Multitool MT482-8 Installation Instructions

Installation Instructions for Belt Grinder Model MT482-8
!
MULTITOOL GRINDERS IS NOT RESPONSIBLE FOR ANY DAMAGES OR INJURIES INCURRED
WARNING: To avoid mistakes that could cause injury, do not use the Multitool until you have
read and understood the following:
1. ALWAYS WEAR EYE PROTECTION. A full-face visor is preferred. Any Belt/Disc Grinder can throw foreign objects into the eyes.
2. AVOID CONTACT WITH BELT OR DISC. The abrasive belt when running is an aggressive cutting tool. Extra care should be
exercised when using coarse grit belts because of their rapid cutting action.
3. KEEP CHILDREN AWAY. All visitors should be kept a safe distance from the work area.
4. BOLT THE BENCH GRINDER securely to the bench or supporting surface to stop it from tipping over or moving when in use.
5. DO NOT MOUNT the attachment protruding into walkways.
6. KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
7. ALWAYS WEAR A DUST MASK to prevent dust inhalation when adequate ventilation or extraction is not available.
8. DO NOT WEAR LOOSE CLOTHING which may become entangled in the machine. Wear protective hair covering to contain
long hair.
9. ALWAYS HOLD the work piece firmly when grinding and apply a light and steady pressure against abrasive disc or belt.
10. ALWAYS GRIND ON THE DOWNWARD SIDE of the grinding disc. Grinding on the upward side of the disc could cause the
work piece to fly out of position, resulting in injury.
11. DO NOT USE BELTS THAT ARE DAMAGED, TORN, OR SHOW SIGNS OF WEAR.
12. ALWAYS INSTALL BELTS with arrows in the back of the belts pointing the correct direction. Belts with lap joints must be
fitted facing the correct direction.
The words "us", "we" or "our" refers to Multitool Grinders or
their authorized agent.
A.) The warranty will only apply if the fitting and operating
instructions are followed.
B.) The warranty will only apply for a period of 1 year from the
date of original purchase against any defect in our product,
which can be proved, to our satisfaction to have been caused
by faulty materials or workmanship. Our liability is limited
to the cost of repairing or at our option, replacement of the
defective goods or parts of the goods. We will not be liable for
any defect caused by unauthorized repair.
Hardware Kit
(Refer to this image for numbered
hardware throughout the instructions)
For parts, tech support, belts, or discs contact Multitool Grinders at 641-628-4253 or sales@multitoolgrinders.com
SAFETY INSTRUCTIONS
USER IS RESPONSIBLE TO HAVE WORKING KNOWLEDGE OF BELT GRINDER USAGE.
WHILE USING THE MULTITOOL PRODUCT LINE.
WARRANTY AND CONDITIONS OF SALE
CONTENTS
INSTRUCTIONS TO FOLLOW FOR WARRANTY CLAIMS:
1. If warranty claim is made, we must be notified as soon as
possible after assumed defect has become apparent.
2. Goods may only be returned with the approval and RGA # from
Multitool Grinders. Contact Multitool Grinders at 641-628-4253 or
email us at sales@multitoolgrinders.com to obtain RGA# and
return approval.
3. The customer must prepay all freight charges for returned goods.
4. We will contact the customer with a suggestion after inspecting
the goods to determine with the customer what action should be
taken in the circumstances.
Tensioner Arm Belt and Disk
