  • Page 1 ThinkPad P14s Gen 5 and ThinkPad P16s Gen Hardware Maintenance Manual...
  • Page 2 First Edition (May 2024) © Copyright Lenovo 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...

  • Page 3: Table Of Contents

    Reset or restore Windows ... Reading or writing the ECA information ..Use Lenovo recovery options..Use Window recovery options ..
  • Page 4 Appendix A. Notices ..103 I/O board of ThinkPad P14s Gen 5 ..I/O board of ThinkPad P16s Gen 3 ..

  • Page 5: About This Manual

    About this manual This manual contains service and reference information for the following products: Product name Machine type (MT) ThinkPad P14s Gen 5 21G2 and 21G3 ThinkPad P16s Gen 3 21KS and 21KT Use this manual along with the advanced diagnostic tests to troubleshoot problems.
  • Page 6 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    • Fan louvers on the machine help to prevent overheating of internal components. Do not obstruct fan louvers or cover them with labels or stickers. Electrical safety Observe the following rules when working on electrical equipment. © Copyright Lenovo 2024...
  • Page 8 This practice ensures correct grounding of the units. • If an electrical accident occurs: – Use caution; do not become a victim yourself. – Switch off power. – Send another person to get medical aid. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 9: Safety Inspection Guide

    4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-ThinkPad / non-Lenovo alterations. Use good judgment as to the safety of any non-ThinkPad / non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 10: Grounding Requirements

    The safety notices in this section are provided in the following languages: • English • Arabic • Brazilian Portuguese • French • German • Hebrew • Japanese • Korean • Spanish • Traditional Chinese DANGER DANGER ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 11 DANGER DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO PERIGO PERIGO DANGER DANGER ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 15 DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 16 DANGER VORSICHT VORSICHT VORSICHT VORSICHT ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 25: Chapter 2. Important Service Information

    – “FRU identification” on page 20 Important: • Advise customers to contact the Lenovo Customer Support Center if they need any assistance in obtaining or installing any software fixes, drivers, and UEFI BIOS downloads. Telephone numbers for Lenovo Support are available at: https://pcsupport.lenovo.com/supportphonelist...

  • Page 26: How To Use Error Message

    Dynamic Configure To Order (CTO) model This model provides the ability for a customer to configure a Lenovo solution from a Web Site, and have this configuration sent to fulfillment, where it is built and shipped directly to the customer. The machine label and eSupport will load these products as the 4-character MT, 4-character model, and 2-character country code.

  • Page 27: Chapter 3. General Checkout

    Before checking problems with the computer, determine whether the damage is covered under the warranty by referring to the following list: © Copyright Lenovo 2024...

  • Page 28: Checkout Guide

    Note: If you are unable to isolate and repair the problem yourself after running the program, save and print the log files created by the program. You need the log files when you speak to a Lenovo technical support representative.

  • Page 29: Quick Test Programs

    The following table displays the main items of the UEFI diagnostic program. Depending on the model, the items might differ slightly. Table 1. Items on the main screen of the UEFI diagnostic program for ThinkPad P14s Gen 5 Tests Tools •...

  • Page 30: Bootable Diagnostic Programs

    25, and check the power sources. If an error code is displayed, go to “Symptom-to-FRU index” on page 31 for error code descriptions and troubleshooting hints. Step 2. Insert the disc into the optical drive. Step 3. Restart the computer. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 31: Power System Checkout

    Checking the built-in battery and operational charging This system supports only batteries specially designed for this specific system and manufactured by Lenovo or an authorized manufacturer. The system does not support unauthorized batteries or batteries designed for other systems.

  • Page 32: Checking The Coin-Cell Battery

    Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no warranties for failures or damage arising out of their use. Move your pointer to the battery-status icon in the Windows notification area to check the battery status. The battery-status icon displays the percentage of battery power remaining and how long you can use your computer before you must charge the battery.

  • Page 33: Chapter 4. Related Service Information

    When the latest maintenance diskette and the system program service diskette become available, they will be posted on: https://support.lenovo.com Reset or restore Windows To reset or restore Windows, refer to the information below： Use Lenovo recovery options Step 1. Go to https://support.lenovo.com/HowToCreateLenovoRecovery Step 2.

  • Page 34: Power-On Password

    The system management password can also protect the system information stored in UEFI BIOS like a supervisor password, but it has lower authority by default. The system management password can be set through the UEFI BIOS menu or through Windows Management Instrumentation (WMI) with the Lenovo client-management interface.

