Public Address System
D6801 Conference Host
D6802 Chairman MIC (3 1.5V AA Batteries)
D6803 Delegate MIC (3 1.5V AA Batteries)
D6802L Chairman MIC (Lithium Battery)
D6803L Delegate MIC (Lithium Battery)
User Manual
Thank you for using our DSPPA public address system. Please read this User Manual carefully to make better use
of this equipment.
G u a n g z h o u D S P PA A u d i o C o . , L t d .
http://www.dsppatech.com / http://www.dsppacs.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DSPPA D6801
Summary of Contents for DSPPA D6801
- Page 1 D6803L Delegate MIC (Lithium Battery) User Manual Thank you for using our DSPPA public address system. Please read this User Manual carefully to make better use of this equipment. G u a n g z h o u D S P PA A u d i o C o . , L t d .
- Page 2 This page is left blank for memo.
- Page 3 About the Manual This User Manual is available and effective upon completion of development of wireless conference system device. The User Manual includes system description, matters needing attentions in use, instructions on system connection, and instructions on use of product of wireless conference system device.
- Page 4 Caution To assure the finest performance, please use or operate the product in accordance with corresponding instructions. This symbol indicates "forbidden content" This symbol indicates "compulsory content" ■ Please make sure that the ■ When the equipment is in use, DO NOT block the air power wire is NOT damaged.
-
Page 5: Table Of Contents
CONTENTS Chapter One Host Part ...............................1 I. Product Description ..............................1 1.1 Device Introduction ..............................1 1.2 Features ...................................1 II. Appearance Description ............................2 2.1 Front Panel ................................2 2.2 Rear Panel ................................2 III. System Working Environment & Operating Procedures ..................3 3.1 System Working Environment ........................3 3.2 System Operating Procedures ........................ -
Page 6: Chapter One Host Part
Wireless Conference System Chapter One Host Part I. Product Description 1.1 Device Introduction This product is a wireless intelligent discussion conference system with video tracking function. It uses digital wireless processing technology to process audio signals and control signals, no need for complicated wiring. With the scientific ID code design, it can be used when the power is turned on, easy to install and operate. -
Page 7: Appearance Description
Wireless Conference System II. Appearance Description 2.1 Front Panel 1. POWER 5. Left Button / VOL- Button 2. Full-view 4.3" Color Screen 6. Right Button / VOL+ Button 3. Down Button 7. OK/ENTER/Page-turning Button 4. Up Button 8. Exit Button 2.2 Rear Panel 1. -
Page 8: System Working Environment & Operating Procedures
Wireless Conference System III. System Working Environment & Operating Procedures 3.1 System Working Environment After taking out the host from the packing box, connect the antenna to the antenna socket of the host, and adjust the antenna to the top up and basically perpendicular to the ground. Please note that reflective objects such as large metal objects, walls and ceilings, as well as shielding objects like human bodies will weaken the direct signal of the transmitter. -
Page 9: System Functions
Wireless Conference System IV. System Functions 4.1 Working Status Settings Press the OK button “ENTER”, and the content of the working status option flashes once and is displayed with a black background. Press the Left button “ ” or Right button “ ” to select between the two options of “mode, number of speakers”, and press the Up button “... -
Page 10: Camera Settings And Diagram
Wireless Conference System 4.3 Camera Settings and Diagram On the main interface, press the OK button “ENTER” four times to enter the camera setting interface. The setting option content flashes once and is displayed with a black background. Press the Left button “ ”... -
Page 11: Master Volume Setting And Diagram
Wireless Conference System 4.4 Master Volume Setting and Diagram In any working status, the output volume of the host can be adjusted by just pressing the Left button “ ” or Right button “ ”. Press the Left button “ ” or Right button “ ” to adjust the volume to the desired volume. (Press the Left button “... -
Page 12: Preset Point Settings
Wireless Conference System camera (make sure that every unit is saved on the host according to the preset point). 2. If there are multiple cameras in use, the unit IDs can only be superimposed in order, and the tracking objects can be distinguished by the PTZ ID. -
Page 13: Connection Diagram
Wireless Conference System VI. Connection Diagram System Connection Diagram Note: Precautions for host installation (otherwise it will affect the reception effect) 1m above the floor At least 1m away from the wall Antenna perpendicular to the host... -
Page 14: Connection Mode Of Host And Antenna
Wireless Conference System Connection Mode of Host and Antenna A. Host + Omnidirectional Antenna In an open environment, connect the 2.4G host to an omnidirectional antenna, with the straight-line distance of ≤30 meters. The omnidirectional antenna must be vertically upward (as shown in the figure). B. - Page 15 Wireless Conference System D. Host + 10m Antenna Extension Cable + Antenna Amplifier + Directional Antenna Connect the 2.4G host to the antenna extension cable, then to the antenna amplifier, and finally to the directional antenna, with the straight-line distance of ≤80 meters, which can meet the needs of different occasions and different environments.
