Summary of Contents for Global Pool Products TSUNAMI
- Page 1 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” TSUNAMI ASSEMBLY & INSTALLATION GUIDE www.global-poolproducts.com Page | 1...
- Page 2 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” TSUNAMI SLIDE TABLE OF CONTENTS Introduction PAGE - 3 Tsunami Post Installation Instructions PAGE - 4 Maintenance Instructions PAGE - 4 Tsunami Slide Placement/Stub Up PAGE –...
- Page 3 Examine all parts thoroughly prior to installation to avoid anything that may have been damaged in transit. A damaged part should not be used in the installation of this slide. Contact Global Pool Products if any parts arrived damaged. Proper assembly and installation of the Tsunami Slide is imperative. Not following the directions provided will void Global Pool Products Warranty and may affect the safety of the slide rider.
- Page 4 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” POST INSTALLATION CHECKLIST FOR TSUNAMI SLIDE Installer to review with slide owner upon completion of slide installation. Examine: The flume for any apparent cracks or gashes.
- Page 5 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Tsunami Slide Placement/Stub-up Location Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to...
- Page 6 This slide is intended for use on in-ground residential swimming pools ONLY. Our multi point anchoring system allows the Tsunami to accommodate most geographical regions. The slide is rated for a maximum of 275 lb. (124 kg) for its riders.
- Page 7 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Tsunami Slide Specifications Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to P: 989-269-5900 - TF: 866-712-0606...
- Page 8 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Tsunami Slide Specifications Global Pool Products 1330 Pigeon Rd Bad Axe, MI 48413 Information contained in this document is proprietary and confidential to P: 989-269-5900 - TF: 866-712-0606...
- Page 9 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” TSUNAMI ASSEMBLY INSTRUCTIONS Tools Needed: 1. 3/16” Allen Wrench PTFE (Teflon) Tape 10. 5/8” Deep Well Socket 2. 7/32” Allen Wrench PTFE (Teflon) Paste 11.
- Page 10 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Prior to the Start of Assembly: o Utilize the cardboard that the slide shipped in as a barrier between your slide components and the surface that the slide is being assembled on to prevent any scuffs and scratches.
- Page 11 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” 4. Attach the upper flume to the lower flume assembly, first with the one (1) 2” Button-head bolt on the upper attachment point and one (1) 2 1/4” Button-head bolt in the inner spindle.
- Page 12 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” 9. Insert two (2) 2 ¾” studs to the upper portion (lower 2 threaded inserts) of the Upper Ladder section of the slide and two (2) 2 ¼” Studs in the upper threaded holes.
- Page 13 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” 12. Merge the Flume assembly to the Ladder assembly using the studs to aide in the connection. 13. Attach the two assemblies with two (2) 3/8” acorn nuts at the upper connection point and two (2) Hex nuts at the lower stud location apply in this order: washer, lock washer then attach with 3/8”...
- Page 14 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” 15. Pull the lighting wires and flex hose through the bottom 6” hole at the underside base of the ladder. Please consult with a local electrician to conform to your area’s codes and regulations on bonding and electrical hook-up.
- Page 15 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” ON-DECK MOUNTING & PLUMBING INSTRUCTIONS Required Tools ½” SDS Concrete Bit Hammer Hammer Drill Shop-vac Center Punch (Marking Tool) 4 ¾” Hole Saw (for garden hose hook-up option) Included Hardware ½”...
- Page 16 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” a. Clean flex hose from slide and stub-up plumbing prior to assembling. b. Use PVC Primer & PVC Glue to adhere plumbing components from the slide and stub-up plumbing together 9.
- Page 17 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Page | 17...
- Page 18 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Page | 18...
- Page 19 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” Page | 19...
- Page 20 “Global Pool Products is committed to engineering and manufacturing world class products in the pool industry” * Hardware attaches through access plate on back side of ladder section *GPP-B375x75HHCS 3/8” x ¾” Hex Bolt QTY. 4 *GPPBW375 WASHER QTY. 4...
