Panasonic LUMIX DMC-G6P Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Digital Camera
  5. LUMIX DMC-G6P
  6. Service manual

Panasonic LUMIX DMC-G6P Service Manual

Digital camera/body/lens kit/double zoom lens kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Digital Camera/Body/Lens Kit/Double Zoom Lens Kit
DMC-G6P
Model No.
DMC-G6PC
DMC-G6EB
DMC-G6EC
DMC-G6EE
DMC-G6EF
DMC-G6EG
DMC-G6GC
DMC-G6GN
DMC-G6HEB
DMC-G6HEC
DMC-G6HEE
DMC-G6HEF
DMC-G6HEG
DMC-G6WEB
DMC-G6WEC
DMC-G6WEE
DMC-G6WEF
DMC-G6WEG
DMC-G6WGC
DMC-G6WGH
DMC-G6WGK
© Panasonic Corporation 2013 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1306018CE
B26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMIX DMC-G6P and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic LUMIX DMC-G6P

Summary of Contents for Panasonic LUMIX DMC-G6P

  • Page 1 Digital Camera/Body/Lens Kit/Double Zoom Lens Kit DMC-G6P Model No. DMC-G6PC DMC-G6EB DMC-G6EC DMC-G6EE DMC-G6EF DMC-G6EG DMC-G6GC DMC-G6GN DMC-G6HEB DMC-G6HEC DMC-G6HEE DMC-G6HEF DMC-G6HEG DMC-G6WEB DMC-G6WEC DMC-G6WEE DMC-G6WEF DMC-G6WEG DMC-G6WGC DMC-G6WGH DMC-G6WGK © Panasonic Corporation 2013 Unauthorized copy- ing and distribution is a violation of law.
  • Page 2 DMC-G6WGN DMC-G6KGK DMC-G6KGN DMC-G6WGT DMC-G6XPC DMC-G6KP DMC-G6XEC DMC-G6KPC DMC-G6XEE DMC-G6KPU DMC-G6XEF DMC-G6KEB DMC-G6XEG DMC-G6KEC DMC-G6XGC DMC-G6KEE DMC-G6XGH DMC-G6KEF DMC-G6XGK DMC-G6KEG DMC-G6XGN DMC-G6KGC DMC-G6XGT DMC-G6KGD Colour [DMC-G6] [DMC-G6X] (K)...Black Type (K)...Black Type [DMC-G6H] (W)..White Type (only EE/EF/GH/GK/GT) (K)...Black Type (S)...Silver Type (only GK/GT) [DMC-G6K] [DMC-G6W] (K)...Black Type...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions----------------------------------------------- 4 1.1. General Guidelines---------------------------------------- 4 1.2. Leakage Current Cold Check--------------------------- 4 1.3. Leakage Current Hot Check (See Figure. 1) ------- 4 1.4. How to Discharge the E.Capacitor on Flash P.C.B. --------------------------------------------------------- 5 2 Warning -------------------------------------------------------------- 6 2.1.

  • Page 4: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check (See Figure. 1) 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 5: How To Discharge The E.capacitor On Flash P.c.b

    1.4. How to Discharge the E.Capacitor on Flash P.C.B. CAUTION: • Be sure to discharge the E.Capacitor on Flash P.C.B. before disassembling. • Be careful of the high voltage circuit on Flash P.C.B. when servicing. [Discharging Procedure] 1. Remove the Battery Con Cover. 2.

  • Page 6: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 7: Caution For Ac Cord (For Eb/Gc/Gh)

    2.3.2.3. How to Replace the Fuse A replacement fuse cover can be purchased from your local Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 8: How To Replace The Lithium Battery

    2.4. How to Replace the Lithium Battery 2.4.1. Replacement Procedure 1. Remove the EXT MIC P.C.B.. (Refer to Disassembly Procedures.) 2. Unsolder the each soldering point of electric lead terminal for Lithium battery (Ref. No. “B4401” at component side of EXT MIC P.C.B.) and remove the Lithium battery together with electric lead terminal.

