- Page 1 Chico Breeze Installation Manual Installation Manual...
- Page 3 Before installing your new Fanco exhaust fan, it is important that you read and follow these instructions prior to installation, even if you feel you are quite familiar with this type of product. Please keep this document handy for future reference as it contains servicing and maintenance requirements.
-
Page 4: Delivery Set
The S Series exhaust range described in this user’s manual is designed for exhaust ventilation of small to medium-sized premises heated during winter. DELIVERY SET 1. Fan: 1 piece 2. Screws and dowels: 4 pieces 3. User's manual: 1 piece 4. - Page 5 MOUNTING The fan is designed for ceiling or wall mounting and is connected to a ventilation shaft or an air duct of respective diagram below. STEP 1 - Cut off power supply and make preparations in the room to install a fan. STEP 2 - Remove the front panel from the fan.
- Page 6 STEP 3 - Position the fan in your preferred installation location and mark the position of the holes on the fan where the screws will then be placed. STEP 4 – Drill the holes for the in compliance with the mounting seats on the fan casing and install the fan with screws.
-
Page 7: Wiring Diagram
STEP 6 – Connect the wire to the terminal box by following the wiring diagram. Install the retaining clamp back and secure it with the included screws. WIRING DIAGRAM TERMINAL DESIGNATION KEYS AT WIRING DIAGRAMS: L - phase (only for 220-240 V power mains) N - 0 (only for 220-240 V power mains) S - external switch STEP 7 –... -
Page 8: Maintenance
MAINTENANCE The product surfaces must be regularly cleaned from dirt and dust. Cut off power supply prior to any maintenance operations. Use a soft cloth or compressed air to remove external dust. To clean internal surfaces, remove the front cover. Thoroughly clean the internal surfaces every 6 months using a soft dry cloth or a brush. - Page 12 reeze ation Manual...
