- Page 2 WARNING! Please read this manual before use the tool TOOLS SAFETY WARNINGS WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
- Page 3 c) Prevent unintentional starting. Ensure the switch is in the off-position connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents.
-
Page 4: Hazard: Hazardous Vapors
Additional instructions A high-pressure paint stream produced by this equipment can pierce the skin and underlying tissues, leading to serious injury and possible amputation. DO NOT TREAT AN INJECTION INJURY AS A SIMPLE CUT! See immediately a doctor. Injection can lead to amputation. See a doctor immediately. The maximum operating range of the gun is 22.7MPa fluid pressure. - Page 5 Avoid all ignition sources such as static electric sparks, open flames, pilot lights, electrical appliances, and hot objects. Connecting or disconnecting power cords or working light switches can make sparks. Paint or solvent flowing through the equipment is able to result in static electricity.
- Page 6 damage or movement of couplings. Immediately replace the hose if any of these conditions exist. Never repair a paint hose. Replace it with another grounded high- pressure hose. All hoses, fittings, and filter caps must be secured before operating spray pump. Unsecured parts may eject at great force or leak a high-pressure fluid stream causing severe injury.
- Page 7 Description and accessories NOZZLEX1 PAINT SPRAYER X1 LEFT LEG（L）X1 RIGHT LEG（R）X1Suction feeding tubeX1 NOZZLE SPRAY GUNX1 duckbill baseX1 HANDLEX1 8/10 spannerX1 extension rodX1 high-pressure tubeX1 hoopX1 M6 hex flange screwX4 O-ringX2 lubricating oil X1 17/19 spannerX1 19/22 spannerX1 Intended use Spray a variety of paints, oil base latex, primers, stains, preservatives and other nonabrasive materials, including pesticides and liquid fertilizers.
- Page 8 ASSEMBLY Do not plug in the sprayer until setup is complete. Step1 Step2 Step3 1、First,thread the 4pcs M6 hex flange screw 1、Insert the suction feeding tube into the 1、Use the hoop to fix the tube. through the hole on the left and right leg. sprayer.
- Page 9 Locking the Spray Gun: Always lock the trigger off when attaching the spray tip or when the spray gun is not in use. Spray Gun The gun is locked when the trigger lock is at a 90º angle. (perpendicular to the trigger in either direction).
- Page 10 Pressure Relief Procedure Be sure to follow the Pressure Relief Procedure when shutting the unit off FOR ANY PURPOSE. This procedure is used to relieve pressure from the spray hose. 3. Unlock the spray gun and 2. Turn the PRIME/SPRAY 1.
- Page 11 3. Plug in the sprayer and move the ON/OFF 4. Switch the pump OFF (O). Remove the switch to the ON (l) position. return tube from the waste container and place it in its operating position above the container of spraying material. Use the metal The unit will begin to draw material up the suction tube, into the pump, and out the...
- Page 12 3. While pulling the trigger, switch the pump ON (l), AND turn the PRIME/SPRAY knob to SPRAY. Hold the trigger until all air, water, or solvent is purged from the spray hose and material is flowing freely. If the PRIME/SPRAY knob is still on SPRAY, there will be high pressure in the hose and spray gun until the PRIME/SPRAY knob is turned to PRIME.
- Page 13 NOTE - Be sure that the paint hose is free of kinks and clear of objects with sharp cutting edges. 1. Switch the pump ON (l). Turn the 2. When motor shuts off, unlock the spray PRIME/SPRAY knob to SPRAY. Turn the gun and spray a test area to check the spray pressure control dial to maximum pressure pattern.
- Page 14 The key to a good job is an even coating over the entire surface. This is done by using even strokes. Follow the TIPS, below. Tip: Keep the spray gun at right angles to the surface. This means moving your entire arm back and forth rather than just flexing your wrist.
- Page 15 Spraying Troubleshooting - Unclogging the Spray Tip If the spray pattern becomes distorted or stops completely while the gun is triggered, follow these steps. Do not attempt to unclog or clean the tip with your finger. NOTE - Do not use a needle or other sharp pointed instrument to clean the tip. The hard tungsten carbide can chip.
- Page 16 Spraying Troubleshooting - Cleaning the Spray Gun Filter The filter must be cleaned every time you use your sprayer. When using thicker spray materials, the filter might need to be cleaned more often. 1. Perform Pressure Relief Procedure 2a. 1 - Unscrew the fitting from the bottom of the spray gun using an adjustable wrench, making sure not to lose the spring.
- Page 17 If after completing all of the steps in Spraying Troubleshooting you are still experiencing problems spraying, refer to the Troubleshooting section. Important Cleaning Notes - Read before cleanup When using latex materials, clean your sprayer and components with water. When using oil-based materials, use mineral spirits.