  • Page 9: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.
  • Page 10 3.3.2. Lens Unit (Interchangeable Lens: H-PS14042) 3.3.2.1. About Lens Main Block Unit (Ref. 203) 1. LENS MAIN BLOCK UNIT (Ref. 203) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “LENS MAIN BLOCK UNIT” (Ref. 203), carefully confirm its performance in advance. 2.
  • Page 11 3.3.3. Lens Unit (Interchangeable Lens: H-FS1442A) 3.3.3.1. About Lens Main Block Unit (Ref. 308) 1. LENS MAIN BLOCK UNIT (Ref. 308) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “LENS MAIN BLOCK UNIT” (Ref. 308), carefully confirm its performance in advance. 2.
  • Page 12 3.3.4. Lens Unit (Interchangeable Lens: H-FS014042) 3.3.4.1. About Lens Main Block Unit (Ref.408) 1. LENS MAIN BLOCK UNIT (Ref. 408) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “LENS MAIN BLOCK UNIT” (Ref. 408), carefully confirm its performance in advance. 2.
  • Page 13 3.3.5. Lens Unit (Interchangeable Lens: H-FS45150) 3.3.5.1. About Lens Main Block Unit (Ref. 509) 1. LENS MAIN BLOCK UNIT (Ref. 509) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “LENS MAIN BLOCK UNIT” (Ref. 509), carefully confirm its performance in advance. 2.
  • Page 14 3.3.6. Lens Unit (Interchangeable Lens: H-FS14140) 3.3.6.1. About Lens Main Block Unit (Ref. 609) 1. LENS MAIN BLOCK UNIT (Ref. 609) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “LENS MAIN BLOCK UNIT” (Ref. 609), carefully confirm its performance in advance. 2.

  • Page 15: Service Notes

    3.4. Service Notes 3.4.1. About Wi-Fi Function The page number in this chapter does not show the page number of this service manual.
  • Page 16 3.4.2. Important Notice of Servicing This Camera unit has the personal information of wireless LAN connection the customer has registered. For the protection of private information, please erase the personal information after the completion of repair by “INITIAL SET- TING”. In addition, please print out the following documents, and pass to the customer with the Camera unit.

  • Page 17: General Description About Lead Free Solder (Pbf)

    3.5. General Description About Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin (Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the normal solder.

  • Page 18: How To Define The Model Suffix (Ntsc Or Pal Model)

    3.6. How to Define the Model Suffix (NTSC or PAL model) There are nine kinds of DMC-G6 (Camera body unit), regardless of the colours. • a) DMC-G6 (Japan domestic model) • b) DMC-G6P/PC • c) DMC-G6EB/EC/EF/EG • d) DMC-G6EE • e) DMC-G6GD •...
  • Page 19 3.6.2. INITIAL SETTINGS: After replacing the MAIN P.C.B., make sure to perform the initial settings after achieving the adjustment by ordering the following procedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, make sure to read the following CAUTION. 2.
  • Page 20 • Step 4. Display the INITIAL SETTING: While pressing [ MENU/SET ] and “[ RIGHT ] of Cursor buttons” simultaneously, turn the Power off. The “INTIAL SETTINGS” menu is displayed. There are two kinds of “INITIAL SETTINGS” menu form as follows: [ CASE 1.
  • Page 21 • Step 5. Choose the model suffix in “INITIAL SETTINGS”: (Refer to “CAUTION”) [Caution: After replacing Main P.C.B.] The model suffix can been chosen, JUST ONE TIME. Once one of the model suffix have been chosen, the model suffix lists will not be displayed, thus, it can not be changed. Therefore, select the area carefully.

  • Page 22: Specifications

    4 Specifications 4.1. Body The following specification is for DMC-G6EB/G6KEB/G6HEB/G6WEB. Some specifications may differ depending on model suffix.

