PowerMOVE
PowerMOVE
touch&move 3.1
touch&move 3.1
This user manual applies to the following models
Spreader bars
4-point electric spreader bar
2-point spreader bar
Warning! Always read the entire user manual before using the product.
The hoist should only be used by qualifi ed caregivers with adequate knowledge of the
operations to be carried out. If you have any questions about the use or the application,
please contact the supplier.
Mini
Mini
Optional
Weighing unit
PowerMOVE
user manual
user manual
PowerMOVE
VERSION
passive hoist
Mini
hoist
Mini
09-2023
Advertisement
Table of Contents
Related Manuals for JOYinCARE PowerMOVE Mini
Summary of Contents for JOYinCARE PowerMOVE Mini
- Page 1 passive hoist PowerMOVE Mini PowerMOVE PowerMOVE Mini Mini touch&move 3.1 touch&move 3.1 user manual user manual PowerMOVE hoist Mini This user manual applies to the following models Spreader bars Optional 4-point electric spreader bar Weighing unit 2-point spreader bar Warning! Always read the entire user manual before using the product. The hoist should only be used by qualifi...
- Page 2 © JOYinCARE 2023 JOYinCARE products are patented. Information about our patents can be provided upon request. We are alert to new developments, therefore technical specifications are subject to change without notice. The latest version of this user manual can always be downloaded from our website. The content of this user manual may not be copied either in whole or in part without our consent.
-
Page 3: Table Of Contents
Contents Introduction ............................. 3 General product description ......................7 Product description PowerMOVE Mini touch&move ..............9 Use of the PowerMOVE Mini touch&move .................. 13 Inspection & maintenance ......................20 Troubleshooting ..........................22 Contact details JOYinCARE ......................22 Annex A: Technical specifications ......................23 Annex B: Identification labels ........................ -
Page 4: Introduction
In addition to this user manual, which also includes daily cleaning and safety checks, a comprehensive service manual is available for the PowerMOVE Mini hoist. For the safe usage of a patient sling, it is also very important to read the user manual of the sling. - Page 5 A hoist should always be used in combination with a sling. The sling can be attached to the spreader bar of the hoist with either loops or safety clips. This can be a sling from JOYinCARE or another compatible brand. The patient should be closely monitored during the transfer and should never be left unattended in the hoist.
- Page 6 The hoist is not suitable for use in the shower, large jets of water can cause serious malfunctions. The safe use of slings from JOYinCARE in combination with the hoist has been extensively tested and documented. These slings can be recognised by the JOYinCARE logo on the label of the sling.
- Page 7 1.7 Liability JOYinCARE assumes no liability for consequential damages in case of malfunctions or breakdowns and is not responsible for unsafe situations, accidents and damages resulting from: o Not following the instructions included in this user manual, the user manual of the sling and the service manual;...
-
Page 8: General Product Description
2. General product description 2.1 General The PowerMOVE Mini is a passive hoist designed for lifting passive patients with reduced mobility from a lying or seated position, e.g. a (wheel)chair or bed. The hoist has a high lifting reach, enabling a patient to be lifted from the floor as well as from a higher sitting or lying element. - Page 9 First make sure that the patient is safely placed back in the chair or bed. Take the hoist out of use immediately and ask the technical service or supplier to check the hoist for any defects. User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023...
-
Page 10: Product Description Powermove Mini Touch&Move
3. Product description PowerMOVE Mini touch&move 3.1 General The PowerMOVE Mini touch&move consists of the following parts: ⑨ ① ② ③ ⑤ ⑩ ④ ⑥ ⑪ ⑧ ⑦ ⑬ ⑫ ⑭ Mast Separate hand control Lifting arm Emergency lowering function... - Page 11 JOYinCARE. 3.3 Control panel The PowerMOVE Mini touch&move is fitted with both a control panel and a separate hand control. The image below shows the control panel mounted on the push handle on the left and the hand control on the right.
- Page 12 If the PowerMOVE Mini touch&move is not used for a longer period of time, it is recommended to switch it off by pressing and holding the On/off button. After 15 minutes, the device indication light starts flashing green, meaning the hoist will go into sleep mode.
