- Page 1 Dryer User Manual BDPB104HW 2960313619_EN/040124.1246...
- Page 2 Dear Customer, Please read this guide prior to use this product! Thank you for choosing Beko product. We would like you to achieve the optimal efficiency from this high quality product which has been manufactured with state of the art technology. Please make sure you read and understand this guide and supplementary documentation fully before use.
-
Page 3: Table Of Contents
1 Safety Instructions .................. 5 1.1 Intended use ......................5 1.2 Safety of children, vulnerable persons and pets ............5 1.3 Electrical Safety ....................6 1.4 Transporting safety ....................6 1.5 Installing safety .....................7 1.6 Usage safety ......................8 1.7 Maintenance and cleaning safety ................10 1.8 Lighting safety ....................10 2 Environmental instructions.............. - Page 4 6 Running the product ................18 6.1 Control Panel ......................18 6.2 Symbols ......................18 6.3 Preparation of drying machine ................18 6.4 Program selection and consumption chart ............19 6.5 Auxiliary functions ....................22 6.6 Warning indicators ....................23 6.7 Starting the program ...................23 6.8 Child Lock ......................23 6.9 Changing the program after it is started ..............23 6.10 Cancelling the program ..................24 6.11 End of program ....................24...
-
Page 5: Safety Instructions
1 Safety Instructions This section includes the safety instructions necessary to prevent the risk of personal injury or material damage. • Our company shall not be held responsible for damages that may occur if these instructions are not observed. • Installation and repair operations shall always be performed by Authorized Service. -
Page 6: Electrical Safety
• Keep the packaging materials away from children. Risk of injury and suffocation. • Keep all additives used with the product away from children. • Before disposing of the product, cut the power cord and destroy the loading door. 1.3 Electrical Safety •... -
Page 7: Installing Safety
1.5 Installing safety • To prepare the product ready for installation, ensure that the electrical installation and water drain is proper by checking the information in the user manual. If it is not suitable for installation, call a qualified electrician and plumber to arrange the utilities as necessary. -
Page 8: Usage Safety
• Do not plug the product to loose, broken, dirty, greasy sockets or sockets that has come out their seats or sockets with a risk of water contact. • The new hose sets supplied with the product shall be used. Do not re-use the old hose sets. - Page 9 • Empty the pockets of the clothes and remove items such as matches and lighters. • If all items cannot be removed rapidly and cannot be placed where heat can dissipate, do not stop the drying machine before drying cycle completed. •...
-
Page 10: Maintenance And Cleaning Safety
• If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products be placed in a tumble dryer they should first be washed in hot water with extra detergent – this will reduce, but not eliminate, the hazard. -
Page 11: Environmental Instructions
: < 100mW Conformity declaration for CE Arcelik A.S. hereby declares that this appliance complies with Directive 2014/53/EU. The complete text of the EU declaration of conformity is available in the following internet address: – Products, from :support.beko.com Dryer / User Manual... -
Page 12: Your Drying Machine
3 Your drying machine 3.1 Technical specifications Height (Min. / Max.) 84,6 cm / 86,6 cm* Width 59,8 cm Depth 67,2 cm Capacity (max.) 10 kg** Net weight (± %10) 48 kg Voltage Rated power input See type label*** Model code * Min. -
Page 13: General Appearance
3.2 General appearance 3.3 Scope of delivery 1. Water 5. Water discharge filling cap* hose* 2. Filter drawer 6. Pure spare Water* sponge* 7. Odour 3. User Capsule Manual Group* 8. Filter 4. Brush* cloth* 1. Top panel 2. Control panel *Optional - may not be included, depends on 3. -
Page 14: Installation
4 Installation • Once the drying machine is installed, the connections must stay stable. After placing the drying machine, ensure that the back wall does not come in contact Read the “Safety Instructions” first! with any extrusion (a water tap, electrical outlet etc.). -
Page 15: Connection Of Water Drain Hose On Products With Vapour Feature
4.3 Connection of water drain hose 4.4 Adjusting the stands on products with vapour feature You can directly drain accumulated water Until the drying through the water drain hose supplied with machine stands level the product instead of periodically draining the and sturdy, adjust water collected in the water tank the stands by turning... -
Page 16: Preparation
5 Preparation 5.3 Preparing the laundry to be dried Items such as coins, metal parts, needles, nails, screws, stones etc. may damage the drum group of the product or may cause functional Read the “Safety Instructions” first! operation issues. Therefore check all laundry that will be loaded to the product. -
Page 17: Correct Load Capacity
• If you are using environment friendly filter, you are not required to clean the filter after every cycle. When the environment friendly icon is lit on the screen, change the filter cloth. 5.5 Correct load capacity NOTICE If the laundry in the product exceed maximum load capacity, it may not... -
Page 18: Running The Product
6 Running the product 6.1 Control Panel 1. Program selection button. 7. Express Dry (RapiDry) button and child lock selection button. 2. On / Off button. 8. Steam selection button. 3. Start / Pause button. 9. Reverse drum selection button. 4. -
Page 19: Program Selection And Consumption Chart
6.4 Program selection and consumption chart Table of steam functioned cycles Programmes Programme Description 1,5 (6 pieces) Is a cycle aimed to reduce the wrinkle level on shirts and t-shirts using a steam function. This cycle usually eliminates the need for ironing for casual shirts after drying. - Page 20 Table of non-steam functioned cycles You may dry your cotton laundry to be ironed in this Cottons Iron dry 1000 program to have them slightly damp for ease of ironing. (Shirt, T-shirt, tablecloth, etc.) It is the programme that you can dry your washed products you want to provide with extra hygiene (baby clothes, underwear, towels, etc.).
