The IBEX product line represents advanced speed controllers for use exclusively in RC airplane models. With
integrated telemetry and various possibilities of optional user configuration, the controllers offer high
efficiency, low weight and precise motor control.
F
EATURES
-
Small dimensions combined with high power motor control.
-
Over- and undervoltage protection, overtemperature protection, motor-stall protection.
-
Configurable current limiter.
-
Fast and precise heli/governor mode with many configuration possibilities.
-
Optically isolated throttle input.
-
Safety shutdown when the throttle impulse is lost.
-
Configurable acceleration, timing, electromagnetic brake, motor reversing etc.
-
Low acoustic noise due to high frequency switching.
-
Automatic telemetry detection: Duplex EX, Hott, MSB, PowerBox P
with Spektrum SRXL2 telemetry support.
-
Telemetry (RC system dependent): voltage, current, power, capacity, temperature, RPM, energy.
-
Telemetry min/max values are logged.
-
Configuration through the transmitter, MAV Manager PC software or external terminal (JETIBOX/
SMART-BOX).
-
Firmware updates via USB interface.
-
Languages: CZ/DE/EN/FR/IT.
Dimensions
Weight incl. cables
Continuous current
Peak current
Supply voltage
LiPo cells
LiFe cells
Battery/motor cables
Anti-spark circuit
Recommended
connectors
Temperature range
PWM frequency
Operating current
Standby current
Propeller positioning
Telemetry
Status LED
Active Freewheeling
BEC
Optical isolation
Maximum RPM
I
NSTALLATION
Fasten the controller in your model by the screws. Alternatively, you can use Velcro or double-sided adhesive
tape for fixing. Connect the motor and receiver according to the schematic below. You may connect the motor
cables in arbitrary order, as changing direction is done by exchanging any of the two cables (alternatively also
by the "Direction" parameter in the configuration). Turn on the transmitter followed by the receiver – the
receiver uses a separate battery. Now you can plug in the main flight pack.
IBEX E
LECTRONIC
I
M
NSTRUCTION
ANUAL
IBEX-80
IBEX-120
57x35x28mm
58x53x24mm
60g
80A
120A/2s
8 – 51V
(max. 64V)
3 – 12
3 – 14
4mm
/2.5mm
4mm
2
2
No
G4 (75A)
G5.5 (150A)
XT90 (90A)
Duplex EX, Multiplex MSB, Futaba S.Bus2, Graupner Hott, PowerBox P
Throttle input only
S
C
PEED
ONTROLLER
F
V
IRMWARE
ERSION
IBEX-130
58x53x28mm
110g
110g
120A
130A
160A/2s
180A/2s
10 – 59V
10 – 51V
4 – 14
4 – 12
4 – 16
4 – 14
/4mm
4mm
2
2
2
Yes
Yes
G5.5 (150A)
-10÷110°C
20kHz
50mA
4mA
With additional Hall-sensor
Spektrum SRXL2™
Yes
Yes
No
> 300 000 eRPM (2-pole motor)
1
2.02
Bus, S.Bus2. Alternative firmware
2
IBEX-200
81x63x35mm
270g
200A
260A
12 – 59V
(max. 64V)
4 – 14
4 – 16
/4mm
6mm
/6mm
2
2
Yes
G8 (170A)
Complete
IBEX-220
81x63x35mm
270g
220A
280A
10 – 51V
4 – 12
4 – 14
6mm
/6mm
2
2
2
Yes
G8 (170A)
60mA
10mA
Bus,
2
Advertisement
Table of Contents
Related Manuals for MAV Sense IBEX-200
Summary of Contents for MAV Sense IBEX-200
- Page 1 Telemetry (RC system dependent): voltage, current, power, capacity, temperature, RPM, energy. Telemetry min/max values are logged. Configuration through the transmitter, MAV Manager PC software or external terminal (JETIBOX/ SMART-BOX). Firmware updates via USB interface. Languages: CZ/DE/EN/FR/IT. IBEX-80 IBEX-120 IBEX-130 IBEX-200 IBEX-220 Dimensions 57x35x28mm 58x53x24mm 58x53x28mm 81x63x35mm 81x63x35mm Weight incl. cables...
-
Page 2: Controller Mode
Note: The red LED on the controller will light up for two seconds to indicate proper initialization. After the correct throttle impulse is detected (meaning off position), the controller plays a predefined melody. Now it’s ready to fly. If the throttle impulse is not detected for more than 4 seconds (e.g. after disconnecting the receiver battery), the controller will enter standby mode. - Page 3 Acceleration influences the motor response on the throttle channel. By decreasing the acceleration value, the motor response gets faster, providing more “locked-in” feeling. However, the motor consumes more current and the controller generates more heat. We recommend the default acceleration 1.0s for majority of model types, including electric gliders, scale models, EDFs etc.
