BEKA Schreder LEDFLOOD MIDI Installation Instructions

LEDFLOOD
MIDI / MAXI
The light source fitted in this luminaire shall only be
replaced by a BEKA Schréder employee or agent or a
ENG
similar qualified person. This luminaire is installed above
5 meters. The glass cover will fracture into small pieces.
CAUTION - RISK OF ELECTRIC SHOCK
13
Please note: Tools are not included
MIDI
60mm
Weight (kg)
Mounting height (m)
Mounting position
CxS (m )
2
SANS
60598
La source de lumière intégrée dans ce luminaire peut
uniquement être remplacée par un employé de
FRA
BEKA Schréder, un agent ou une autre personne qualifiée.
Ce luminaire est installé au dessus de 5 mètres. La
couverture en verre se fracturera en petits morceaux.
CAUTION - Possibly hazardous optical radiation emmited from this product. Do not stare at operating lamp.
May be harmful to eyes. The luminaire should be positioned so that prolonged staring into the luminaire at a
4
16
MIDI
10.5
Up to 15m
Horizontal & Vertical
0.11
IP 66 198-264V - 50Hz
RISK GROUP 2
distance closer than 1.9m is not expected.
4x 0.5 PH2
MAXI
Weight (kg)
Mounting height (m)
Mounting position
CxS (m
A fonte de luz montada nesta luminária só pode ser
substituída por um funcionário ou agente da BEKA Schréder
POR
ou por profissional qualificado autorizado para o efeito. Esta
luminária está instalada acima de 5 metros. A tampa de vidro
irá fraturar em pequenos pedaços.
Recommended
fixation bolt
M16
Gr8.8 Zinc plated
120 N.m.
MAXI
16.5
Up to 30m
Horizontal & Vertical
) 0.18
2
M16 Hex Screw
M16 Spring
Washer
M16 Body
Washer (Large)
