EDS50 Wall-mounted Docking
Station
User Manual
Hytera Communications Corporation Limited

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDS50 and is the answer not in the manual?

Questions and answers

Related Manuals for Hytera EDS50

Summary of Contents for Hytera EDS50

  • Page 1 EDS50 Wall-mounted Docking Station User Manual Hytera Communications Corporation Limited...
  • Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. To derive optimum performance from the product, please read this manual carefully before use. This manual is applicable to the following product: EDS50 Wall-mounted Docking Station...

  • Page 3: Icon Conventions

    : indicates tips that can help you make better use of your product. Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names.

  • Page 4: Packing List

    1. Packing List Unpack carefully and check that you have received the following items. If any item is missing or damaged, contact your dealer. Item Qty. (PCS) Item Qty. (PCS) Docking Station WLAN Antenna Power Cord Bracket Network Cable Disk M8 x 60 mm Expansion Bolt Documentation Kit Figures in this manual are only for reference.

  • Page 5: Product Overview

    Mortise Power Switch 2.2 Specifications Item Description  Main EDS50: 507 mm x 459 mm x 117 mm Dimensions (H x W x D)  Extended EDS50: 507 mm x 205 mm x 117 mm  Weight Main EDS50: 15.6 kg...
  • Page 6 Item Description  Extended EDS50: 7.8 kg  13.3-inch LCD touchscreen LCD Display  Resolution: 1920 x 1080 Quantity of Inserted BWCs Dual-core, Intel 3855U, 1.6 GHz Memory 8 GB Hard Disk Capacity 4 TB USB Port 2 x USB 2.0...

  • Page 7: Before Use

    Install the Main EDS50 Fix the bracket on the wall through expansion bolts. Align the hang holes on the back of the main EDS50 with the protrusions on the bracket. Gently slide the host straight down until it locks in place.
  • Page 8 Fix the bracket on the wall through expansion bolts. On the left side of the main EDS50, unscrew the two screws on the aluminum panel, and then remove this panel. Align the hang holes on the back of the extended EDS50 with the protrusions on the bracket.

  • Page 9: Connect The Ground Wire

    ) with proper length, and then install OT terminals at both ends of the wire. The metal wires must be completely sealed. Connect the OT terminal at one end of the wire to the M6 grounding stud of the EDS50, and the OT terminal at the other end to the internal grounding bar.
  • Page 10 3.5 Access the Network To access the network, do either of the following:  Insert the network cable into the network port of the EDS50.  Install a WLAN antenna.

  • Page 11: Basic Operations

    4. Basic Operations 4.1 Turn On the Product Connect the product to the power supply. Toggle the Power Switch to on (I) position. Press the Power Button. 4.2 Turn Off the Product Press the Power Button. Toggle the Power Switch to off (O) position. 4.3 Log In to the Account You can perform the related operations only after login.
  • Page 12 If the product remains idle for more than ten minutes, it will automatically log out. 4.5 Set Data Acquisition Parameters You can set the parameters that are used to acquire digital evidence from BWCs by the product and the Digital Evidence Management (DEM).

  • Page 13: Set Ports

    Module Parameter Description  Important: Only the marked digital evidence will be uploaded.  Not important: Only the unmarked digital evidence will be uploaded. Days of Electronic Not Important Set the retention time for unmarked digital evidence. Evidence Important Set the retention time for marked digital evidence. Preservation Tap OK.

  • Page 14: Manage Users

    (Optional) Select a port, and then select Preferred. The product will first acquire data from the BWC connected to this port and suspend data acquisition from other ports automatically. After the data acquisition from this port completes, other ports resume. Tap OK.

  • Page 15: Manage Devices

    Tap OK. 4.7.2 (Optional) Add the Fingerprint The "admin" user can add the fingerprint for himself and common users. Then the "admin" user and common users can log in to the product by the fingerprint. In the upper right corner, tap , and then select the User tab.
  • Page 16 Set the following parameters. Parameter Description Serial number and unique identifier of a BWC. Officer ID ID of the officer using the BWC. Officer Name Name of the officer using the BWC. Tap OK. 4.8.2 Import the Device You can import BWCs in batches. In the upper right corner, tap , and then select Devices tab.
  • Page 17 In the Edit dialog box, edit the BWC and officer information. Tap Parameters. 4.9 Manage Officers 4.9.1 Add the Officer In the upper right corner, tap , and then select Officer Management tab. Tap Add. In the New Officer dialog box, fill in the following parameters. Parameter Description Officer ID...

  • Page 18: Acquire Data

    Choose the file save path, and then enter the file name. Tap Save. Send the key license application file to Hytera to obtain the license. 4.10.2 Import the License Ensure that you have obtained the license file (in .license format) and plugged the dongle to the product.

  • Page 19: More Functions

    Close the BWC pocket door. 4.12 More Functions For more details of the product functions, refer to Hytera IDS Operation Guide. To obtain the manual, tap in the upper right corner, and then tap...

  • Page 20: Troubleshooting

    5. Troubleshooting Phenomena Analysis Solution Turn on the product, and then press the DEL key to enter the BIOS. The product fails to be turned The BIOS startup item may In the Boot tab, set the first startup item to on after the USB flash drive or be set incorrectly.
  • Page 21 Phenomena Analysis Solution The product shows a partially The display may Replace the display. blurred screen. malfunction. The product fails to acquire The BWC may be inserted Remove the BWC, and then insert it into the the digital evidence from the improperly into the slot of slot of the product again.

  • Page 22: Care And Cleaning

    6. Care and Cleaning To guarantee optimal performance as well as a long service life of the product, follow these tips. Product Care  Do not pierce or scrape the product.  Keep the product far away from substances that can corrode the circuitry. ...
  • Page 23 5150-5350 MHz est limité à une utilisation en intérieur uniquement is the trademark or registered trademark of Hytera Communications Corporation Limited. © 2022 Hytera Communications Corporation Limited. All Rights Reserved. Address: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People's Republic of China Postcode: 518057...
