KingsBottle WRTS04 Assembly Instructions Manual

Wine Rack Assembly Instructions
STEP 1 - BOTTOM FRAME
• Assemble the bottom metal frame on a flat surface.
• Line up and hammer the timber slats into the metal
frames using a rubber mallet. Make sure it's fully
hammered in.
• Start from the center.
( Instruction Video )
A
B
C
D
STEP 2 - TOP FRAME
Insert one section of the metal frame only halfway
down into the wood pieces.
( Instruction Video )
E
Insert the 2nd section of the metal frame into the 1st
and use a rubber mallet to complete the installation
into the wood pieces.
F
STEP 3 - NECK PROTECTOR
Snap the bottle neck protectors onto the front side of
the metal frame.
G