- Page 21 Downloaded Program Use it to dry your clothes made of synthetics, cotton Outdoor/Sports or mixed fabrics or waterproof products such as 1000 (Goretex) functional jacket, raincoat etc. Turn them inside out prior to drying. It provides hygienic drying for your underwear Underwear 1000 via high temperature.
-
Page 22: Auxiliary Functions
2. Select the drying program. Allergy UK is the trademark of the British Allergy Foundation. 3. Press the End Time selection button and The Seal of Approval has been set the delay time you wish. End time LED created to guide people turns on. -
Page 23: Warning Indicators
The child lock has to be deactivated to be able to start a new program after the current program is finished or to be able to interfere with the program. To deactivate the child lock, keep the same buttons pressed for 3 seconds. When the child lock is activated, the child lock warning indicator on the screen turns on. -
Page 24: Cancelling The Program
If the Wrinkle Prevention mode Adding laundry after the drying is active and the laundry is not operation starts may cause the removed after the program is dried laundry inside the drying completed, the wrinkle prevention machine to mix with wet laundry function activates for 2 hours to and leave the laundry damp at the prevent the laundry inside the... -
Page 25: Homewhiz Function
Press the Dryness level and Remote Control keys together for 3 seconds. 3-2-1 appears on the screen during this time. Then the image This symbol indicates that you can run the below appears on the screen. drying cycle with a maximum load of 1.5 kg (6 pieces). - Page 26 :Deleting the product from network When the time delay and Wifi buttons are pressed for 5 seconds while the product is on, it counts down from 5 on the screen and when the beep is heard, the product is deleted from network and the Wifi is turned off.
-
Page 27: Maintenance And Cleaning
7 Maintenance and cleaning • Open both of the lint filters (outer and inner) and remove the fibres with your hands or with the brush on the air deflector. You can clean the hair in the filters with a vacuum cleaner. -
Page 28: Cleaning The Sensor
• Insert the lint filters on one another and place it back in its place. Clean the metal surfaces of the sensor 4 times a year. Do not use metal tools to clean the sensors’ metal surfaces. Due to fire and explosion hazard, do not use solutions, cleaning materials •... -
Page 29: Cleaning The Condenser
The cleaning brush is inside the documentation bag. Get your brush from the documentation bag and insert it to its place on the air deflector to store it. If fibre is accumulated in the funnel on the Clean the fibre on the water tank, remove it under running water. - Page 30 When the air deflector cover is removed, it is normal to have water at the plastic section in front of the condenser. If you see fibre accumulation on the fan cover and the toe board, remove with a cloth. Do not have weight on the toe board when it is open.
-
Page 31: Troubleshooting
8 Troubleshooting The drying operation takes too long. Fibre filter (interior and exterior filters) pores may be clogged. >>> Wash the fibre filters with warm water and dry them The front side of the condenser may be clogged. >>> Clean the front side of the condenser. The ventilation grills in front of the machine may be closed. - Page 32 The fibre filter cleaning icon is lit. Fibre filters (interior and exterior filters) may be unclean. >>> Wash the filters with warm water and dry them. A layer may be formed in the fibre filter pores, leading to clogging. >>> Wash the filters with warm water and dry them. A layer may be formed in the fibre filter (internal and external filters) pores that leads to clogging.<<Wash the filters with warm water and dry>>...
- Page 36 www.beko.com.au...
