Summary of Contents for Echowell echoNET3

  • Page 2: Table Of Contents

    Table of Contents Table of Contents / Package content ················· 1. Front view ·········································· 2. Rear view ··········································· 3. 1. Internet Radio Mode ······························ 5. 2. Podcasts Mode ···································· 11. 3. Spotify Connect ·································· 13. 4. DAB/DAB+ mode ··································· 14. 5.
  • Page 3 Front Panel 1. Speaker 8.BACK 2. Display 9.INFO 3. Preset 1 / Play / Pause 10. ALARM 4. Preset 2 / Back 11. MODE 5. Preset 3 / Forward 12.POWER 6. PRESET 13 TUNING / SELECT 7. MENU 14.VOLUME / SNOOZE...
  • Page 4 Rear Panel 15. Antenna 16. Headphone 17. LINE OUT 18. AUX IN 19. DC power supply (DC 12V/1.5A) Control Butto Mode Radio mode: Press and hold this button to store the radio station a s preset 1 when the radio station is playing. In Bluetooth mode, you can press this button to enter Bluetooth Pla y/Pause.
  • Page 5 In Spotify connect , you can press this button to enter next track Playback. PREST Press for the Preset recall/Save menu Show menu for the current mode. Press again to show Now playing scr een. MENU Menu settings: In any mode, press this button to enter the system menu or other op tions, press this key again to return to the setting mode.
  • Page 6 c. Turn to adjust the volume up or down...

  • Page 7: Internet Radio Mode

    Internet co nnection. When you select Internet radio mode, echoNET3 Radio contacts the Frontier Smart Technologies Internet radio portal to get a list of station s, organized into different categories like Country, and Popular. Once you select a station, echoNET3 connects directly to that station To enter Internet Radio mode, either press "MODE"...
  • Page 8 ② The station list menu is provided from the Internet radio portal, so it is only accessible when echoNet3 is connected to the Internet. Sta tion lists and submenus will change from time to time. The Station lis t is organized into various categories and search facilities: •...
  • Page 9 select a country and the available inter net radio stations are presented. Choose a radio station from the list to tune to that station. 1.3.4 Popular Presents a list of the most popular in ternet stations from around the world. 1.3.5 Discover Allows you to select from a list of stations defined by either the ir origin (Country), Genre (style of music) or language.
  • Page 10 PC, connected to your network. To connect to the web page enter the echoNET3 unit’s IP address into your web browser. To view the IP address, on the echoNET3 M ENU system, navigate to: MENU > System Settings > Network > View Settings –...
  • Page 11 ough the play button is not available on the Embedded web-page the blank preset can still be selected from the local User Interface. Internet Radio/podcast preset names should only use alphanumeric characters and not include any special characters (!”£$%^&*()_ +…etc.). Note: The presets displayed on the embedded web page are those for the cu rrent mode being used on the VeniceX device.
  • Page 12 1.5.3 Report tab This tab allows users to store and view incident reports. The repo rts are generated by pressing the RFU button on the Venice X devic e or alternatively using the Create button on the Report tab. Repo rts contain the following information: •...

  • Page 13: Podcasts Mode

    Frontier Smart Technologies Podcast portal to get a list of available podcasts. Once you select a podcast, echoNET3 radio connects directly to that podcast source. To enter Podcast mode, either press "MODE" to cycle through the listening m odes until Podcasts is displayed, or select "...
  • Page 14 dcast lists and submenus may change from ti me to time. The Podcast list is organized into search categories: • <Local area> - dependent on radio device’s location, for example: • Search • Location • Discover. 2.3.1 <Local area> - dependent on radio device’s location, for exam ple: UK Presents a sub-menu for local area podcasts.

  • Page 15: Spotify Connect

    on >. Select a continent from the menu and a list of countries available is presented, select a country and the available podcasts are pr esented. Choose a podcast from the list to tune to that podcast. 2.3.4 Discover Allows you to select from a list of podcas ts defined by either their origin (Countr y), Genre (style of music) or language.

  • Page 16: Dab/Dab+ Mode

    4. DAB/DAB+ Mode 4.1 Power On 4.1.1 Extend the antenna on the back panel, and press the "POWER" button to turn on the ra dio. 4.1.2 When using for the first time, the ra dio will automatically perform a compl ete frequency scan and store the detec ted stations into memory.
  • Page 17 4.1.5 Once frequency scanning is completed, the DAB/DAB+ stations will be display ed in alphanumeric order, and the rad io will access the first station in t he list. 4.2 Switch to other DAB/DAB+ station During the playing of the program, press the "TUNING/SELECT" dial, the display screen will appear "Station list", you can switch between the available stations, or press "TUNING/SELECT"...
  • Page 18 4.6 Manual Tune (Manual Search) Stations can be selected manually. 4.6.1 Press the corresponding button or the dial "MENU → turn TUNING/SELECT→ Manu al Tune to enter Manual Tune option. 4.6.2 Press "TUNING/SELECT" to confirm the d esired option, and it will automaticall y enter the station.

