I
NSTALLATION
Straight
installation
1
1 - Insulated chimney
2 - Finish support
3 - Trim collar (DQ)
2
4 - Telescopic length
3
(DL42A)
4
5 - Appliance
5
Cathedral
ceiling
installation
1
1 - Storm collar
2
3
2 - Roof flashing
3 - Cathedral support
4
4 - Decorative collar (DQD*)
5 - Double wall black
5
pipe length (DL)
6 - Appliance
6
Through-the-wall
installation
1
2
1 - Insulated chimney
6 in. MINIMUM
3
7
2 - Wall radiation shield
4
3 - Decorative collar (DQD*)
4 - Elbow (DE90)
6
5
5 - Telescopic length
(DL42A)
6 - Wall support
6 in.
7 - Insulated tee
8 - Appliance
*DQDH for ASHT + chimney
*DQDX for S-2100 + chimney
8
WARNING: The double-wall
black stove pipe connectors
must not be used as a chimney.
O
F
RDER
ORM
Chimney size
6"
7"
8"
Circle required size and indicate the quantity needed.
Ref.
Description
42
Lengths
DL
A
Telescopic length
3 1/2
' to
5 1/2
'
6 6
DL
" length
12 12
DL
" length
24 24
DL
" length
36 36
DL
" length
3
DL
A
Adjustable length
3
9
" to
"
DT
Tee
45 45
Elbows
DE
° elbow
90 90
DE
° elbow
Adaptors
DMA
Masonry adaptor
DAB
Stove adaptor
DLW
Increaser
DLR
Reducer
UP
Flue extension
Decorative Parts DQDH
Decorative collar for
ASHT chimney
DQDX
Decorative collar for
2100
S-
chimney
DQ
Trim collar
Accessories
DLK
Damper
IMPORTANT:
This booklet must be perceived only as a "planning guide".
For complete information consult the instruction
manual, included in DAB, DL3A, DL42A, DLK and DMA
components.
NOTE: Allow for a reduction of 1-1/2" per joint after
assembly.
Security Chimneys International Ltd.
2125 Monterey
Laval (Quebec)
Canada H7L 3T6
SECURITY CHIMNEYS
Tel.: (514) 973-9999
INTERNATIONAL
Fax.: (514) 973-2222
Warnock Hersey
Specifications subject to change without prior notice.
®
Security Chimneys International is
Distributed by:
certified ISO 9001, your guarantee
of quality and satisfaction for years
to come.
AD-DL
REV:0 10-1997
Printed in Canada
D
Quantity
Price
DL
- STOVE PIPE CONNECTOR
Tested to 2100°F and
listed at a 6-inch
clearance to combustible
materials
W
B
S
OUBLE
ALL
LACK
TOVE
SECURITY
CHIMNEYS
P
IPE
