ASROCK 785GM-S3 Specifications

785GM-S3
AMD 785G + SB710 Chipsets
Product Brief
- Phenom II X6 6-Core CPU Ready
- Support ASRock UCC - Unlock CPU Core
- Support Dual Channel DDR3 1800(OC)
- Integrated AMD Radeon HD 4200 graphics,
DX10.1 class iGPU, Shader Model 4.1
TM
- Support ATI Hybrid CrossFireX
- Support ASRock Instant Boot, Instant Flash,
OC Tuner, IES, OC DNA, AIWI, APP Charger,
SmartView
- Free Software : CyberLink DVD Suite - OEM
and Trial; Creative Sound Blaster X-Fi MB - Trial
- ErP/EuP Ready
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.

Detail Specification

Platform
CPU
Chipset
Memory
Expansion Slot
Graphics
Audio
LAN
Rear Panel I/O
Connector
BIOS Feature
Support CD
Unique Feature
TM
Hardware Monitor
OS
Certifications
Accessories
w w w. a s ro ck . c o m
- Micro ATX Form Factor: 9.6-in x 7.2-in, 24.4 cm x 18.3 cm
- Support for Socket AM3 processors: AMD Phenom
(except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors
- Six-Core CPU Ready
- Support ASRock UCC - Unlock CPU Core
- AMD LIVE! TM Ready
- Support AMD's Cool 'n' Quiet Technology
- FSB 2600 MHz (5.2 GT/s)
- Support Untied Overclocking Technology
- Support Hyper-Transport 3.0 (HT 3.0) Technology
- Northbridge: AMD 785G
- Southbridge: AMD SB710
- Dual Channel DDR3 memory technology
- 2 x DDR3 DIMM slots
- Support DDR3 1800(OC)/1600(OC)/1333/1066/800 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express 2.0 x16 slot (blue @ x16 mode)
- 1 x PCI Express 2.0 x1 slot
- 2 x PCI slots
- Support ATI TM Hybrid CrossFireX TM
- Integrated AMD Radeon HD 4200 graphics
- DX10.1 class iGPU, Shader Model 4.1
- Max. shared memory 512MB
- Support D-Sub with max. resolution up to 2048x1536 @ 60Hz
- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
- Realtek PCIEx1 LAN 8105EL
- Speed: 10/100 Ethernet
- Support Wake-On-LAN
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
- 4 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1
RAID 10 and JBOD), NCQ, AHCI and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x Print port header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 8Mb AMI Legal BIOS
- Support "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Support jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM, NB Voltage Multi-adjustment
- Drivers, Utilities, AntiVirus Software (Trial Version), AMD OverDrive
ASRock Software Suite (CyberLink DVD Suite - OEM and Trial; Creative
Sound Blaster X-Fi MB - Trial)
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- ASRock AIWI
- ASRock APP Charger
- SmartView
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
- Microsoft ® Windows ® 7 / 7 64-bit / Vista TM / Vista
Center / XP 64-bit compliant
- FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA data cables (optional)
TM II X6 / X4 / X3 / X2
TM
Utility,
TM 64-bit / XP / XP Media
