- Page 1 EDS30 Portable Integrated Docking Station User Manual Hytera Communications Corporation Limited...
- Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. To derive optimum performance from the product, please read this manual carefully before use. This manual is applicable to the following product: EDS30 Portable Integrated Docking Station...
-
Page 3: Icon Conventions
: indicates tips that can help you make better use of your product. Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names. -
Page 4: Fcc Radiation Exposure Statement
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a different circuit to that of the receiver's outlet. Consult the dealer or an experienced radio/TV technician for help. ... -
Page 5: Eu Regulatory Conformance
le fonctionnement de 5150-5350 MHz est limité à une utilisation en intérieur uniquement. EU Regulatory Conformance As certified by the qualified laboratory, the product is in compliance with the essential requirements and other relevant provisions of the following directives: 2006/66/EC ... -
Page 7: Packing List
1. Packing List Unpack carefully and check that you have received the following items. If any item is missing or damaged, contact your dealer. Item Qty. (PCS) Item Qty. (PCS) Docking Station WLAN Antenna Power Cord Documentation Kit Network Cable Disk Figures in this manual are only for reference. -
Page 8: Product Overview
2. Product Overview 2.1 Product Layout Slot Display Network Port Power Inlet WLAN Antenna Port USB Port Power Button 2.2 Specifications Item Description Dimensions (H x W x D) 435 mm x 298 mm x 110 mm Weight 9 ± 0.5 kg 10.1-inch touchscreen LCD Display Resolution: 1280 x 1080... - Page 9 Item Description Memory 8 GB System SSD 128 GB 4 TB, supporting redundant array of independent disks (RAID) Hard Disk Capacity backup USB Port 2 x USB 3.0 RJ45 Gigabit port Network Port WLAN 2.4G/5G, 802.11a/b/g/n/ac Power Supply 220 V AC, 300 W, supporting 115 V to 230 V –10°C to 55°C Operating Temperature Operating Noise...
-
Page 10: Before Use
3. Before Use 3.1 Connect the Power Cord Power Cord 3.2 Access the Network To access the network, do either of the following: Insert the network cable into network port on the back of the product. Install a WLAN antenna. ... -
Page 11: Basic Operations
4. Basic Operations 4.1 Turn On or Off the Product Press the Power Button. 4.2 Log In to the Account You can perform the related operations only after login. In the upper right corner, tap In the displayed Login interface, enter the user name and password. The initial username is "admin", and the initial password is "99999999". -
Page 12: Set Ports
DEM Address automatically uploads evidence files. Safe Mode needs to be checked when the DEM server is in safe mode. Hytera provides the trial certificate "dem.cer". You can Safe Mode also buy the certificate from Certificate Authority if necessary. To import the certificate, tap Certificate. - Page 13 is connected, so that you can quickly find the BWC. This operation is available only to the "admin" user. In the upper right corner, tap , and then select the Port Settings tab. Set the total number of ports in Maximum Ports, and then tap Change. Connect the BWC to physical ports of the product from left to right.
-
Page 14: Manage Users
Tap OK. 4.6 Manage Users The "admin" user can manage common users, including adding the user, resetting the password, and deleting the user. This operation is available only for the "admin" user. 4.6.1 Add the User In the upper right corner, tap , and then select the User tab. - Page 15 Tap Add. Set the following parameters. Parameter Description Serial number and unique identifier of a BWC. Officer ID ID of the officer using the BWC. Officer Name Name of the officer using the BWC. Tap OK. 4.7.2 Import the Device You can import BWCs in batches.
- Page 16 Choose the file save path and enter the file name. Tap Save. Send the key license application file to Hytera to obtain the license. 4.8.2 Import the License Ensure that you have obtained the license file (in .license format) and plugged the dongle to the product.
-
Page 17: Data Acquisition
5. Data Acquisition After the BWC is connected to the product, the product will automatically acquire data from the BWC. -
Page 18: More Functions
6. More Functions For more details of the product functions, refer to Hytera IDS Operation Guide. To obtain the manual, tap in the upper right corner, and then tap... -
Page 19: Toubleshooting
7. Toubleshooting Phenomena Analysis Solution Disconnect the product from the power supply, clean the connecting finger of the The memory module and the memory module with an eraser, and then main board may have a poor re-insert the memory module. contact. - Page 20 Phenomena Analysis Solution After power-on, the product displays "Reboot and Select Solid State Disk (SSD) may proper Boot device or Insert be faulty so that the product Replace the SSD. Boot Media in selected Boot cannot detect the SSD. device and press a key". The product failed to acquire The BWC may be inserted Remove the BWC, and then insert it into the...
-
Page 21: Care And Cleaning
8. Care and Cleaning To guarantee optimal performance as well as a long service life of the product, please follow these tips. Product Care Do not pierce or scrape the product. Keep the product far away from substances that can corrode the circuitry. ... - Page 22 Hytera Communications Corporation Limited. © 2022 Hytera Communications Corporation Limited. All Rights Reserved. Address: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People's Republic of China Postcode: 518057 https://www.hytera.com...
