GForce GLR-30H Operation Manual

Garden products 30 inch ride on mower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATION MANUAL
GARDEN
PRODUCTS
30 INCH
RIDE ON
MOWER
GLR-30H
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLR-30H and is the answer not in the manual?

Questions and answers

Related Manuals for GForce GLR-30H

Summary of Contents for GForce GLR-30H

  • Page 1 OPERATION MANUAL GARDEN PRODUCTS 30 INCH RIDE ON MOWER GLR-30H...
  • Page 2 WARNING! Read this manual carefully before using YEAR YEARS your ride on mower and keep it in a safe place for future reference. BELT, BATTERY ENGINE & CHASSIS AND EASY DAMAGED PARTS...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTENDED USE DESCRIPTION OF PRODUCT PARTS PACKAGE CONTENT LIST SYMBOLS GENERAL SAFETY WARNINGS ASSEMBLY PREPARTION OPERATION CLEANING, MAINTENANCE AND STORAGE TROUBLESHOOTING DISPOSAL TECHNICAL SPECIFICATIONS WARRANTY...

  • Page 4: Intended Use

    INTENDED USE 1. INTENDED USE The 30 inch ride on mower is for cutting grass on lawns. It is for outdoor use only. It is designed for domestic use and is not designed for commercial, trade or industrial use.

  • Page 5: Description Of Product Parts

    DESCRIPTION OF PARTS 2. DESCRIPTION OF PRODUCT PARTS Clutch/Brake Pedal: The pedal has two functions - clutch and brake Parking Brake: Use to engage the brake when you leave your mower. Lift Lever: Use to adjust the cutting height. Throttle Control Lever: Use to increase or decrease the speed of the engine.

  • Page 6: Package Content List

    PACKAGE CONTENT LIST 3. PACKAGE CONTENT LIST Fig. B Seat Fig. B Steering wheel and Steering post Steering tube Bag of small parts Side discharge attachment Instruction manual • Remove all packing materials • Ensure all parts are present • Check the mower and all accessories for transportation damages WARNING: Packaging materials are not toys! Children must not play with plastic bags! Danger of suffocation!

  • Page 7: Symbols

    WARNING SYMBOLS 4. EXPLANATION OF SYMBOLS This section depicts and describes safety symbols that may appear on this product. Read, fully understand and follow all instructions on the machine before attempting to assemble and operate it. To reduce the risk of injury, users must read the instruction manual carefully.
  • Page 8 WARNING SYMBOLS Before and during backing, always look down and behind you, make sure that children, bystanders, and pets are clear of the area. Wear ear protection. Wear eye protection. Wear protective gloves. Do not expose to rain. Wait until the engine is completely stopped before touching the moving parts.

  • Page 9: General Safety Warnings

    GENERAL SAFETY WARNINGS 5. GENERAL SAFETY WARNINGS Know your control. Read the instruction manual carefully. Learn how to stop the engine quickly in any emergency. Operators shall have adequate training before operating the mower. Do not allow children or people unfamiliar with these instructions to use the mower.
  • Page 10 GENERAL SAFETY WARNINGS 10. It is advisable to wear suitable eye protection when operating a mower. 11. Mow only in good daylight. 12. Before using, always visually inspect to see that blades, blade bolts and cutter assembly are not worn or damaged. Replace worn or damaged blades and bolts in sets to preserve balance.

  • Page 11: Assembly

    ASSEMBLY 6. ASSEMBLY 1. ASSEMBLING THE STEERING WHEEL 1. Make sure the front wheels point forward. 2. Slide the tube into the console. Make sure the end of the tube fits over the steering bushing. 3. Slide the steering wheel and steering post into the tube and console. 4.
  • Page 12 ASSEMBLY 3. Align the holes in the seat to the holes in the seat support. Fasten the seat to the seat support with the bolts and wing bolts provided. 4. Check the operating position of the seat. If the seat needs to be adjusted, loosen the wing bolts.
  • Page 13 5. INSTALLING THE MULCHER COVER 1. Remove the fasteners that secure the mulcher cover. 2. Lift the mulcher cover. Mount the side discharge attachment onto the same bolts that secured the mulcher cover. 3. Secure the side discharge attachment with the fasteners. 4.

