REVOLUTION
TM
2
BURNER
ASSEMBLY MANUAL
RV-201BBQ (G36361)
LIMITED 5-YEAR WARRANTY
Read and save manual for future reference.
Assemble your grill immediately. Missing or damaged parts
should be claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-800-249-2506.
ANS Z21.58-2018 / CS
ANS Z21.58-2018 / CSA 1.6-2018
ANS Z21.58-2018 / CSA 1.6-2018
ANS Z21.58-2018 / CSA 1.6-2018
Master No. 211648
Manual Revision #: 2023.12.13 MK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REVOLUTION RV-201BBQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Coleman REVOLUTION RV-201BBQ

Summary of Contents for Coleman REVOLUTION RV-201BBQ

  • Page 1 REVOLUTION BURNER ASSEMBLY MANUAL RV-201BBQ (G36361) LIMITED 5-YEAR WARRANTY Read and save manual for future reference. Assemble your grill immediately. Missing or damaged parts should be claimed within 30 days of purchase. For product inquiries, parts, warranty and troubleshooting support, please call 1-800-249-2506.

  • Page 2: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS THIS MANUAL MUST REMAIN WITH THIS PRODUCT AT ALL TIMES CAUTION DANGER Read and follow all safety statements, 1. If you smell gas: assembly instructions, use and care directions a. Shut off gas to the appliance. before attempting to assemble and cook. b.

  • Page 3: Hardware Pack

    HARDWARE PACK TOOLS NEEDED FOR ASSEMBLY Description Part Number Qty. • #2 Phillips screwdriver (long and short) 1/4"-20UNCx38 Screw 20120-13038-250 1/4"-20UNCx16 Screw 20120-13016-250 • 1/4” Slotted screwdriver (long and short) 1/4''-20UNC Screw G353-0014-9000 • Adjustable wrench NO.10-24UNCx13 Screw 20124-10013-250 • Pliers NO.8-32UNCx18 Screw 20132-08018-250 NO.8-32UNCx10 Screw...
  • Page 4 PARTS LIST FOR RV-201BBQ (G36361) Item Item Qty. Description Part No. Qty. Description Part No. Top Lid Assembly G363-2500-01 Side Shelf Table G363-0800-01 Lid Handle G363-0005-02 Side Shelf Fascia, Left G363-8600-01 Thermometer G363-0009-01 Side Shelf Table Rear Brace, G363-1000-01 Thermometer Bezel G532-0006-01 Left Screw, Top Lid...
  • Page 5 EXPLODED DIAGRAM FOR RV-201BBQ (G36361) Extras Assembly Safe Use Manual & Care Hardware Manual Pack...
  • Page 6 ASSEMBLY INSTRUCTIONS 6 1 2...
  • Page 7 ASSEMBLY INSTRUCTIONS...
  • Page 8 ASSEMBLY INSTRUCTIONS...
  • Page 9 ASSEMBLY INSTRUCTIONS...
  • Page 10 ASSEMBLY INSTRUCTIONS...
  • Page 11 ASSEMBLY INSTRUCTIONS WARNING: WATCH YOUR HANDS!
  • Page 12 ASSEMBLY INSTRUCTIONS TIP: Ensure that the rubber side of the rubberized washer makes contact with the burner box.
  • Page 13 ASSEMBLY INSTRUCTIONS...
  • Page 14 ASSEMBLY INSTRUCTIONS TIP: Ensure that the rubber side of the rubberized washer makes contact with the burner box.
  • Page 15 ASSEMBLY INSTRUCTIONS...
  • Page 16 ASSEMBLY INSTRUCTIONS...
  • Page 17 ASSEMBLY INSTRUCTIONS Electronic Ignition Wire Assembly The electrode wires for main burner electrode set (CC), instastart button (CE3) can be found under the control panel (CG), attached to the manifold (CA). Insert them and the ground wire (CE4) into the electronic ignition (CE1). Insert one “AA” battery into the compartment with the positive end facing outward.
  • Page 18 ASSEMBLY INSTRUCTIONS...
  • Page 19 ASSEMBLY INSTRUCTIONS TIP: Ensure that the rubber side of the rubberized washer makes contact with the burner box.
  • Page 20 ASSEMBLY INSTRUCTIONS...
  • Page 21 ASSEMBLY INSTRUCTIONS Support Bracket A Support Bracket B (DF) (DG) Support Bracket A Support Bracket B (DF) (DG)
  • Page 22 ASSEMBLY INSTRUCTIONS...
  • Page 23 ASSEMBLY INSTRUCTIONS...
  • Page 24 ASSEMBLY INSTRUCTIONS...
  • Page 25 ASSEMBLY INSTRUCTIONS ATTENTION: YOUR MODEL includes the CONVERTIBLE Before completing steps 16 to 21, follow VALVE SYSTEM™. If you would like to the steps outlined in the CONVERTIBLE convert your barbecue from PROPANE to VALVE SYSTEM™ instruction manual that NATURAL GAS, the following kit is required accompanied the kit.
  • Page 26 ASSEMBLY INSTRUCTIONS...
  • Page 27 ASSEMBLY INSTRUCTIONS ATTENTION: STACK GRATES BEFORE POSITIONING. Upper Cooking Grate: BF - Porcelain Cast Iron Cooking Grate Lower Cooking Grate: BK - Stamped Steel Cooking Grate...
  • Page 28 ASSEMBLY INSTRUCTIONS...
  • Page 29 ASSEMBLY INSTRUCTIONS FOR PROPANE MODEL ONLY. FOR NATURAL GAS MODEL, FOLLOW STEP 21.
  • Page 30 ASSEMBLY INSTRUCTIONS HOW TO CONVERT YOUR GRILL TO NATURAL GAS This grill is sold propane-ready. To convert it to natural gas, purchase the Coleman Convertible Valve System Kit.

  • Page 31: Additional Warnings

    ADDITIONAL WARNINGS You have now completed the assembly of your Coleman® Revolution™ grill. NEXT STEPS: 1. Position your Grill 2. Read Safe Use & Care Manual 3. Perform Grill Safety Check-list WARNING: WARNING HOT SURFACES: FOR YOUR FAMILIES SAFETY, DO NOT ATTEMPT TO LIGHT...
