EV E N HEAT ™
Includes: 1X Burner, 1X Screw, 1X M4 Wing Nut, 1X Lock Washer
Care And Safety INSTRUCTIONS
EXACT FIT FOR COLEMAN
2010
85-3026-0 (G52201), 85-3027-8 (G52202), 85-3028-6 (G52203), 85-3029-4 (G52204)
2011/ 2012
85-3046-2 (G35301), 85-3047-0 (G35302), 85-3026-0 (G52205), 85-3027-8 (G52206),
85-3028-6 (G52207), 85-3029-4 (G52208), 85-3046-2 (G35303), 85-3047-0 (G35304),
85-3026-0 (G52209), 85-3027-8 (G52210), 85-3028-6 (G52211), 85-3029-4 (G52212)
2013
85-3066-4 (G35305), 85-3067-2 (G35306), 85-3068-0 (G52215), 85-3069-8 (G52216),
85-3074-4 (G52217), 85-3075-2 (G52218), 85-3076-0 (G53101), 85-3077-8 (G53102)
2014
85-3066-4 (G35305), 85-3067-2 (G35306), 85-3068-0 (G52220), 85-3069-8 (G52221),
85-3092 (G52222), 85-3093-8 (G52223), 85-3076-0 (G53103), 85-3077-8 (G53104)
2015
85-3066-4 (G35308), 85-3067-2 (G35309), 85-3068-0 (G52227), 85-3069-8 (G52228),
85-3092-0 (G52229), 85-3093 (G52230), 85-3076 (G53103), 85-3077 (G53104)
2016
85-3066 (G35308), 85-3067 (G35309), 85-3076 (G53103), 85-3077 (G53104)
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
The Coleman
®
Coleman
Even Heat™ Barbecues ONLY. This product will replace the original
®
Even Heat™ burner sold with your Coleman
BURNER
PART NUMBER: 85-1978 (G522-B600-02)
Even Heat™ Burner is designed and intended for use with
www.colemanbbqs.com
DURABILITY • POWER • PERFORMANCE
EVEN HEAT™ MODELS:
®
Even Heat™ Barbecue.
®
Manual Revision #: 01022018 PD
