- Page 1 Hybrid Installation Manual Version 2.0...
- Page 2 Before installing your new Fanco Hybrid Exhaust Fan, it is important that you read and follow these instructions prior to installation; even if you feel you are quite familiar with this type of product. Please keep this document handy for future reference as it contains servicing and maintenance requirements.
-
Page 3: Delivery Set
DELIVERY SET: • Fan Motor: 1 piece (note that the decorative or light grille is packaged separately) • Hole size cut-out template: 1 piece (attached to the box) • User's manual: 1 piece • Packing box: 1 piece SHORT DESCRPTION: •... - Page 4 MOUNTING: The fan is designed for ceiling mounting and installation in gyprock/plasterboard and is securely fastened by using removable rotary clamping brackets on the fan casing. The fan installation location must comply with local building codes for this type of product. Check the fan for mechanical damages prior to mounting. The minimum install depth should be 220mm.
- Page 5 3. Push the ducting through the hole in the ceiling and attach it onto the duct connector (which has a non- return valve). 4. Loosen the self-tapping screws on the rocking levers, increasing the gap between the casing and the lever. DO NOT remove the rocking levers.
- Page 6 MODELS WITH LIGHT a. Locate the light wire holes on the motor. b. Carefully cut the light wire hole plastic, making sure the hole is big enough to fit the light wire through. CAUTION: DO NOT damage the motor structure. c.
- Page 7 5. Connect the duct connector (and ducting) to the motor. At this point, you can plug the fan into the available power socket in the roofspace. FOR LIGHT MODELS: Plug the light cable into the available power socket. CAUTION: A standard socket and electrical wiring to an ON/OFF wall switch must be pre-installed. It is necessary to arrange for a licenced electrician to ensure this is completed before installation of the product.
- Page 8 7. Secure the fan in the roof space, by turning the levers. Inside Room View Inside Roof View 8. Clamp the self-tapping screws on the rocking levers, by using a screwdriver to tightnen. FOR LIGHT MODELS a. Connect and lock the two light cables together.
- Page 9 NOTE: You can change the colour of the light to either Warm 3000K (WW), Natural 4000k (NW) or Cool 6500K (CW) using the colour selection switch located on the back of the light panel 9. Install the fascia, by one of two methods below: ROUND a.
- Page 10 SQUARE a. Locate the four (4) hooks on the corner of the b. Start by clipping in two (2) of the hooks of the fascia. fascia to the outer circle of the motor face. Then clip in the remaining two (2) hooks by applying gentle pressure to each corner.
-
Page 11: Maintenance
MAINTENANCE: • The product surfaces must be regularly cleaned from dirt and dust. • Cut off power supply prior to any maintenance operations. • Use a soft cloth or compressed air to remove external dust. • To clean the internal surfaces, remove the decorative cover. To remove the round fascia a.