-
Page 16: Directional Antenna Installation Diagram
Wireless Conference System VII. Directional Antenna Installation Diagram Please tighten the screws to fix it after installation. -
Page 17: Faq
Wireless Conference System VIII. FAQ Faults Causes Solutions Mains socket is not Check the mains socket. The host has no power-on energized. response. External power supply Check and replace the external power supply of failure. the host. The unit is not turned on. Turn on the corresponding unit. -
Page 18: Chapter Two System Mic
Wireless Conference System Chapter Two System MIC I. Features 1.1 Chairman MIC Features Adopt a new digital control design. Cardioid directional condenser pickup microphone, with first-class intelligibility and directivity. There are three lengths of microphone rods: 400MM, 270MM and 136MM. The LCD display shows the working mode, unit ID, battery power, speaking status, and speaking time. -
Page 19: Appearance Description
Wireless Conference System II. Appearance Description D6802/D6802L Chairman MIC D6803/D6803L Delegate MIC... -
Page 20: Appearance Description Of D6802/D6802L Chairman Mic (Take D6802 For An Example)
Wireless Conference System 2.1 Appearance Description of D6802/D6802L Chairman MIC (Take D6802 for An Example) MIC Rod LCD Display Standby/Speak Button Chairman Priority Button Short Connector 2.2 Appearance Description of D6803/D6803L Delegate MIC (Take D6803 for An Example) MIC Rod LCD Display Standby/Speak Button Short Connector... -
Page 21: Operating Instructions And Functions
Wireless Conference System III. Operating Instructions and Functions 3.1 Conference MIC Operating Instructions Open the battery cover at the bottom of the D6802 chairman unit/D6803 delegate unit, and insert 3 1.5VAA batteries with the correct positive and negative polarity; the D6802L chairman unit/D6803L delegate unit can be directly charged, and support continuous speaking time of more than 10 hours. -
Page 22: D6802 Chairman Mic/D6803 Delegate Mic Battery Installation Diagram
Wireless Conference System 3.3 D6802 Chairman MIC/D6803 Delegate MIC Battery Installation Diagram Battery Compartment (Bottom) Note: Do not install the battery with wrong polarity, otherwise it may damage the internal electronic components of the chairman unit. The battery compartment is loaded with 3 1.5V AA batteries, for continuous speaking time of more than 6 hours. -
Page 23: Faq
Wireless Conference System IV. FAQ Faults Causes Solutions The host has not been turned on. Turn on the host. The unit displays The communication ID does not Reallocate the communication “Connecting”. match. Replace the battery with The unit displays “Shutdown”. Low battery. -
Page 24: Packing List
Wireless Conference System Packing List Host Packing List: List Quantity D6801 Host 1 piece D24V Power Cord 1 piece 6.3-6.3 Connection Cable 0.5m 1 piece User Manual 1 copy Directional Antenna 1 piece Omnidirectional Antenna 1 piece Antenna Amplifier 1 piece... -
Page 25: Specifications
Wireless Conference System Specifications System Parameters: Power Supply DC12-17V Frequency Range 2400MHZ-2483.5MHZ Operating Mode FHSS Reception Mode Receiving Sensitivity ≧100dBm >90dB Distortion <0.05%dB Effective Working Distance (in ≤30m (Omnidirectional antenna) Open Environment) ≤40m (Connect directional antenna) ≤70m (Connect antenna amplifier + directional antenna) Power 6.5W EIA Standard Chassis... - Page 26 Wireless Conference System Delegate MIC Parameters: Delegate MIC D6803 D6803L Power Supply DC4.5V, 1.5V AA*3 Built-in lithium battery 3.7V 2100mAh Modulation Mode Transmitting Power 10mW Pick-up Microphone Condenser, unidirectional Sensitivity —38±2dB@1KHz Frequency Response 20Hz~20KHz Operating Current 140mA The LCD display shows the working mode, unit ID, battery power, speaking status, and speaking time. Host Dimensions: Host Package Dimensions (L×W×H) 560×480×195mm...
- Page 27 Wireless Conference System Safety Precautions 1． Safety Precautions Please do NOT connect this device to the power source, before the system is correctly wired. It is important to ensure that input voltage to the device is the same as required voltage of the device, ...
- Page 28 Therefore, it is required to place the power socket to a position where the power cord can be plugged and unplugged conveniently. Guangzhou DSPPA Audio Co., Ltd.
