Installing TKIS-2 VoIP Intercom Module
Item Number
Item Name
1008131020
TKIS-2
Power/Relay Inputs: Programmable relay. Max: 250VAC/220VDC, 2A, 60W
I/O Interface:
Interface for control inputs, control outputs and analog audio line out.
External Audio:
Connection for microphone and loudspeaker.
Ethernet Port:
Ethernet connection with Power over Ethernet.
DIN Mounting Clips: Plastic clips for mounting the device to a DIN rail.
1
Mounting the TKIS-2
The TKIS-2 is normally mounted on a DIN rail. The DIN rail shall be mounted securely to the equipment
rack, and properly stabilized.
Description
VoIP Intercom Module
Figure 1: TKIS-2 Overview
Figure 2: TKIS-2 Mounting Clips
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vingtor Stentofon TKIS-2
Summary of Contents for Vingtor Stentofon TKIS-2
- Page 1 DIN Mounting Clips: Plastic clips for mounting the device to a DIN rail. Mounting the TKIS-2 The TKIS-2 is normally mounted on a DIN rail. The DIN rail shall be mounted securely to the equipment rack, and properly stabilized. Figure 2: TKIS-2 Mounting Clips...
- Page 2 VDC local power supply. Network Connection There is a RJ-45 port located on the TKIS-2 that is used for PoE/LAN Ethernet connection to the network. Inputs & Outputs There are 6 I/O connection options for the Turbine Compact Station. These connections can be used to interface with external I/O devices.