  • Page 27: Lens

    4.2. Lens The following specification is for DMC-G6EB/G6KEB/G6HEB/G6WEB. Some specifications may differ depending on model suffix.
  • Page 29 The following specification is for DMC-G6PC/G6KPC/G6XPC. Some specifications may differ depending on model suffix.

  • Page 30: Location Of Controls And Components

    5 Location of Controls and Components 5.1. Body The following description is for DMC-G6EB/G6KEB/G6HEB/G6WEB. Some descriptions may differ depending on model suffix.

  • Page 32: Lens

    5.2. Lens The following description is for DMC-G6EB/G6KEB/G6HEB/G6WEB. Some descriptions may differ depending on model suffix. The following description is for DMC-G6PC/G6KPC/G6XPC. Some descriptions may differ depending on model suffix.

  • Page 33: Service Mode

    6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly.
  • Page 34 Error Code List The error code consists of 8 bit data and it shows the following information. Important notice about “Error Code List” About “*” indication: The third digit from the left is different as follows. - In case of 0 (example: 2B001000) When the third digit from the left shows “0”, this error occurred under the condition of INITIAL SETTINGS has been com- pleted.

  • Page 35: Troubleshooting Guide

    7 Troubleshooting Guide 7.1. Checking Method of Body and Interchangeable Lens...

  • Page 40: About Tilt Sensor Display

    7.2. About Tilt Sensor Display The unit has the tilt sensor display function using G (3-axis accelerometer) sensor inside the unit. [Principal of Operation] 1. Movement of “Weight” is detected by capacitance. -------- [A] 2. Each acceleration of the X/Y/Z axis is converted into data and they are output. 3.
  • Page 41 [Test of the G-Sensor working] • G-Sensor working can be confirmed by G-Sensor data change on the “Edit Memory”. [Operation] (1)-----When you acquire the data of the G-sensor continually, put a checkmark here. (2)-----Raw data of G- sensor is displayed. (3)-----Roll angle (Horizontal Level) and Pitch angle (Tilt) are displayed.

  • Page 42: Failure Diagnosis Of Nfc

    7.3. Failure Diagnosis of NFC 7.4. Wi-Fi P.C.B. 7.4.1. How to Remove Wi-Fi Password Protection To prevent incorrect operation or use of the Wi-Fi function by a third party and to protect saved personal information, this unit pro- tects the Wi-Fi function with a password. It is unable to service with password locked condition.

  • Page 43: Service Fixture & Tools

    8 Service Fixture & Tools 8.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit. About Name Ring Fixture: • RFKZ0507 for H-FS014042 and H-FS45150 About Adjustment Shaft: • VMS7941 for H-FS1442A...

  • Page 44: Clean Box

    8.2. Clean Box • The repair quality is considered, and it is recommended working in the environment of specified clean level less than class 10,000 (Federal Standard 209D). [NOTE] • Work in the environment of specified clean level less than class 10,000 (Federal Standard 209D) when inside cleaning of a lens. Please refer to the following service manuals.

  • Page 45: Service Position

    8.3. Service Position This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing. Table S1 Extension Cable List Parts No. Connection Form FP9001(MAIN) ←→ TOP UNIT RFKZ0564 23pin / 0.3 FFC FP9002(MAIN) ←→ FLASH FPC - FP8502(FLASH P.C.B.) VFK1950 33pin / 0.3 FFC FP9003(MAIN) ←→...