  • Page 14: Prepartion

    PREPARTION 7. PREPARTION 1. CHECKING ENGINE OIL LEVEL AND ADDING OIL WARNING! Be sure to check the engine oil while the mower is on level ground with the engine turned off. WARNING! To avoid engine damage, check oil level before each use and be sure the oil fill cap is tightened securely.
  • Page 15 PREPARTION 2. FILLING FUEL WARNING! Use fresh unlead fuel (petrol), 90 Octane or better. Do not use E10 or Ethanol blends. WARNING! Fuel (petrol) is highly inflammable. Handle the fuel (petrol) with extreme precaution. Keep the fuel (petrol) out of reach of children. WARNING! Do not smoke when handling the fuel (petrol).

  • Page 16: Operation

    OPERATION 8. OPERATION WARNING! Check and ensure all controls are properly functioning before operating the mower. WARNING! Stop the engine and park the mower before leaving the operator's position. WARNING! The mower shall not be operated without the grass catcher in place.
  • Page 17 OPERATION 2.1 Key start 1. Push the clutch/brake pedal completely forward, Keep your foot on the pedal. 2. Move the shift lever to the neutral (N) position. 3. Make sure the blade rotation control is in the disengage position. 4. Move the throttle control to the fast (rabbit) position. 5.
  • Page 18 OPERATION 4. CHANGING THE SPEED AND DIRECTION OF THE MOWER - SHIFT LEVER The speed and direction of the mower can be controlled by the shift lever. To go forward, move the shift lever to a forward speed setting. To go backward, move the shift lever to reverse position. Fig.
  • Page 19 OPERATION 6. ENGAGING THE BLADE 1. Move the blade rotation control lever forward to engage the blade. 2. Move the blade rotation control lever backward to disengage the blade. Fig. 11...

  • Page 20: Cleaning, Maintenance And Storage

    CLEANING, MAINTENANCE AND STORAGE 9. CLEANING, MAINTENANCE AND STORAGE WARNING! Stop the engine and remove the key from the ignition control, wait until the engine and the blade are completely stopped before preforming any cleaning, maintenance and storage. 1. CLEANING 1.1.
  • Page 21 CLEANING, MAINTENANCE AND STORAGE Fig. 12 2. MAINTENANCE 2.1 Maintenance schedule The following maintenance schedule is recommended: 12 hours of use 24 hours of use 36 hours of use Engine oil check change check Air filter clean clean clean Spark plug check clean check...
  • Page 22 CLEANING, MAINTENANCE AND STORAGE 2.3 Removing and installing the blade Raise the cutting height of the mower to the highest position. b. Wedge a block of wood between the blade and the mower deck to prevent the blade from turning. Loosen the blade nut by turning it anti-clockwise (as viewed from the bottom of the mower.

  • Page 23: Troubleshooting

    TROUBLESHOOTING 10. TROUBLESHOOTING Problem Cause Solution Engine fails to Blade is engaged Disengage the blade start Spark plug wire Connect the spark plug wire disconnected Fuel tank is empty Fill the fuel tank Faulty spark plug Change the spark plug Engine flooded Clean the engine Parking brake is not engaged Engage the parking brake...

  • Page 24: Disposal

    DISPOSAL 11. DISPOSAL Dispose of your mower according to the regulations and requirements of your local council. If appliances are disposed of in landfills or dumps, hazardous substances may leak into the ground water and get into the food chain, damaging your health and well-being. Do not dispose of rechargeable battery with your household refuse.

  • Page 25: Technical Specifications

    TECHNICAL DATA 12. TECHNICAL DATA Dimension Assembled Length 1550 mm Assembled Height 850 mm Assembled Width Without Discharge 1150 mm Deflector Net Weight 160 kg Mower & Deck Front 10” ( Ø 260×95 mm) Pneumatic Tyre Sizes Rear 14” ( Ø 360×160 mm) Cutting Width 76 cm Blade Cutting Diameter...
  • Page 26 TECHNICAL DATA Performance Driving Maximum Forward Speed 7 km/h Maximum Reverse Speed 2-3.5 km/h Noise Measured sound pressure level(LPA ) 78.8 dB(A) Measured sound power level(LwA ) 100.4 dB(A) Guaranteed sound power level 100 dB(A)

  • Page 27: Warranty

    WARRANTY 13. WARRANTY This product is covered by a 2 year parts and labour warranty for engine and chassis (1 year for belt, battery and easy damaged parts) against manufacturing defects. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
