- Page 1 S6000 Handheld Instruction Manual...
- Page 2 Introduction Thank you for purchasing your Trantec S6000 Handheld. If you require additional copies of these instructions, they can be obtained from our web site, http://www.trantec.co.uk, along with other information about the Trantec range. > Background Information S6000 Handheld microprocessor controlled UHF transmitter, which can operate on up to 40 different channels.
- Page 3 100m. > Guarantee All Trantec products are guaranteed for a period of one year from date of purchase against defects in materials and workmanship. In the event of a claim under guarantee the system should be returned to your dealer in its original packaging and with proof of purchase.
-
Page 4: Transmitter Setup
Transmitter Set-up Open the microphone by twisting the latch (1) at the base anti-clockwise. The sleeve then slides open to reveal a 1.5 V ‘ ” AA” alkaline battery holder on one side and an LCD, infrared port (7) and a screwdriver adjust on the opposite side. - Page 5 > Changing the Transmitting Frequency Next to the LCD there is a screwdriver adjust (5). This is a dual-function digital switch. When the microphone is initially turned on the LCD (6) shows the current gain setting for a few seconds. It then displays the currently loaded frequency.
- Page 6 RF link and can be monitored from the receiver. > Head selection The S6000 microphone can be used with a variety of different head options. The head capsule can be removed by grasping the grill and unscrewing the capsule assembly anti-clockwise at the point arrowed.
- Page 7 Appendix Frequency Guide for the UK Channel 69 (854 MHz – 862 MHz) is the only channel available throughout the entire UK. Other frequencies in the UHF band are available regionally. More information can be obtained through the JFMG (Joint Frequency Management Group).
- Page 8 ETS300-422/455 & FCC Delivery includes 1 x radio microphone transmitter body (microphone head to be ordered separately) 1 x microphone clamp 1 x instruction manual 1 x zipped pouch 1 x foam windshield Suitable receivers S6000 rack system, S6001 & S6002...
- Page 9 Information on adaptors for other manufacturers capsules is available on request. (BBM Electronics Group Ltd cannot be held liable for any damage to third party capsules that are attached to any Trantec product) This symbol indicates that this piece of electrical/electronic equipment must be disposed of separately from normal waste at the end of its operational life.
