Echo PB-2520 Operator's Manual

Power blower
Hide thumbs Also See for PB-2520:
Table of Contents

Advertisement

Quick Links

Download this manual
1Top cover
OPERATOR'S MANUAL
READ THE INSTRUCTIONS CAREFULLY AND FOLLOW THE
RULES FOR SAFE OPERATION.
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY.
POWER BLOWER
WARNING
ENGLISH
(Original instructions)
PB-2520

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-2520 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo PB-2520

Summary of Contents for Echo PB-2520

  • Page 1 1Top cover ENGLISH (Original instructions) OPERATOR'S MANUAL POWER BLOWER PB-2520 WARNING READ THE INSTRUCTIONS CAREFULLY AND FOLLOW THE RULES FOR SAFE OPERATION. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY.
  • Page 2  Always keep your manual in a place where it is readily accessible.  If you have lost your manual or it is damaged and no longer readable, please purchase a new one from your ECHO DEALER.

  • Page 3: Table Of Contents

    Contents For safe use of your product....................4 Warning notices ......................4 Other indicators ......................4 Symbols ......................... 4 Location in which the safety decal is attached............... 6 Handling fuel........................7 Handling the engine....................... 8 Handling the product ..................... 9 Packing list........................

  • Page 4: For Safe Use Of Your Product

    For safe use of your product For safe use of your product Be careful to read this section before using your product.  The precautions described in this section contain important safety information. Please observe them carefully.  You must also read the precautions that appear in the body of the manual itself. Text following a [diamond mark] mark describes the potential consequences of failing to observe the precaution.
  • Page 5 For safe use of your product Symbol form/shape Symbol description/applica- Symbol form/shape Symbol description/applica- tion tion Choke Control "Run" Beware of fire Position (Choke Open) Guaranteed sound power lev- Beware of electric shocks Ignition Beware of high-temperature ON / OFF areas Engine start Keep bystanders away 15 m...

  • Page 6: Location In Which The Safety Decal Is Attached

     If the decal becomes unreadable due to wear and tear or damage, or peels off and is lost, please purchase a replacement decal from your ECHO DEALER and attach it in the location shown in the illustrations below. Ensure that the decal is readable at all times.

  • Page 7: Handling Fuel

     If you do find fuel leaks or discharges, stop using the  Tighten the fuel tank cap securely after refuelling. product immediately and contact your ECHO DEALER  Fuel spills can cause fire and burns when ignited. to have it repaired.

  • Page 8: Handling The Engine

    Do not use the product if there maintaining your product after use: are abnormal vibrations or sounds. Contact your ECHO  Turn the engine off and do not attempt to check or main- DEALER to have it repaired.

  • Page 9: Handling The Product

    For safe use of your product Handling the product General precautions WARNING Operator's manual Loaning or assigning your product  Be careful to read the operator's manual  When loaning your product to another party, ensure properly before using your product in or- that the person borrowing the product receives the op- der to ensure correct operation.
  • Page 10 For safe use of your product Precautions for use WARNING Users of the product Using the product The product should not be used by: When using the product, pay special attention to observe  people who are tired the following precautions. ...
  • Page 11 (RSI). Contact your ECHO DEALER for repair. To reduce the risk of RSI, do the following:  Continuing to use parts when they are damaged could lead ...

  • Page 12: Packing List

    Packing list  The following parts are packed separately in the packing box.  When you have unpacked the box, please check the parts that it contains.  Contact your ECHO DEALER if anything is missing or broken. Number Part name...

  • Page 13: Description

    Description Description 1. Stop switch "SLIDE SWITCH" mounted on top of handle. 9. Spark arrestor - Catalytic silencer / Silencer The silenc- Push forward to start and run. Slide back to stop. er or catalytic silencer controls exhaust noise and emis- 2.

  • Page 14: Before You Start

    Before you start Before you start Assembly WARNING  Read the operator's manual carefully to ensure that you assemble the product correctly.  Never perform maintenance or assembly procedures with engine running.  Using a product that has been incorrectly assembled could lead to an accident or serious injury. Install blower pipes Stand unit upright on blower base.

