User Manual
Welcome your entering DSPPA family music control system. For better use of the equipment, you are invited to
read the manual carefully before operation.
Digital Programmable Conference System
CM60
G u a n g z h o u D S P P A A u d i o C o . , L t d
CM60
http：//www.DSPPA.com
MP9866
CM-60
CM-61
Advertisement
Table of Contents
Related Manuals for DSPPA MP9866
Summary of Contents for DSPPA MP9866
- Page 1 CM60 CM60 Welcome your entering DSPPA family music control system. For better use of the equipment, you are invited to read the manual carefully before operation. G u a n g z h o u D S P P A A u d i o C o . , L t d...
-
Page 2: Table Of Contents
Table of Contents General Description ............................1 Description of Control Unit MP9866 ......................1 Functions of Control Unit ........................1 Appearance of Control Unit MP9866 ....................2 2.2.1 Front Panel ..........................2 2.2.2 Back Panel ..........................2 Operation Instructions of MP9866........................3 System Connection .......................... -
Page 3: General Description
General Description Concerning Digital Programmable Conference System The digital programming conference system is composed of the system control unit MP9866, chairman microphone CM60, delegate microphone CM61 and connecting line etc., adopting the full digital control design, and having multiple operation modes. It is a professional conference system with a real meaning of answering-outbidding and auto-queuing function. -
Page 4: Appearance Of Control Unit Mp9866
* Fire protection / PA system Digital Programming Conference System Appearance of Control Unit MP9866 2.2.1 Front Panel 15 16 Power switch (Press Position 1 to turn on the power, Press Position 0 to turn off the power.) Power indicator (The indicator is lit when the power is turned on, and the indicator is distinguished when the power is turned off.) -
Page 5: Operation Instructions Of Mp9866
System audio balanced output port (BALANCED OUT). (Connected to the power amplifier, the output signal is not controlled by control unit tone adjustment.) System connection port 8P-DINX3 (LONE). (Connected to microphone units) Interface has not been enabled. AC220 power outlet (AC). Operation Instructions of MP9866 System Connection AC 220V CM61 CM60... -
Page 6: Free Speech Mode
* Fire protection / PA system Digital Programming Conference System 3.2.1 Free Speech Mode It means that all the microphones inside the system can be freely turned on/off. The chairman microphone priority key acts on all the delegate units. 3.2.2 First-In-First-Out Mode It means it is able to select the quantity of delegate microphone turned on simultaneously in the system and the microphones can be turned on in alternation within this scope (maximum 19 pcs). -
Page 7: First-In-First-Out (Fifo) Mode Setup
* Fire protection / PA system Digital Programming Conference System indicator “C. only” changes to long-term lit status and starts flashing again 2 seconds later, this means it is in Chairman Only mode; if the indicator “C. only” goes out and starts flashing again 2 seconds later, this means it is in Chairman Common mode. -
Page 8: Microphone Unit Cm60, Cm61
* Fire protection / PA system Digital Programming Conference System Microphone Unit CM60, CM61 Functions of Delegate Unit CM61 Fully digital-control design. Powered by system Control Unit. The output voltage is a safety voltage, 18V. The unit is provided with a 1.5m 8P connection line, used for “cross” type line connection. ... -
Page 9: Precautions For Operation
As to the subjects or precautions not mentioned in the manual, please contact the distributor or visit the web page of our company: //www. dsppa. com when necessary. Please contact the service personnel of the company (or the distributor) if there is any failure phenomena... - Page 10 Switch AC220V Static power dissipation Max power ≤36W/18V/channel Output power Impedance：100Ω unbalanced Audio output 100±10mV Input sensitivity Freq. Response 50-16kHz >65dB S/N(S/N) < 0.5% Weight About 6.5KG Size 484L x 365W x88H (mm) Color Black Guangzhou DSPPA Audio Co. Ltd...
