OBHWA - T1000 INSTALLATION INSTRUCTIONS

TOOLS REQUIRED:

• 10MM SOCKET WRENCH OR NUT DRIVER

• TWO (2) AA BATTERIES

Rev. 9/27/23

sales@ozliftingproducts.com • P.O. Box 845, Winona, MN 55987 • Tech Support (507) 457-3346

General guidelines for installation of the OBHWA-T1000

Wireless Adapter to an OBH1000 OZ Electric Builder's Hoist.

STEP 1

Before you begin, check to ensure all components

are included. Contact OZ Lifting Products to report

missing parts.

• Receiver

• Mounting bracket with bolt and cotter pin

• 10mm hex head bolt

• Washer

• Wireless remote

NOTE: Batteries not included.

STEP 2

Mount the bracket to the receiver as shown.

Do not over-tighten the 10mm hex head bolt as it may

damage the housing.

Pg. 1

ozliftingproducts.com

Need help?

Do you have a question about the OBHWA-T1000 and is the answer not in the manual?

Page 1 OBHWA - T1000 INSTALLATION INSTRUCTIONS TOOLS REQUIRED: General guidelines for installation of the OBHWA-T1000 • 10MM SOCKET WRENCH OR NUT DRIVER Wireless Adapter to an OBH1000 OZ Electric Builder’s Hoist. • TWO (2) AA BATTERIES STEP 1 Before you begin, check to ensure all components are included.
Page 2 STEP 3 Remove the cotter pin and nut from the mounting bolt. Ensure that the bracket arms of the receiver are on the outside of the bracket on the hoist itself. Insert the mounting bolt, reinstall the nut and cotter pin as shown below.
Page 3 Your OZ Electric Builder’s Hoist Wireless Adapter is now ready to use. Please follow the instructions in the operator’s manual for further details. If you have any questions, please contact OZ Lifting Products. Rev. 9/27/23 Pg. 3 sales@ozliftingproducts.com • P.O. Box 845, Winona, MN 55987 • Tech Support (507) 457-3346...
