINGS Training Read the instructions carefully. Be familiar with the controls and the proper use of the mower; Never allow children or people unfamiliar with these instructions to use the mower. Local regulations can restrict the age of the operator; Never mow while people, especially children or pets are nearby;...
- Page 9 GENERAL SAFETY WARNINGS example deflectors and/or grass catchers; 12. Do not change the engine governor settings or over speed the engine; 13. Disengage all blades and drive clutches before starting the engine; 14. Start the engine or switch on the motor carefully according to instructions and with feet well away from the blade(s);...
-
Page 10: Assembly
ASSEMBLY ASSEMBLY Assembling the handle Attached the lower handle to the bracket with Fixing knobs and nuts (x4) provided. Attaching the upper handle Attach the upper handle to the lower handle using the fast clips and bolts (x2) provided. Fix the cable throttle control cable to the handle with the cable clip. Lower handle Assembling the grass catcher... - Page 11 ASSEMBLY Attaching the grass catcher onto the mower 1. Lift the rear flap 2. Put the grass catcher to the mower, hold the grass catcher and put down the rear flap on the grass catcher. Attaching the mulching plug Warning! Stop the engine before inserting or removing the mulching plug 1.
-
Page 12: Preparing The Engine
10. After checking, replace and tighten the oil filler cap and dipstick. 11. Make sure that the oil filler cap and dipstick is securely tightened before starting the engine. Oil filler cap and dipstick Min Max GZ132/GZ149 engine (NP130/NP150) GZ-X196 engine (XP200) - Page 13 4. Clean up any overflow or splashes of fuel (petrol) before starting the engine. 5. Replace the fuel tank cap and wait for 5 minutes for excess fuel (petrol) to evaporate, before starting the engine. Fuel tank cap Fuel tank cap GZ132/GZ149 engine (NP130/NP150) GZ-X196 engine (XP200)
-
Page 14: Adjustment
ADJUSTMENT ADJUSTMENT Adjusting cutting height WARNING! Stop and turn off the engine before adjusting the cutting height. 1. The cutting height has 10 settings, ranging from 15 mm to 80 mm. 2. Pull the cutting height adjusting handle out and move it to the desired cutting height notch. - Page 15 OPERATION CAUTION! Before starting the engine, make sure that spark plug lead is connected to the spark plug, the engine is filled with engine oil and fuel (petrol). 1. Press the primer bulb 3-5 times. 2. Move the throttle lever to the rabbit position. 3.
-
Page 16: Maintenance And Storage
MAINTENANCE AND STORAGE MAINTENANCE AND STORAGE WARNING! Disconnect the spark plug lead from the spark plug before maintenance. Maintenance schedule The following maintenance schedule is recommended: 12 hours of use 24 hours of use 36 hours of use Engine oil check change check... - Page 17 5. Reinstall the air filter element and close the air filter cover. Air filter cover Air filter cover GZ-X196 engine (XP200) GZ132/GZ149 engine (NP130/NP150) Changing engine oil 1. Remove the oil filler cap and dipstick and tilt the mower, drain the oil into a container.
- Page 18 5. Replace the blades and secure the blades with the blade setting bolts. Oval disc 2 blades Round disc 4 blades (GZ132) (GZ149 / GZ-X196) Storing the mower Fuel can become stale when stored over 30 days, Stale fuel causes acid and gum deposits to form in the fuel system.
-
Page 19: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Problem Possible cause Possible solution Screws/bolts are loose Tighten the screws/bolts Noisy and vibrates Blade is loose Tighten the blade heavily Blade is unbalanced Balance the blade Throttle lever at incorrect Check the throttle lever position Engine cannot start Fuel tank is empty Refill the fuel Spark plug is flooded... -
Page 20: Warranty
WARRANTY WARRANTY This product is covered by a 2 year parts and labour warranty against manufacturing defects. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