  • Page 35: How To Remove The Power-On Password

    Lenovo cannot reset your passwords or recover data from the storage drive. You can contact a Lenovo authorized service provider to have the storage drive replaced. A fee will be charged for parts and service. If the storage drive is a CRU (Customer Replaceable Unit), you can also contact Lenovo to purchase...

  • Page 36: How To Remove The System Management Password

    Disable the built-in battery. See “Disabling the built-in battery” on page 67. Step 3. Remove the base cover assembly. See “Base cover assembly of ThinkPad P14s Gen 5” on page Step 4. Remove the built-in battery. See “Built-in battery” on page 75.

  • Page 37: Hibernation Mode

    • After a period of inactivity specified in power plan settings • When the battery power is low To resume the computer from sleep mode, press the power button. Also, in either of the following events, the computer automatically returns from sleep mode and resumes operation: •...

  • Page 38: Numeric Error Codes

    Remove all but the reader that you set up for the More than one external fingerprint reader is attached. authentication. Power off and remove all but the reader that you set up within your main operating system. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 39: Error Messages

    The battery installed is not supported by this system and Replace the battery. will not charge. Please replace the battery with the correct Lenovo battery for this system. Press the Esc key to continue. This system does not support batteries that are not Replace the battery.
  • Page 40 • We recommend that you speak to our Customer Support Center before attempting to service the computer yourself so that you can be directed to the correct documentation and repair information. It might be recommended to have a Lenovo-authorized service provider repair your computer depending on the complexity of the error or fault.

  • Page 41: No-Beep Symptoms

    Blinking patterns Error codes Solutions 0283: PCI resource error 1. Remove PCIe devices (the M.2 card, PCIe card, and so on) (service provider only). 2. If step 1 does not work, replace the system board (service provider only). 0284: TCG-compliant functionality-related Replace the system board (service provider error (might be the BIOS code validation only).

  • Page 42: Lcd-Related Symptoms

    If the LCD you are servicing has two or less visible defective pixels, it should not be considered faulty. However, if the LCD has three or more visible defective pixels, it will be deemed as defective by Lenovo and it should be replaced.

  • Page 43: Intermittent Problems

    Step 1. Ensure that the computer is connected to ac power. Then, press the power button for about seven seconds to turn off the computer. Step 2. Press Fn, left Ctrl, and the power button at the same time. If the computer displays five solid colors in sequence across the entire screen, it indicates that the LCD functions normally.
  • Page 44 If the problem does not recur, reconnect the removed devices one at a time until you find the failing FRU. Step 7. If the problem remains, replace the following FRUs one at a time (do not replace a nondefective FRU): System board LCD assembly ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 45: Chapter 5. Use The Keyboard Shortcuts

    Open the context menu of the current active app. Fn + Open the Calculator (for ThinkPad P16s Gen 3). Fn + Put the computer to sleep (for ThinkPad P16s Gen 3). Fn + Adjust the keyboard backlight. Fn + Go to beginning. Fn + © Copyright Lenovo 2024...
  • Page 46 Fn + K Scroll contents. Fn + P Pause operation. Fn + S Send system request. Fn + N Open system information Window. For more keyboard shortcuts, go to https://support.lenovo.com/us/en/solutions/windows-support ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 47: Chapter 6. Locations

    Chapter 6. Locations Locating computer controls and connectors Front view Have a quick glance at the front view of your computer. ThinkPad P14s Gen 5 © Copyright Lenovo 2024...
  • Page 48 TrackPoint Three Buttons * for selected models Webcam privacy shutter Slide the webcam privacy shutter to cover or uncover the camera lens. It is designed to protect your privacy. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 49 Chapter 6 Locations...

  • Page 50: Side View

    Ethernet connector USB-A connector (USB 5Gbps) Smart-card slot* USB-A connector (USB 5Gbps, Always Audio connector On USB) ® USB-C power connector HDMI™ connector (Thunderbolt™ 4) * for selected models ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 51 ThinkPad P16s Gen 3 Description Description Item Item Security—lock slot Ethernet connector USB-A connector (USB 5Gbps) Nano-SIM-card tray* Smart-card slot* Audio connector USB-A connector (USB 5Gbps, Always USB-C power connector (Thunderbolt 4) On USB) HDMI connector * for selected models Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer...
  • Page 52 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 53: Bottom View

    Bottom view Have a quick glance at the bottom part of your computer. ThinkPad P14s Gen 5 ThinkPad P16s Gen 3 Description Description Item Item Emergency-reset hole Speaker Chapter 6 Locations...
  • Page 54 2. Insert a straightened paper clip into the hole to cut off power supply temporarily. 3. Connect your computer to ac power and then turn on your computer. Note: If your computer is still no response, you can call Lenovo Customer Support Center to get further help.