  • Page 15: Preparing The Fuel

    If you do find fuel leaks or discharges, stop using the product immediately and contact your ECHO DEALER to have it repaired.  If the fuel ignites, it could cause burns and fire.

  • Page 16: Engine Operation

    Engine operation Engine operation Starting the engine WARNING  When starting the engine, observe the precautions described from Page 4 in the section "For safe use of your prod- uct" to ensure that you operate the product correctly.  Failure to observe the precautions could cause an accident or injury, or even lead to a fatality. NOTE ...

  • Page 17: Stopping The Engine

    If engine does not stop when stop switch is moved to 1. Stop switch 2. Throttle position lever STOP position, close choke - position - to stall engine. 3. Throttle trigger Have your ECHO dealer repair stop switch before using blower again.

  • Page 18: Operation

    Operation Operation Operating blower WARNING Always wear safety glasses, hearing protection, face filter mask and take all safety precautions or serious personal in- jury may result. Do not point the blower pipe in the direction of people or pets. IMPORTANT To avoid engine damage due to over revving, do not block blower pipe opening.

  • Page 19: Maintenance And Care

    IMPORTANT Time intervals are maximum. Actual use and your experience will determine the frequency of required maintenance. Maintenance and care If you have any questions or problems, please contact your ECHO DEALER. Throttle connecting rod Tools required:None Parts required:Lithium based grease Remove spark plug cap from spark plug.
  • Page 20 Maintenance and care Cleaning air filter Tools required:25-50 mm (1-2 in.) Cleaning brush Parts required:Air filter Close choke ( ). This prevents dirt from entering the car- burettor throat when the air filter is removed. Brush accumu- lated dirt from air cleaner area. Release the filter cover latch, and remove air filter cover.
  • Page 21 Maintenance and care Carburettor adjustment CAUTION When there is trouble with the carburettor, contact your ECHO DEALER. Tools required: Screwdriver, tachometer Parts required: None NOTE Every unit is run at the factory and the carburettor is set in com- pliance with Emission Regulations. This carburettor does not have acceleration and high speed adjustment needles.
  • Page 22 The cylinder exhaust port must be inspected and cleaned of ex- cess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service.
  • Page 23 Maintenance and care Cleaning housing cover Remove dust of various sorts, including fallen leaves blocking the housing cover. IMPORTANT Do not remove the housing cover. If necessary, Please consult your dealer. 1. Housing cover Check spark plug Tools required: T-Wrench, Feeler gauge Parts required: Spark plug IMPORTANT Use only NGK BPMR8Y spark plug otherwise severe engine...

  • Page 24: Troubleshooting Table

    ECHO DEALER. Do not attempt to dismantle the product.  Consult your ECHO DEALER in the event of a problem that is not covered in the table above, or other such concerns.  For spare parts and consumables, please use only genuine parts and designated products and components. Using parts from...

  • Page 25: Long-Term Storage(30 Days Or More)

    Fit the spark plug. (Do not connect the spark plug cap. ) Remove blower pipe assembly from unit. 1. Spark plug 2. Spark plug cap Please contact your ECHO DEALER in order to dispose of the product or its parts in compliance with national laws.

  • Page 26: Specifications

    Do not use fuel containing methyl alcohol or more than 10 % of ethyl alcohol. Two stroke, air-cooled engine oil. ISO-L-EGD Stand- ard (ISO/CD 13738), JASO FC,FD grade and ECHO recommended oil. Ratio 50 : 1 (2%)

  • Page 27: Declaration Of Conformity

    OHME; TOKYO 198-8760 JAPAN This declaration of conformity is issued under the sole responsibility of the manufacturer. Declares that the hereunder specified new unit: POWER BLOWER Brand: ECHO Type: PB-2520 Assembled by: ECHO, INCORPORATED 400 Oakwood Road Lake Zurich, Illinois 60047-1564 U.S.A.
  • Page 28 7-2 SUEHIROCHO 1-CHOME, OHME, TOKYO 198-8760, JAPAN PHONE: 81-428-32-6118. FAX: 81-428-32-6145. Printed in Japan 0x0xxxx zzzz ES X750119-1600 © 2019...