  • Page 46: Disassembly And Assembly Instructions

    9 Disassembly and Assembly Instructions 9.1. Camera Body Part Disassembly Flow Chart 9.1.1. This is a disassembling chart. When assembling, perform this chart conversely. P.C.B. Location 9.1.2.
  • Page 47 Disassembly Procedure 9.1.3. Item Removal Battery Lock Knob (Fig. D16) 2 Locking tabs Condenser Holder Item Removal Battery Lock Spring Rear Case Unit (Fig. D1) Memory Card Battery Lock Knob Battery LVF Unit (Fig. D17) 2 Screws (T) 2 Screws (A) LVF Unit 2 Screws (B) LVF Module...
  • Page 48 Item Removal LCD IF P.C.B., (Fig. D29) 2 Convexes LCD Unit (Fig. D30) 2 Screws (d) 2 Screws (e) 6 Locking tabs LCD Case Bottom FP7201 (Flex) LCD Hinge Unit FP7203 (Flex) (Fig. D31) 1 Locking tab LCD IF P.C.B. LCD BL Bezel Sheet LCD Unit LCD Earth Plate Unit...
  • Page 49 9.1.3.1. Removal of the Rear Case Unit (Fig. D1) (Fig. D2)
  • Page 50 9.1.3.2. Removal of the Main P.C.B. 9.1.3.3. Removal of the Top Unit and Flash P.C.B. (Fig. D4) (Fig. D3)
  • Page 51 (Fig. D6) (Fig. D5)
  • Page 52 9.1.3.4. Removal of the Front Case Unit (Fig. D8) 9.1.3.5. Removal of the Mount Box Unit (Fig. D7) (Fig. D9)
  • Page 53 9.1.3.7. Removal of the Wi-Fi P.C.B. (Fig. D10) 9.1.3.6. Removal of the NFC Antenna Unit (Fig. D12) 9.1.3.8. Removal of the Battery Frame (Fig. D11) (Fig. D13)
  • Page 54 9.1.3.10. Removal of the Battery Lock Knob (Fig. D14) 9.1.3.9. Removal of the Battery Door Unit (Fig. D16) (Fig. D15)
  • Page 55 9.1.3.11. Removal of the LVF Unit 9.1.3.13. Removal of the LVF Lens Unit (Fig. D17) 9.1.3.12. Removal of the LVF Module (Fig. D19) (Fig. D18)
  • Page 56 9.1.3.14. Removal of the Mic P.C.B. 9.1.3.15. Removal of the Ext Mic P.C.B. (Fig. D21) 9.1.3.16. Removal of the Hot Shoe FPC Unit (Fig. D20) (Fig. D22)
  • Page 57 9.1.3.17. Removal of the Flash Lock Lever 9.1.3.18. Removal of the Hot Shoe Unit and Mic Unit (Fig. D23) (Fig. D24)
  • Page 58 9.1.3.19. Removal of the Flash Unit (Fig. D25) (Fig. D26)
  • Page 59 9.1.3.20. Removal of the Hinge SW FPC Unit (Fig. D28) 9.1.3.21. Removal of the LCD IF P.C.B. and LCD Unit (Fig. D27) (Fig. D29)
  • Page 60 (Fig. D30) (Fig. D31)

  • Page 61: Disassembly And Assembly Procedure For The Lens

    9.1.3.22. Removal of the Rear Operation NOTE: (When Installing) Make sure to confirm the following points when installing: FPC Unit • The Screw is tightened enough. • Installing conditions are fine. (No distortion, no abnormal- space.) • No dust and/or dirt on Lens surfaces. •...

  • Page 62: Measurements And Adjustments

    • Inspect it, not only corresponding part is replaced, but also camera body is shocked and/or dropped. • The Panasonic camera body in accordance with the Micro Four Thirds system (marketed commodity: operates normal) and a standard zoom lens H-FS014045 (marketed commodity: operates normal) is required as a reference machine.
  • Page 63 *2 NOTE: (When exchange the MAIN P.C.B.) • Correspond by either the following when exchange the MAIN P.C.B. unavoidably by destruction and damage etc. of MAIN P.C.B.. 1. When it can turn on power, and the adjustment software can communicate with the camera body: •...

  • Page 64: Maintenance

    11 Maintenance 11.1. Notice in external cleaning 11.1.1. ABOUT THE BODY NOTE: Before cleaning the camera, remove the battery and/or disconnect power plug from the outlet. Also, remove the memory card and lens unit. 11.1.1.1. DUST/DIRT ON THE OUTER CASING PART (S) 1.

