Ryobi RPLL4 Original Instructions

ORIGINAL INSTRUCTIONS
USB Lithium Pivoting Laser Light
RPLL4
IMPORTANT!
It is essential that you read the instructions
in this manual before assembling, operating,
and maintaining the product.
Subject to technical modifications.
Safety, performance, and dependability have
been given top priority in the design of your
pivoting head light.
INTENDED USE
The light is intended for general illumination.
The product can also be used as a laser
pointer.
With the magnetic function, the product can be
attached to horizontal steel flat surfaces.
Do not use the product for any other purpose.
Use of the product for operations different from
intended could result in a hazardous situation.
LIGHT SAFETY WARNINGS
■ The light source of this luminaire is not
replaceable. When the light
reaches its end of life the whole luminaire
shall be replaced.
■ Use only with recommended battery pack
and charger. Any attempt to use another
battery pack will cause damage to the
product and could possibly explode, cause
a fire, or personal injury.
■ Do not disassemble the product.
■ If wrapped or in contact with fabrics, the
lens can produce sufficient heat to melt
some fabrics. To avoid serious personal
injury, never allow the lens to come in
contact with anything.
■ Do not place the product or battery pack
near fire or heat. This will reduce the risk
of explosion and possible injury.
■ Remove the battery pack or disconnect
the mains power before starting any work
on the product.
■ Do not store the product in a damp or
wet location, or in a location where the
temperature may reach or exceed 40°C.
For example, inside sheds, vehicles, or
metal buildings in the summer.
■ Do not direct the light beam at persons
or animals and do not stare into the light
beam yourself (not even from a distance).
Staring into the light beam may result in
serious injury or vision loss.
■ Use the magnets to mount the product on
22-gauge low carbon steel flat surface.
Minimum thickness: 0.6 mm.
LASER SAFETY WARNINGS
■ Laser radiation. Do not stare into beam.
Class 2 laser product.
■ Risk of severe eye injury if the laser beam is
directed at persons or animals. Avoid direct
eye exposure.
■ Do not direct the laser beam towards other
people.
■ Do not operate the product around children
or allow children to operate the laser.
■ Avoid using the product on reflective
surfaces. The laser beam may be reflected
at the operator or other persons.
■ Store the product indoors and avoid
substantial knocks, continuous vibration or
extreme temperatures.
■ Always keep the product away from dust,
liquids and high humidity. They may
damage internal components or affect
accuracy.
■ Do not remove or deface warning labels on
the product.
■ Do not disassemble the product.
■ Avoid heavy impact to or dropping of the
laser. The accuracy of the laser should be
checked before use if it has been dropped
or subjected to other mechanical stresses.
■ Do not operate the product in explosive
areas or in extreme environments.
BATTERY SAFETY WARNINGS
■ To reduce the risk of fire, personal injury,
and product damage due to a short circuit,
source
never immerse your tool, battery pack, or
charger in fluid or allow fluid to flow inside
them. Corrosive or conductive fluids, such
as seawater, certain industrial chemicals,
and bleach or bleach-containing products,
etc., can cause a short circuit.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local
and national provisions and regulations.
Follow all special requirements on packaging
and labelling when transporting batteries by a
third party. Ensure that no batteries can come
in contact with other batteries or conductive
materials while in transport by protecting
exposed connectors with insulating, non-
conductive caps or tape. Do not transport
batteries that are cracked or leaking. Check
with the forwarding company for further advice.
MAINTENANCE
■ Use only original accessories and spare
parts. Should components that have not
been described need to be replaced,
please contact an authorised service
centre. All repairs should be performed by
an authorised service centre.
■ Avoid using solvents when cleaning
plastic parts. Most plastics are susceptible
to various types of commercial solvents
and may be damaged by their use. Use
clean cloths to remove dirt, carbon dust,
etc.
■ Do not at any time let brake fluids,
gasoline, petroleum-based
penetrating oils, etc., come in contact with
plastic parts. Chemicals can damage,
weaken or destroy plastic which may
result in serious personal injury.
SYMBOLS
Direct current
Regulatory Compliance Mark
(RCM). Product meets applicable
regulatory requirements.
Please read the
carefully before starting
product.
Do not stare at the operating light
source.
Class III protection
Do not dispose of waste
batteries, waste electrical
and electronic equipment as
unsorted municipal waste. Waste
batteries and waste electrical
and electronic equipment must
be collected separately. Waste
batteries, waste accumulators,
and light sources have to be
removed from the equipment.
Check with your local authority
or retailer for recycling advice
and collection point. According
to local regulations, retailers
may have an obligation to
take back waste batteries and
waste electrical and electronic
equipment free of charge. Your
contribution to the reuse and
recycling of waste batteries and
waste electrical and electronic
equipment helps to reduce the
demand of raw materials. Waste
batteries, in particular containing
lithium, and waste electrical
and electronic equipment
contain valuable and recyclable
materials, which can adversely
impact the environment and the
human health if not disposed of
in an environmentally compatible
manner. Delete personal data
from waste equipment, if any.
SYMBOLS IN THIS MANUAL
Note
Parts or accessories sold
separately
LED lens
Laser output
Adjustable head
On/Off switch
Magnetic battery cap
Belt clip
USB charging cable
Battery
Operator's manual
USB power adaptor
products,
instructions
the
