UNILITE WL-450R Manual

PRODUCT FEATURES
450 Lumen 7W white 6500K COB LED
ƒ
Additional 450 lumen 3W 6500K CREE LED spot beam with
ƒ
magnifying collimator lens for long distance beam
Ultra tough nylon & TPR construction
ƒ
360˚ Rotating stand/handle with super strong magnets
ƒ
Memory switch - remembers last mode used
ƒ
IP65 Dust & water resistant
ƒ
IK07 Shock proof - 2M drop resistant
ƒ
Powerful 3.7v 1500mAh Li-polymer battery
ƒ
Battery level & charging indicator LED under the switch
ƒ
Fast 3A USB-C charging - 2.5 hour charge time
ƒ
Supports fast 'USB PD' (power-delivery) charging
ƒ
1m high quality USB-C cable included
ƒ
BATTERY - 3.7v 1500mAh Li-polymer rechargeable battery
WEIGHT - 145g
DIMENSIONS - 69.5 x 34.1 x 85.7mm
ADVICE & IMPORTANT INFORMATION!
ƒ Do not look directly at LEDs.
ƒ Do not operate in direct sunlight or extreme temperature conditions
(below -10˚C or above 40˚C).
ƒ LEDs can become warm/hot when switched on; DO NOT touch and
NEVER place face down on any surface – risk of fire! Even once the
device has been switched off, DO NOT place face down as the LED and
Lens can stay hot/warm for a while.
ƒ Do not use the device if there is any visible damage.
ƒ Do not use the device in the immediate vicinity of flammable materials
or gases.
ƒ Take care when charging, check the charging output on the charging
source you are using and DO NOT exceed the stated Max charging input
or damage may occur to the battery and may void the warranty.
ƒ The rechargeable battery will reach full performance after a few complete
charging and discharging cycles.
ƒ To keep the rechargeable battery in optimum condition, it should be
recharged every 3-6 months, especially if it is not being used for a long
period of time.
ƒ Always fully charge rechargeable batteries before storage and if the
rechargeable battery can be removed, this is advised to avoid battery
depletion and avoids the risk of a battery leaking.
ƒ Always protect lithium batteries from heat, intense sunlight, fire, water
and moisture – danger of explosion!
ƒ If a battery is damaged, fluids can leak out. AVOID contact as this can lead
to skin irritation and/or burns. If skin contact occurs, rinse thoroughly with
www.unilite.co.uk
English
ANSI FL1 Standard
SPOT BEAM
FLOODLIGHT - LOW
FLOODLIGHT - HIGH
OPERATING INSTRUCTIONS
SWITCH SEQUENCE:- Spot Beam > Floodlight Low > Floodlight High
> Off
Memory Switch - If left On in any mode for over 5 seconds, the next
press will turn off. Next press On will return to the last mode used.
RECHARGING
1. Only use a 5V USB-C charging cable.
2. Lift the charging port cover on the back of the light.
3. Plug the USB-C end of the cable into the charge port.
4. Plug the USB-A end of the cable into a USB charging source (do
not exceed 5V-3A charging input or damage may occur).
5. Green Flash indicates charging, Solid Green indicates fully charged.
6. Charge Time: 2.5 hours
7. Make sure the charge port cover is secured back in place.
(THIS PRODUCT CAN NOT BE USED WHILE RECHARGING)
*Warranty void if not used with the specified cable & max charge
input*
CHARGING INDICATOR
BATTERY LEVEL INDICATOR
NOTE: Battery indicator lights up for 10 seconds when the worklight is
first turned on.
water. If irritation persists, seek medical advice. Seek immediate medical
assistance if lithium battery fluid comes into contact with the eyes.
ƒ Children under 12 years of age should only use the product under adult
supervision.
ƒ Do not disassemble or attempt to modify the product; this will void the
warranty and can be dangerous. Improper use or modification is not
covered under the warranty.
ƒ Take care not to let lenses come into contact with hard/sharp objects,
damage/scratches to lenses will affect light output.
ƒ Before cleaning the product, disconnect the charge cable. Clean with
a dry or slightly moist, clean, lint-free cloth and a mild detergent if
required. Do not use cleaners that contain abrasives or solvents.
ƒ This product is water resistant to IPX5 – DO NOT SUBMERGE. If the
product has been subjected to excessive moisture/water the warranty
may be void.
ƒ This product has a 1 year standard warranty (or extended to 2 years
once registered online at WWW.UNILITE.CO.UK/WARRANTY) against
manufacturing faults and defects. It does not cover normal wear and tear,
modifications, accidental damage or poor maintenance. Unilite standard
warranty does not cover disposable batteries that have leaked or the use
of incorrect chargers and cables that can damage rechargeable batteries.
ƒ Do not dispose of this device in normal household waste. It must be
disposed of via an authorised electrical appliance disposal centre or at
your local waste disposal unit.
ƒ Please re-use or recycle packaging responsibly.
ƒ Keep these instructions for future reference or for subsequent possessors.
450
Lumen
125
Lumen
450
Lumen
Green Flashing = charging
Solid Green = fully charged
Green = 65% - 100%
Orange = 30% - 65%
Red = 5% - 30%
Red Flashing = less than 5%
WL-450R
34 M 2.5 H
11 M 6 H
29 M 2.5 H