  • Page 19: Fm Mode

    5. FM Mode 5.1 Tuning in FM Mode 5.1.1 Turn on the power, press the button "MODE → FM", it will autom atically enter this mode. 5.1.2 When using for the first time, the radio will start from FM 87. 50MHz, press the knob "TUNING/SELECT"...
  • Page 20 5.4 Radio Preset Settings (DAB/DAB+ and FM modes) Note: The setting method of "Radio station preset" and "Preset Recall" is appli cable to DAB/DAB+ and FM mode. 5.4.1 When playing your favorite radio station, press and hold the pr eset button "1" to store it as preset 1. When the user is playin g other radio frequencies, press the preset button 1 to automati cally recall preset 1 radio station.

  • Page 21: Bluetooth Mode

    In the MENU, find “Settings" b utton, click "Settings" → turn on“ B luetooth”→ find “Available Device “→ press “Available Device (device name: echoNET3 radio)”(Other players with Bluetooth systems ) Please refer to the instructions for Bluetooth pair ing of the player.

  • Page 22: Aux In Mode

    7. AUX IN Mode Note: The AUX IN jack can be quickly and easily connected to an MP3 player or other external audio sources. 7.1 Turn on the power, press "MODE→Auxiliary Input", it will automaticall y enter this mode. 7.2 After using the 3.5mm audio cable, your radio will output audio through i ts high-quality speakers.
  • Page 23 8.2 System Menu Settings 8.3 Equalizer 8.3.1 Equalizer Setting Note: Selecting an appropriate equalizer can help imp rove the sound quality of music played: 8.3.1.1 In any mode, press “MENU → System set tings → Equalizer”. 8.3.1.2 Press "TUNING/SELECT" to select the desired option (Normal/Flat/Jazz/Rock/Movie/Classic/Pop/News/MyEQ/My EQ p rofile Setup）...
  • Page 24 Wi-Fi Protected Setup (WPS). To connect echoNET3 radio to your network, you need one of the followi • A Wi-Fi wireless router, together with passphrase key, if setTo sel...
  • Page 25 Those options starting with WPS in brackets indicates encrypted net works offering Wi-Fi Protected Setup (WPS) options. 8.5.2 Wi-Fi network (SSID), select a network from the list. 8.5.3 If the network is open (non-encrypted), echoNET3 radio connects and no further details are required; 8.5.4 Standard encrypted network If the wireless network is protected the next screen presents opt ions to enter the network key or passphrase.
  • Page 26 To exit the process use the Back/MENU butto • Pin > (code number) echoNET3 radio generates an 8-digit code numb er which you enter into the wireless router, access point. • Skip WPS > Enter key as for a standard encrypted network, above V...
  • Page 27 EchoNET3 radio remotely over a network. 8.5.9 Network profile This displays a list of the networks remembered by EchoNET3 (up to a maximum of 4). You can see the list of registered networks throug h MENU > System settings > Network > Network profile >. From here y...
  • Page 28 8.7 Inactive Standby The radio is set default to turn off automatically after 120 minutes w ithout any manual operation of the radio. To deactivate Inactive stand by or to change the Timeout period: 8.7.1. In any mode, press “MENU → System settings →Inactive Standb y”...
  • Page 29 8.12 Setting up the connection to the echoNET3 After you download and install the UNDOK Wireless application you must set up a connection between the Phone and the echoNET3 Radio . follo w these steps: 8.12.1 On the echoNET3 Radio , press to MENU → System settings → Netwo rk→...

  • Page 30: Software Update

    You can either check manually, o r set echoNET3 to check periodically automatically (this is the defaul t). If echoNET3 detects that newer software is available, it asks if y ou want to go ahead with an update. If you agree, the new software is then downloaded and installed.
  • Page 31 and after (Dim level) the timeout period. • For the On level, High, Medium and Low, plus an Auto setting are a vailable. • For the Dim level, Medium, HIGH, Low, plus an Auto setting are ava ilable. 9.4 Sleep To set the sleep timer, select MENU >...
  • Page 32 5/10 minutes, or repeatedly press this knob for a lon ger snooze. Note: In general, power suppliers should not be plugged in at night or when you are not home. All Echowell Audio products are CE approved and certified".

  • Page 33: Specifications

    10. Specifications Items Specifications Function description Internet Radio / Podcasts / Spotify / DAB / DAB+ / FM / Bluetooth / AUX in / Alarm / Sleep / Clock/ UNDOK Wireless Remote Amplifier Rated Output Po 7W RMS@1%THD 3" MONO Full Range Driver, 4 ohms speaker FM: 87.5-108MHz Frequency Range...