  • Page 55: Locating Frus And Crus

    Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You can find a list of CRUs for your product in this Hardware Maintenance Manual. An electronic version of this manual can be found at .

  • Page 56: Major Frus And Crus

    Major FRUs and CRUs ThinkPad P14s Gen 5 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 57 Notes: • Depending on the computer model, your computer might look different from the illustration above. • The Lenovo factory recovery USB key is used to restore the Microsoft Windows operating system. It might not come with the computer, and a user might order it from https://pcsupport.lenovo.com/...
  • Page 58 ThinkPad P16s Gen 3 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 59 Power button with fingerprint reader bracket Smart-card reader* Smart-card-reader cable* Dummy smart card reader* Nano-SIM-card tray* Power cord ac power adapter Miscellaneous parts kits (see “Miscellaneous parts” on page 57) Lenovo factory recovery USB key* * for selected models Chapter 6 Locations...

  • Page 60: Lcd Frus And Crus

    ThinkPad P14s Gen 5 Table 8. LCD FRUs and CRUs FRU description Self-service Optional-service LCD bezel LCD panel LCD panel with X-rite* Microphone rubbers Camera-and-microphone module Camera-and-lid cable LCD cover assembly ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 61 Table 8. LCD FRUs and CRUs (continued) FRU description Self-service Optional-service LCD hinges LCD cable Wireless LAN antenna assembly Elastic adhesive tapes * for selected models Note: Depending on the computer model, your computer might look different from the illustration above. ThinkPad P16s Gen 3 Table 9.
  • Page 62 Wireless LAN antenna assembly LCD cable Elastic adhesive tapes * for selected models Note: Depending on the computer model, your computer might look different from the illustration above. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 63: Miscellaneous Parts

    Table 10. Miscellaneous part FRU descriptions Self-service Optional-service Screw kit • For ThinkPad P14s Gen 5: – M1.6 x L1.7, black (13) – M1.6 x L2.5, black (2) – M2.0 x L3.0, black (2) – M2.0 x L3.0, silver (1) –...

  • Page 64: Connector And Cable Guide

    * for selected models Connector and cable guide This topic provides information to help Lenovo authorized service technicians identify connectors and cables for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major FRUs and CRUs” on page 50 and “LCD FRUs and CRUs” on page 54.
  • Page 65 Table 11. System board connector and cable guide (continued) Internal cable required Connector/feature Cable connection LCD connector (internal) LCD cable Connect one end to the LCD panel and the other end to this connector. HDMI connector (external) Connect a compatible digital audio device or video monitor to this connector.

  • Page 66: Looking Up Fru Information

    Connect one end to the system board and the other end to this connector. Looking up FRU information For detailed FRU information, including part numbers, descriptions, and substitution part numbers, go to: https://support.lenovo.com/partslookup ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 67: Chapter 7. Fru Replacement Notices

    • Keep the screw kit in your tool bag. For the part number of the screw kit, go to: https://support.lenovo.com/partslookup Tighten screws as follows: • Plastic to plastic Turn an additional angle of 90 degrees after the screw head touches the surface of the plastic part. © Copyright Lenovo 2024...

  • Page 68: Sensor Calibration

    Step 1. Download the Windows Sensor Calibration Tool by following steps: Note: This Sensor Calibration Tool is limited to Lenovo service providers. You can contact a Lenovo authorized service provider to have your system board or LCD unit replaced. Go to https://support.lenovo.com...

  • Page 69: Retaining Serial Numbers

    Connect a USB memory key to the computer. Step 2. Go to https://www.lenovo.com/maintenanceutilities and follow the instructions on the screen to create a Maintenance Key. Note: Only an authorized Lenovo service technician can access the above Web site. Chapter 7 FRU replacement notices...

  • Page 70: Retaining The Uuid

    Go to and follow the instructions on the screen to https://www.lenovo.com/maintenanceutilities create a Maintenance Key. Note: Only an authorized Lenovo service technician can access the above Web site. Step 3. Restart the computer. Step 4. When the logo screen is displayed, press Esc. The ThinkPad Config Information Update Utility interface is displayed.