- Page 18 1. Lock the gun and remove the 2. Using a garden hose, rinse off the suction spray tip assembly. Place the tube, return tube and inlet filter. Empty the suction tube and return tube into waste container. an empty waste container. Empty waste container 3.
- Page 19 While pulling the trigger, turn the Place the original material container next to PRIME/SPRAY knob to SPRAY to the waste container. Aim the spray gun into purge material from the hose the side of the original material container back into the original container. and hold the trigger.
- Page 20 Bucket with cleaning solution ⚫ 3. While pulling the gun trigger, turn the Hold trigger ⚫ pump ON (l), and turn the PRIME/ Turn pump ON(I) ⚫ SPRAY knob to SPRAY to purge Turn PRIME/SPRAY knob to material from the hose back into the SPRAY original container.
- Page 21 When suction set is clean, thread the suction Submerge the suction set tube back into the inlet valve, and replace into a bucket of NEW the return tube onto the return tube fitting. cleaning solution. Replace clip. Turn the PRIME/SPRAY knob to PRIME. Let the pump circulate cleaning solution Turn the pump ON (l), and trigger the gun through the suction set for 2-3 minutes.
- Page 22 Cleanup - Cleaning the Spray Gun Components 1. Make sure the pump is switched OFF .Remove spray gun from the paint hose (O). Make sure the PRIME/SPRAY using adjustable wrenches. knob is turned to PRIME. Unplug the sprayer. 3. Remove filter from spray gun (refer to 4.
- Page 23 7. Thread the spray gun back onto the paint hose. Tighten with a wrench. Short-Term Storage (up to 16 hours) Follow these steps when using latex materials only. If using materials that are oil-based, follow the Cleanup and Long- Term Storage steps. Shutdown 1.
- Page 24 Startup 1. Remove the gun from the plastic bag. Stir 2. Turn the PRIME/SPRAY knob to PRIME. the water into the paint. Plug sprayer in. Turn the switch to ON (I). 3. Turn the PRIME/SPRAY knob to SPRAY. Test the sprayer on a practice piece and begin spraying.
- Page 25 Cleaning the Inlet Valve Cleaning or servicing the inlet valve may be required if the unit has priming problems. Priming problems may be prevented by properly cleaning the sprayer and following the Long-Term Storage steps. Wipe the entire unit, hose and gun with a damp cloth to remove accumulated paint. Replace the high pressure hose to the paint hose port.
- Page 26 1. Remove the suction set. 2. Unscrew the inlet valve assembly (a) from the sprayer. Visually inspect the inside and outside of the inlet valve assembly. Clean any paint residue with the appropriate cleaning solution.
- Page 27 3. Lubricate the O-ring on the inlet valve 4. Replace suction set and hand-tighten. (b). Replace inlet valve assembly by screwing it into the sprayer. Torque to 23-27 ft lbs. If priming problems persist, you may need to replace the inlet valve assembly.
- Page 28 5. Unscrew and remove the inlet valve assembly. 6. Remove the piston assembly by pushing down on the piston near the yoke. 7. Unscrew and remove the top nut using and adjustable wrench. 8. Remove the worn seals using a flat head screwdriver or punch. Remove the top seal from the top and the bottom seal from the bottom by pressing against the side of the seal and popping it out.
- Page 29 Locating sleeve Lathe dog O-ring Steel ball Valve body Troubleshooting / Maintenance Problem Cause Solution 1. Plug the sprayer in. 1. The sprayer is not A. The sprayer does not plugged in. 2. Turn the ON/OFF switch to 2. The ON/OFF switch is start.
- Page 30 1. Refill the bucket or The paint bucket is B. The sprayer starts but immerse the suction tube in empty or the suction paint. tube is not totally does not draw in paint immersed in the paint. Clean the suction set. The suction set is when the PRIME/SPRAY Clean the tube connection...
- Page 31 Extended Maintenance Some pump parts eventually wear out from use and must be replaced. The following list indicates the available repair kits for the parts replaced by each kit. However, pump performance is the only reliable indicator of when to replace wear parts. Refer to the Troubleshooting section for more information on when to use these kits.
- Page 32 Technical specifications 230-240V˜ 50Hz Voltage and frequency 800W (max.1010W) Power Flow rate 1.5 L/min Maximum pressure 22.7MPa Net Weight 7.2 kg Temperature Min.10°C/ Max 40°C Guaranteed sound power level 110dB(A) DISPOSAL Electrical products should not be discarded with household products. According to the European Directive 2012/19/EU on waste electrical and electronic equipment and its implementation into national law, electrical products used must be collected separately and disposed of at collection points provided for this purpose.
- Page 33 32, rue Aristide Bergès –Z1 31270 Cugnaux – France Tel: +33 (0)5.34.508.508 Fax: +33 (0)5.34.508.509 Declare that the machine AIRLESS PAINT SPAYER Model HSP800 S/N: Is in conformity with the directive « machine » 2006/42/CE And also with the following directive:...