  • Page 65: Block Diagram

    12 Block Diagram 12.1. Overall Block Diagram MOUNT BOX UNIT MEMORY CARD MOS IMAGE SENSOR LENS UNIT 4/3” 16M pix (Built in AFE) SPEAKER ECM(L) Q4201,4202 X9001 STEREO MIC AMP (27MHz) MICROPHONE LENS CONTACT SHUTTER X6001 SSWF IC9102 ECM(R) UNIT TERMINAL (24MHz) SYSTEM IC...

  • Page 66: System Control Block Diagram

    12.2. System Control Block Diagram TOP UNIT IC9102 ( TOP OPERATIONS ) (SYSTEM IC) (LED IA OUT) (LED IA OUT) FP9001 LEDOUT1 (Blue) IA LED (LED WiFi OUT) FP9001 PIOC6 PW D4.5V (LED PWR OUT) (LED PWR OUT) FP9001 LEDOUT0 POWER LED (Green) FP9001...

  • Page 67: Video/Audio Process(1) Block Diagram

    12.3. Video/Audio Process(1) Block Diagram IC6003 (NOR FLASH ROM/256M-bit) LCD HINGE LCD IF P.C.B. DATA CTL SIG ADDRESS FP9009 FP97201 FP7203 LCDOUT0-15 BUS40 LCD0-15 BUS40 LCD0-15 FP9009 FP7201 FP7203 IC6001 CL7201 (LCDVD) (VENUS ENGINE) VSYNC FP9009 FP7201 FP7203 T3 T2 T1 CL7202 (LCDHD) HSYNC...

  • Page 68: Video/Audio Process(2) Block Diagram

    12.4. Video/Audio Process(2) Block Diagram FLASH FPC FLASH P.C.B. Wi-Fi P.C.B. IC6001 (VENUS ENGINE) IC8001 (W-LAN MODULE) (G WiFi CLK) (WiFi CLK) (WiFi CLK) (WiFi CLK) FP9002 FP8501 FP8502 FP8001 IC8002 GPIO3 SDIO CLK (WiFi CMD) (WiFi CMD) (WiFi CMD) (WiFi CMD) (CHIP DIELECTRIC FP9002...

  • Page 69: Eye Sensor/Lens/Flash Block Diagram

    12.5. Eye Sensor/Lens/Flash Block Diagram IC6001 (VENUS ENGINE) MOUNT BOX UNIT (LENS CONTACT TERMINAL) FP9012 PW LEN4.2V LEN4R2V (S LSDET) FP9012 AD1 IN1 LSDET (S LSRST) FP9012 GPIO42 LSRST (S LSB2L) FP9012 GPIO19 LSB2L (S LSL2B) FP9012 GPIO17 LSL2B (S LSDIO) FP9012 GPIO20 LSDIO...

  • Page 70: Power Block Diagram

    12.6. Power Block Diagram FLASH P.C.B. CL1101 CC8501 CC9001 CL1001 P8501 F8501 PW D1.1V (UNREG) FP8501 FP9002 BAT+ 27-33 (BAT THERMO) FP8501 FP9002 BAT THERMO 2 BATTERY CATCHER CC8502 TOP UNIT BAT DET(NC) F1002 CL1201 (TOP OPERATION) FP8501 FP9002 BAT- POWER SW 8-13 20-25...

  • Page 71: Wiring Connection Diagram

    13 Wiring Connection Diagram 13.1. Interconnection Diagram MIC UNIT RL8521 RL8522 Wi-Fi FPC FP4201 FP4401 FLASH MIC GND BACK BAT+ RL8511 ECM RIN UNIT D GND ECM LIN EXT MIC DET RL8512 MIC GND EXT MIC GND EXT MIC GND FP4202 EXT MIC CINA STEREO...

This manual is also suitable for:

Lumix dmc-g6pcLumix dmc-g6ebLumix dmc-g6ecLumix dmc-g6eeLumix dmc-g6efLumix dmc-g6eg ... Show all

Table of Contents