  • Page 71: Reading Or Writing The Eca Information

    To check what ECAs have been previously applied to the machine, use the ECA Information Read/Write function on the LENOVO ThinkPad Hardware Maintenance Diskette or Maintenance Key. Step 1. Insert the latest version of LENOVO ThinkPad Hardware Maintenance Diskette or Maintenance Key, and then restart the computer. Step 2.
  • Page 72 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 73: Chapter 8. Removing Or Replacing A Fru

    Click Power Options, and then click Choose what the power buttons do on the left pane. Step 3. Click Change settings that are currently unavailable at the top. Step 4. If prompted by User Account Control (UAC), click Yes. © Copyright Lenovo 2024...

  • Page 74: Removing The Nano-Sim Card And Nano-Sim-Card Tray (For Selected Thinkpad P16S Gen 3 Models)

    1. Disable the built-in battery. See “Disabling the built-in battery” on page 67. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. 3. Close the computer display and turn over the computer. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 75: Applying Labels To The Base Cover Assembly

    Step 1. Remove the assembly as shown below. Note: Prepare a pry tool to release the hooks. Step 2. Install the assembly as shown below. If the computer does not start up after you reinstall the base cover assembly, disconnect the ac power adapter and then reconnect it to the computer.

  • Page 76: Base Cover Assembly Of Thinkpad P16S Gen 3

    2. Turn off the computer and disconnect the computer from ac power and all connected cables. 3. Close the computer display and turn over the computer. Step 1. Remove the assembly as shown below. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 77: Applying Labels To The Base Cover Assembly

    Note: Prepare a pry tool to release the hooks. Step 2. Install the assembly as shown below. If the computer does not start up after you reinstall the base cover assembly, disconnect the ac power adapter and then reconnect it to the computer. Applying labels to the base cover assembly Notes: •...

  • Page 78: Solid-State Drive And Its Bracket (For Selected Models)

    3. Close the computer display and turn over the computer. 4. Remove the base cover assembly. See “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or see “Base cover assembly of ThinkPad P16s Gen 3” on page 70.

  • Page 79: Wireless Wan Card (For Thinkpad P16S Gen 3 Selected Models)

    The following information is only for the computer with user-installable modules. Ensure that you use only a Lenovo-authorized wireless module specifically tested for this computer model. Otherwise, the computer will generate an error-code beep sequence when you turn on the computer.

  • Page 80: Memory Module

    3. Close the computer display and turn over the computer. 4. Remove the base cover assembly. See “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or see “Base cover assembly of ThinkPad P16s Gen 3” on page 70.

  • Page 81: Built-In Battery

    Built-in battery DANGER Use only the Lenovo authorized battery specified for the computer. Any other battery could ignite or explode. Important notice for replacing a battery Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no warranties for failures or damage arising out of their use.
  • Page 82 For access, remove this FRU: “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70.

  • Page 83: Battery Frame (For Thinkpad P16S Gen 3 Only)

    • Ensure that the base cover assembly is secured in place. Otherwise, the battery connection may fail. Battery frame (for ThinkPad P16s Gen 3 only) For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P16s Gen 3” on page 70 •...

  • Page 84: Thermal Assembly

    Thermal assembly For access, remove this FRU: “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70. Step 1. Remove the thermal assembly as shown below. Step 2.

  • Page 85: Thermal Fan Kits

    Thermal fan kits For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “Thermal assembly” on page 78 Step 1.

  • Page 86: I/O Bracket (On System Board)

    I/O bracket (on system board) For access, remove this FRU: “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70. Step 1. Remove the I/O bracket as shown below.

  • Page 87: Speaker Assembly Of Thinkpad P16S Gen 3

    Use only the Lenovo authorized battery specified for the computer. Any other battery could ignite or explode. For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “Built-in battery” on page 75 Step 1.

  • Page 88: Wireless Wan Antennas (For Thinkpad P16S Gen 3 Only)

    • “Built-in battery” on page 75 • “Battery frame (for ThinkPad P16s Gen 3 only)” on page 77 Step 1. Remove the wireless WAN antennas as shown below. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 89: I/O Board Cable

    When installing: Ensure that the connectors are attached firmly. I/O board cable For access, remove this FRU: “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70.
  • Page 90 • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 • “Thermal fan kits” on page 79 • “I/O board cable” on page 83 Step 1. Remove the I/O board as shown below. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 91: I/O Board Of Thinkpad P16S Gen 3

