Panduit ATLONA AT-OME-CS31-SA-C Installation Manual

AV Presentation
and Collaboration System
AT-OME-CS31-SA-C
The Atlona AT-OME-CS31-SA-C is an is an Omega™ Series AV presentation and collaboration
system featuring AV switching, USB routing, audio mixing, amplification, and control making
it ideal for modern classroom and meeting environments. The OME-CS31-SA-C supports
switching between one USB-C input and two HDMI inputs to a single HDMI output. Sources
connected to the inputs, such as laptops, computers, media players, and document cameras,
can be selected then routed to the output connected to a projector or display.
The system features a four port USB hub for connecting cameras, speakerphones, interactive
displays, and other devices as well the ability to switch them between two host devices. Making
OME-CS31-SA-C ideal for use with popular video conferencing and UC (unified communications)
platforms. The OME-CS31-SA-C offers three line level inputs for connecting a variety of audio
devices. Its onboard mixer supports individual level adjustments of the line inputs, de-embedded
HDMI audio, and USB audio. The integrated amplifier delivers either two channels of 25 watts or
a single channel of 50 watts into 4 or 8 ohms.
Package Contents
1 x AT-OME-CS31-SA-C
1 x Envelope of mating connectors for all captive-screw connectors
1 x Surface mount brackets
4 x rubber feet
1 x 24 V / 9.58 A power supply
1 x AC cord
1 x Insert w/ QR code
IMPORTANT: Visit https://www.atlona.com/product/at-ome-cs31-sa-c for the latest
firmware updates and User Manual.
