INTERODUCTION
This document gives the information about the outdoor antenna installation with the Wire
Free WAP-1000 Access Point. The directional antennas are used to link two Access Point
between two places such as two buildings.
1.PC 2415N
SPECIFICATIONS for PC2415N
Antenna
Band Width:
Gain:
VSWR:
Beam Width:
Weight:
Size:
Cable
Length:
Cable Loss:
Assembly Loss:
Connector:
Note:
N(M) : N type connector with MALE pin
N(F) : N type connector with FEMALE pin
SMA(M/R) : SMA type MALE connector with FEMALE pin (reverse polarity)
2.18T-2400
SPECIFICATIONS for 18T-2400
Antenna
Input Frequency
Gain
-3db Beam Width
Front to back Ratio
VSWR (average)
Impedance @ output
11F, No. 96 Min Chuan Road, Hsin Tien, Taipei,Taiwan, R.O.C. Tel: 886-2-2219-9518
DIRECTIONAL ANTENNA
2.4~2.5 GHz
16 dBi
1.5:1
E 30º H65º
< 1 lb.per unit
22x2 in
20ft. (4m)
1.66 dB
2.16 dB
N(M) - SMA(M/R)
2.4GHz~2.5GHz
18dBi
14°
>23dB
1.3:1
50Ω
PLANET Technology Corporation
Email: Sales@planet.com.tw
30ft. (10m)
2.18 dB
3.305 dB
N(M) - N(F)
With a 1 ft jumper
N(M) -SMA(M/R)
Web Site: http://www.planet.com.tw
Fax: 886-2-2219-9528
