NEFF W7320F1EU Installation Instructions Manual

Safety instructions

Humidity in the drum
Scope of delivery
is caused by the final
inspection.
Depending on the connection
Useful tool
Installation Area
- Stability is important to prevent the machine from wandering!
- The installation area must be firm and level.
- Soft floors/floor coverings are not suitable.
If installing the appliance on a base
If installing the appliance on a wooden joist ceiling

Hose and cable lengths

depending on model
Connection on left side Connection on right side
100 cm  150 cm
145 cm 90 cm
85 cm 140 cm

Built under/Built in appliance

Build under/build in before connection to the power supply.
Installed in between kitchen units
Built under appliance
1
Remove transportation protection
devices
- Before using the appliance for the first time, remove all the transportation
protection devices and retain for subsequent transportation of the
appliance.
- Keep the bolt, washer and sleeve screwed together.
1.
2.
3.
4.
5.
2

Water connection

depending on model
- To prevent leakage or water damage, follow the instructions in this chapter!
- Attention: Operate the washing machine with cold and hot (max. 70 °C) drinking water only.
Do not connect to a mixer tap of a pressureless hot water heater.
- If in doubt, have the appliance connected by a technician.
Water supply
Do not:
Optimum water pressure in the mains: 100-1000 kPa (1-10 bar)
3 4
1.
Tighten plastic screw fittings by hand only.
2.
3.
1 2
A - cold water
B - hot water
(max. 70 C)
Water drainage
Drainage into a washbasin:
Drainage into a siphon:
3
or :
cold water connection only with Y piece
4