- Page 13 The integrated battery of the PowerMOVE Mini touch&move 3.1 can be charged with the included battery charger. It can be recognised by the JOYinCARE sticker and is fitted with an angled plug. Drive the hoist to the desired location with a socket. Plug the charger into the charging point on the right side of the control panel and connect it to the socket.
-
Page 14: Use Of The Powermove Mini Touch&Move
4-point spreader bar can only be used in combination with a sling with safety clips. When the PowerMOVE Mini is fitted with a 2-point spreader bar with hooks, it is only suitable for attaching a sling with loops. Before use, check all clips or loops for abnormalities or defects. Do not use the sling in case of any defects or doubts. - Page 15 Place the loop over the hook of the spreader bar. Cross the leg loops by pulling one strap through the other (do not cross the leg loops of a JOYinCARE Longseat in-situ sling). Do not cross the shoulder loops and use the same length for both shoulder loops and the same length for both leg loops.
- Page 16 Always consider carefully whether it is safe to leave the patient alone in a certain position and for what length of time. Make sure the patient can access and operate an alarm in case of emergency. User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023...
- Page 17 5) When using a sling with loops: cross the loops of the leg straps through the first loop. Do not cross the leg loops of a JOYinCARE Long seat in-situ sling. 6) Place the stiffeners in the head support and attach the sling to the spreader bar.
- Page 18 4.5 Lifting from the floor The PowerMOVE Mini can also be used to lift someone from the floor or to lay someone on the floor. Applying the sling can be done in the same way as in bed, only place a pillow or possibly more pillows under the patient's head.
- Page 19 4.7 Lifting with a 2-point spreader bar If the PowerMOVE Mini is fitted with a 2-point spreader bar, follow the specific instructions in the user manual of the sling. With this spreader bar, the PowerMOVE Mini works exactly as described before, only the buttons for operating the electric spreader bar do not work.
- Page 20 Remove the battery and insert a new one correctly. Slide the battery holder back and close the cover. You can also contact the technical service or maintenance partner for this. User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023...
-
Page 21: Inspection & Maintenance
If any defect, damage or wear is found, the hoist in question should always be taken out of use immediately until further inspection and repair has taken place. User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023... - Page 22 All parts of the hoist should be recycled in accordance with the rules of the country where the hoist is used. At the end of its lifetime, the hoist can be returned to the distributor for recycling. JOYinCARE or the distributor will ensure that these parts are processed in an environmentally friendly manner.
-
Page 23: Troubleshooting
3. The hoist does not charge Check that the charging connector and plug are properly connected to both the hoist and the socket. Check that the accompanying charger is used, which can be recognised by the JOYinCARE sticker. 4. A beeping signal sounds Check whether the emergency button is activated. -
Page 24: Annex A: Technical Specifications
Annex A: Technical specifications Figure 1. PowerMOVE Mini touch&move 3.1 User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023... - Page 25 Maximum lifting weight / weighing weight 200 kg Resolution 0.1 kg Accuracy 0.1 % Weighing unit dimensions approx. 80x207x78 mm Power supply Battery 9 V Number of weighings with full battery approx. 3000 User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023...
-
Page 26: Annex B: Identification Labels
Year-week 2021-35 GTIN (01) GTIN (01) BATCH/LOT (10) BATCH/LOT (10) SERIAL (21) SERIAL (21) JOYinCARE JOYinCARE Industrieweg 47, 8071 CS Nunspeet Industrieweg 47, 8071 CS Nunspeet T. 0341-768080 info@joyincare.com T. 0341-768080 info@joyincare.com User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023... - Page 27 Medical device class I XXX 000 0000 Read user manual before use. Year-week 2023-16 Regulation (EU) 2017/745 NEN-EN-ISO 10535 GTIN (01) JOYinCARE BATCH/LOT (10) Industrieweg 47, 8071 CS Nunspeet SERIAL (21) T. 0341-768080 info@joyincare.com User manual PowerMOVE Mini touch&move 3.1_ENG Version 09-2023...
- Page 28 JOYinCARE...