- Page 4 ROPELLER POSITIONING The positioning feature allows moving the motor/propeller to the exact position required for safe landing, or which is just comfortable for further flying. With just a few external components (Hall-sensor and a small magnet) you can enable this feature and prevent the risk of damaging your propeller during landing. The magnet needs to be properly fixed to the rotating part (either motor or the propeller), and the Hall-sensor has to be located in the fuselage, so that the magnet matches the Hall-sensor at the target propeller position.
-
Page 5: Status Codes
NTISPARK FEATURE The IBEX-120/130 and IBEX-200/220 controllers contain an additional circuit which can be optionally used to prevent sparks when the battery is connected. This circuit is linked to the flight pack using a separate cable. Use the antispark cable only for precharging the controller. Never use the cable for powering the motor or any external electronic components. - Page 6 OVERNOR MODE The speed controllers contain a fast and precise governor function. You are able to configure the governor mode in many aspects according to your preferences. Before enabling the governor mode, please make sure the blades are removed. In the Common Setting menu, set the Controller Mode to “Heli/Governor”...
- Page 7 Note: Please make sure the gear ratio and number of motor poles are correctly set in the Motor Setting menu. Also, please verify that the brake is disabled and check the state of the propeller positioning function. Please note that dynamic changes of the motor revolutions in flight are limited by the “Acceleration” parameter configured in the Motor Setting menu.
- Page 8 OTOR DIRECTION REVERSING The motor reverse feature is available for RC systems with bidirectional bus support (EX Bus, P Bus, SRXL2, S.Bus2). To control the motor direction you need to define an additional channel transferred through the bus system. Both cables (red and black) of the IBEX speed controller must be properly linked the receiver. First, you need to create an additional channel on you transmitter to control the motor direction.
-
Page 9: Galvanic Isolation
IBEX-80 and IBEX-120/130 schematic: IBEX-200/220 schematic: AN CONTROL The IBEX-200/220 contains a driven output for the external fan (5V, up to 300mA). It is activated as soon as the controller temperature reaches 55°C. Use only a suitable fan which is sold as an additional controller accessory. - Page 10 ELEMETRY AND ETTINGS Plug the red data cable into the sensor slot of the JETIBOX / SMART-BOX (or corresponding receiver). Power it up with a battery (4.5 - 8.4V). Now you can safely configure the controller using the arrows on the terminal. The IBEX ESC is compatible with JETIBOX programming.
- Page 11 JETIBOX Menu Structure Available EX and P Bus telemetry 1. Battery voltage [V] 2. Motor current [A] 3. Capacity [mAh] 4. Speed [RPM] 5. PWM [%] 6. Power [W] 7. Running time [s] 8. Energy [Wmin] – useful feature for competitions where total energy is limited (F5B, F5D).
- Page 12 Futaba and Multiplex connection Futaba and Multiplex systems do not offer wireless device configuration. The telemetry transmission is possible with the following fixed sensor slots: Futaba S.Bus2 slot Note Multiplex MSB slot Choose RPM sensor on slot 2. Current Choose SBS01C current sensor on slot 3.
-
Page 13: Safety Information
Note: The IBEX version 2.01 and later is compatible with Spektrum single-cable operation (Smart Throttle). To enable this function, just plug the red telemetry cable into receiver channel No.1 and keep the other (black) cable unplugged. You will be able to control throttle as well as receive telemetry. This approach is compatible with AR10400T receiver family as well. -
Page 14: Firmware Update
USB interface. On the other hand, the IBEX-200/220 requires connecting at least a 3S LiPo main battery since the power circuit is completely galvanically isolated from the signal interfaces. Always start the MAV Manager first and connect the controller through the USB interface. - Page 15 Connect the controller to your PC using the USB interface. The ESC will be automatically detected by the MAV Manager. The controller properties are available after pressing the “Configure” button. Motor settings. Every time you make any change in Real-time telemetry with min/max values. The MAV the configuration, the new value is immediately Manager is also able to create a log file from the real- time telemetry data, which can be viewed, analyzed,...
-
Page 16: Warranty
Warranty and post warranty service is provided by the manufacturer. Distributor GB: ESG-JETI-FIALA UK, B M Jones, 15 London Road, Hassocks, West Sussex, BN6 9NT, United Kingdom. E-mail: sales@esoaringgadgets.co.uk | Website: www.esoaringgadgets.co.uk | Phone: 44(0)7740181861 Manufacturer MAV Sense s.r.o. E-mail: info@mavsense.com | Website: www.mavsense.com...