    Step Screw (quantity) Color Torque Black 0.2 Nm M2.0 × 4.0 mm, flat head, nylon-coated (2) (2.04 kgf-cm) Black 0.2 Nm M2.0 × 3.0 mm, flat head, nylon-coated (1) (2.04 kgf-cm) Step 2. Install the I/O board in reverse order. I/O board of ThinkPad P16s Gen 3 For access, remove these FRUs in order: •...
  • Page 92 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 93: System Board

    Torque Step Screw (quantity) Color M2.0 × 3.0 mm, flat head, nylon-coated (2) Black 0.2 Nm (2.04 kgf-cm) M2.5 × 3.5 mm, flat head, nylon-coated (3) Black 0.2 Nm (2.04 kgf-cm) M2.0 × 3.0 mm, flat head, nylon-coated (2) Black 0.2 Nm (2.04 kgf-cm) Step 2.

  • Page 94: Replace The System Board

    • “Removing the nano-SIM card and nano-SIM-card tray (for selected ThinkPad P16s Gen 3 models)” on page 68 • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 •...
  • Page 95 Torque Step Screw (quantity) Color M2.0 × 3.0 mm, flat head, nylon-coated (1) Black 0.181 Nm (1.85 kgf-cm) M2.0 × 5.0 mm, flat head, nylon-coated (2) Black 0.181 Nm (1.85 kgf-cm) Step 2. Install the system board in reverse order. Notes: •...

  • Page 96: Trackpad And Trackpad Cable

    Trackpad and Trackpad cable For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “Built-in battery” on page 75 •...

  • Page 97: Smart Card Reader (For Selected Models)

    Smart card reader (for selected models) For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “Built-in battery” on page 75 •...

  • Page 98: Dummy Smart Card Reader (For Selected Thinkpad P16S Gen 3 Models)

    Dummy smart card reader (for selected ThinkPad P16s Gen 3 models) For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 •...

  • Page 99: Power Button With Fingerprint Reader

    Power button with fingerprint reader For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “Thermal fan kits” on page 79 •...

  • Page 100: Lcd Unit

    For details, see “How to install new color profiles for LCD panel with the factory color calibration feature” on page 98. For access, remove this FRU: “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70.
  • Page 101 Chapter 8 Removing or replacing a FRU...

  • Page 102: Keyboard Assembly

    • “Removing the nano-SIM card and nano-SIM-card tray (for selected ThinkPad P16s Gen 3 models)” on page 68 • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 •...

  • Page 103: Lcd Bezel

    • “LCD unit” on page 94 LCD bezel For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “LCD unit” on page 94 Step 1.

  • Page 104: How To Install New Color Profiles For Lcd Panel With The Factory Color Calibration Feature

    How to install new color profiles for LCD panel with the factory color calibration feature Follow the instructions to install new color profiles for LCD panel with the factory color calibration feature. ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...

  • Page 105: Lcd Hinges

    LCD hinges For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “LCD unit” on page 94 •...

  • Page 106: Camera-And-Microphone Module

    Install the LCD hinges in reverse order. Camera-and-microphone module For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “LCD unit” on page 94 •...

  • Page 107: Microphone Rubbers

    Install the camera-and-lid cable in reverse order. Microphone rubbers For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “LCD unit” on page 94 •...

  • Page 108: Lcd Cover Assembly

    LCD cover assembly For access, remove these FRUs in order: • “Base cover assembly of ThinkPad P14s Gen 5” on page 68 or “Base cover assembly of ThinkPad P16s Gen 3” on page 70 • “LCD unit” on page 94 •...

  • Page 109: Appendix A. Notices

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
  • Page 110 Trademarks Lenovo, Lenovo logo, ThinkPad, ThinkPad logo, TrackPoint, and UltraConnect are trademarks of Lenovo. Intel, Intel Optane, and Thunderbolt are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Linux is the registered trademark of Linus Torvalds in the U.S. and other countries.

  • Page 111: Appendix B. Abbreviation Table

    Electrically Erasable Programmable Read-Only Memory Extensible Firmware Interface Electrostatic discharge Field Replaceable Unit General Announce Variant Integrated circuits Liquid Crystal Display Machine type and model POST Power-on self-test RFID Radio-frequency identification Supervisor password UUID Universally unique identifier © Copyright Lenovo 2024...
  • Page 112 ThinkPad P14s Gen 5 and ThinkPad P16s Gen 3 Hardware Maintenance Manual...
  • Page 114 Part Number: SP41L93331 Printed in China (1P) P/N: SP41L93331 *1PSP41L93331*...

This manual is also suitable for:

Thinkpad p16s gen 3

Table of Contents

Save PDF
