- Page 1 RYK VECTOR WAVE SYNTH VOICE USER MANUAL V1.24 FIRMWARE...
- Page 2 TOP ROW KNOBS BOTTOM ROW KNOBS VECTOR MODE / ENVELOPES / QUICK CONTROLS / LFOS SETTING MENUS VECTOR ENV/LFO /Q/MENU MODULATION SLOTS OSCILLATOR BANKS / OSCILLATOR MENUS VECTOR JOYSTICK V/OCT OUT L OUT R CV MODULATION MIDI IN INPUTS...
- Page 3 When using VECT1/2 mode, the joystick position controls the mix between the four Banks A,B,C,D. The Vector Wave is a FM & Harmonic synthesiser voice, with four bank The joystick position Vectors can be stored, and then animated or vector synthesis or true four voice polyphony with in built Envelopes triggered from modulation sources for complex repeatable timbre and LFO modulation sources.
- Page 4 OSCILATOR BANKS JOYSTICK M1 M2 VECTOR M3 M4 ANIMATION MIDI VECTOR WAVE - STRUCTURE OVERVIEW...
- Page 5 Quick Controls Performance Page [ XM,WP,FD,DT ]. stored voice from numbers 1-30. [ the Vector Wave ships with a selection of ready stored voices ] XM – Adjust the amount of FM cross modulation [ if being used ] Rotate the bottom right knob to select and preview a Voice Preset, WP –...
- Page 6 OSCILLATOR BANKS Pushing the Red button accesses the Oscillator A B C D Bank mode. Repeated pushes cycle between each bank, A,B,C,D. FINE TUNE MODE LEVELS MODE Each bank has 4 oscillators. Each oscillator has a column of top and bottom knobs, to control the parameters. The Oscillator Display has four pages, depending on which controls are Pushing any of the bottom row knobs will enable the FM algorithm being used:...
-
Page 7: Menu Function
Example1 OSCILLATOR MENU HOLD Oscillator 1&2 are combined in parallel to modulate oscillator 3. Oscillator 4 is not modulated. Pushing and holding the Red Oscillator button for a few seconds will activate the Oscillator Menu, A B C D pushing the button again for a few seconds will exit the Oscillator Menu. - Page 8 INIT - Resets all banks. HARMONIC VIEW CPY TO - Copy the currently selected bank, indicated by the ABCD Pushing and holding any of the top row knobs for a few seconds will Bank LEDs, to the destination bank[s] activate the Harmonic View, pushing again for a few seconds will exit the view.
- Page 9 There are two ADSR type envelopes, ENV1 controls the amplitude of There are two LFOs. They can be used to add movement to a sound by the Vector Wave voice outputs, ENV2 controls the XM [ cross modula- modulating a destination attribute of an Oscillator Bank, such as amplitude [AM].
- Page 10 MODULATION SLOTS Use the bottom row knobs to select the modulation source, destina- tion, and destination suffix. Pushing the Mod button accesses the Use the top row knobs to select the modulation amount [ Attenuverter ], Modulation Slots. Repeated pushes will cycle and modulation offset.
- Page 11 Modulation Sources: VEC – Vector animation position from a modulator. Or Trigger M1,M2,M3,M4 – External CV sources from M1,M2,M3 or M4 playback from Gate or M1[T] input, JYX, JYY - Joystick X or Y position EV1/EV2 - Envelope1 or Envelope2 LF1,LF2 - LFO1 or LFO2 LF1,LF2 - LFO1 or LFO2 AM –...
- Page 12 There are two types of VECTOR animation, VEC1 allows the Joystick destination 'VEC' in a modulation slot, and select GATE or M1T as a movement to be recorded over time, VEC2 allows you to store four trigger source. Joystick vector positions, which are used to recreate a vector The speed is set by the bottom right knob on the Vector page.
- Page 13 Move the Joystick to a desired mix position, and push one of the 'Q' QUICK CONTROLS PERFORMANCE PAGE bottom row knobs to store the Vector position. Repeat for all four Cell boxes. This menu allows easy access to some of the creative Oscillator Bank Use the 1st three bottom row knobs to adjust the time-speed between parameters, giving quick access and hands on control to the timbre of each Cell.
-
Page 14: Settings Menu
NB the Q Performance Controls affect ALL Oscillator Banks. MODE – Allocation modes of Oscillator Banks. VEC1 = Monophonic Voice from all Banks mixed by Joystick For affecting a single Bank, select the bank as a destination in a Modulation Slot, select the destination atribute such as FD and use or vector animation Type1 VEC2 =Monophonic Voice from all Banks mixed by Joystick the offset control to adjust the amount. -
Page 15: Connection Jacks
"RPI-RP2". Copy or drag the UF2 firmware file into the "RPI-RP2" disk. There is also a 12 pin header to connect the Vector Wave Expander If successful, the disk will ‘eject’ automatically, and the module will module. DO NOT ATTEMPT TO CONNECT ANYTHING ELSE TO THIS restart with the new firmware. - Page 16 V/OCT & Gate inputs. instructions on page 13. Bank A is assigned to the V/OCT & GATE jacks on the Vector Wave Do not screw the Expander module into you rack yet, you will need the panel.
- Page 17 Name your Voices ! 15................1................16................17................2................18................3................19................4................20................5................21................6................22................7................23................8................24................9................25................10................26................11................27................12................28................13................29................30................14................
- Page 18 Name your Oscillator Banks ! 1................2................3................4................5................6................7................8................9................10................
- Page 19 Do some nice drawings here !
