- Page 1 QDS1-N Motor Soft Starter User Manual...
-
Page 3: Table Of Contents
CONTENTS Overview ..............................1 Safety ................................1 Safety Mark .............................. 1 1.Function and Feature ..........................2 2.Product Type and Inspection ......................... 3 3.Environment and Installation ........................ 4 3.1 Environment ..........................4 3.2 Installation ..........................4 4.Operating principle ..........................5 5.Wiring and terminal ..........................6 5.1 Wiring diagram ...........................6 5.2 External Terminals ........................ -
Page 4: Overview
Overview This manual is applicable to QDS1 series products. This manual is intended to guide qualified personnel in the installation and operation of this product. In the case of a registered trademark and business ownership, final interpretation right to this manual is belonged to Jiaxing Dannahe Electronic Science&Technology Co.,Ltd. -
Page 5: Function And Feature
1.Function and Feature QDS1 series LED AC motor soft starter is new type starting equipment with advanced international level. This equipment designed and manufactured by the technique of power electronics microprocessor and modern control theory. This equipment can limit the start current efficiently when the asynchronous motor starts. -
Page 6: Product Type And Inspection
2.Product Type and Inspection Each QDS1 series soft starter is tested. Only the starter that passes the function and running test can leave the factory. After receiving the equipment, the user should inspect it according the steps described below. Please notify the supplier immediately if you find any problem. Check the nameplate：Check the item(s) nameplate catalog number against the purchase order. -
Page 7: Environment And Installation
3.Environment and Installation 3.1 Environment The environment is important to the equipment life. So please install the soft starter on the site described below Operation Condition for the standard products Power Supply: Urban power, self-provided substation, diesel generating sets Three-phase AC: 380V (-10%, +15%), 50Hz. -
Page 8: Operating Principle
Cabinet installation If the product is installed in the cabinet, make sure there are good ventilation in the cabinet. The products can be installed vertically or horizontally. Horizontal layout shows in Figure 3-2. Vertical layout shows in Figure 3-3. User can adopt any of them. Note: If the vertical layout is adopted (especial in fan air cooling mode), clapboard should be installed between them to avoid that the upper starter is affected by heat generated by the lower starter. -
Page 9: Wiring And Terminal
5.Wiring and terminal 5.1 Wiring diagram Figure 5-1 Note: There are two wiring ways to control starting and stopping the starter externally. They are three- line and two-line wiring. (See ①and ② in the figure above).Start signal is given by connecting terminal RUN and COM. -
Page 10: Main Circuit Wiring
485+ RS485 + RS485 communication （Modbus communication protocol） 485- RS485 - 4-20Ma output Im：motor output current（A Ie: Load input resistance≤ 400Ω motor rate current（A） I : 4- Im=Ie(I-4)/8 20mA output current（mA 4～20mA output reference In Fault: Fault output K14-K12 close ; K11-K12 open Contacts capacity terminals②... -
Page 11: Control Mode
6.Control mode This product has three start modes: Voltage Ramp and Current Limit and jogging. These start modes is independent. Only one of them can be chosen. Text below introduce that the different of them and which mode should be selected. 6.1 Voltage Ramp The waveform of the voltage shows in Figure 6-1. -
Page 12: Jogging
6.3 Jogging At this start mode, the output voltage reaches the initial voltage U1 quickly, and remains unchanged. Changing the U1, the output voltage and torque of the motor will change corresponding. (See figure 6-3). It is convenient to judge the director of the motor. Figure 6-3 6.4 Heavy load The waveform of the voltage shows in Figure 6-1. -
Page 13: Keyboard
7.Keyboard 7.1 Keyboard Description There is a Keyboard on the front of the soft starter. User can operate it to display data, save data, check data, display fault, reset fault, start or stop the motor etc. The construction of the keyboard shows in figure 7-1. -
Page 14: Parameter Table
8.Parameter table Name Range and mean default Remarks Para group 1:base 2:advance 3:communicate 4:Rate current Start mode ▲ ★ ■ ● 1：Ramp▲ 2：limit★ 3:jog■ 4:heavy load● Initial vol ▲ ● 5%～75%Ue Jog voltage ■ ● 5% ～ 75%Ue Ramp time ▲... -
Page 15: Special Parameter
9.Special parameter Rate Current The Rate Current indicate that the output current of the soft starter at the rate power. This parameter changes with the output power of the soft starter. For detail see chapter 9. User can query this parameter by the method shows below. -
Page 16: Displayed Current Calibration
10.Displayed Current Calibration The displayed current of each Soft starter is calibrated before leave factory. If user finds the current value showing on the keyboard is not equal to the actual current value, this parameter can be calibrated again. WAY1:Set the starting mode to Jogging, and the motor must be connected to its load, the parameter of Jogging Voltage is set below 40%, keep press RUN key (enter the Jogging state), press PRG and up or down key at the same time to modify this value until it is equal to the actual current. -
Page 17: Parameter Details
11.Parameter details Starting There are 4 starting mode. User can set this parameter by keyboard referring to Mode chapter 8-1 and chapter 9. Initial This parameter is valid at the Voltage Ramp mode. Voltage This parameter indicates that the initial output voltage of the product at the instant of starting and also indicates the initial voltage of the motor (see figure 6-1).The more this parameter is, the more the starting torque is. - Page 18 This parameter is set for the protect function aimed at that the difference of 3 phases Current current is bigger at running. The default value is 30%.The smaller this parameter is, unbalance the more the sensitivity is. This parameter should not be too small, in order to avoid factor the protection is too sensitive to influence the normal operation of the equipment.
-
Page 19: Working State
12.Working State Ready When the soft starter is power on, self-inspection is performed. The self-inspection includes: test the parameters that the user changed (fault protection of parameters setting), check if the phase of voltage is not right (protection of missing supply phase) and check if the system temperature is too high (protection of overheating) etc. -
Page 20: Fault
13.Fault There are 11 protections. When the fault is detected, soft starter stop immediately, the fault information displays on the keyboard. User can find the solution by check the explanations to this fault information. After the fault is solved, pres the STOP key(keep 3 seconds) or connect terminal RET and COM to reset and return ready state。For detail see table 13-1 ... - Page 21 Overload Overload protection function is in used during the process of starting and running There are 8 protection levels. The default is 4(same as 15 in IEC60974-4-2 standard). User can set this parameter according to de load situation, the smaller this parameter is, and the shorter the starting time of protection is, vice verse.
-
Page 22: Test Running
14. Test running 14.1 Inspection before running For safe running, user should inspection the items show as following items before power on. Is the power of the soft starter match to that of the motor? Does the insulation of the motor meet the requirement? Is the wiring of power and motor line right? Do all the nut screw tightly Measure the input power (R\S\T) using multimeter, Check whether there is short circuit. -
Page 23: Appendix 1: Specification And Type
Appendix 1: Specification and Type MOTOR POWER RATED CURRENT MODEL （KW) QDS1-008-3 QDS1-015-3 QDS1-022-3 QDS1-030-3 QDS1-037-3 QDS1-045-3 QDS1-055-3 QDS1-075-3 QDS1-090-3 QDS1-110-3 QDS1-132-3 QDS1-160-3 QDS1-187-3 QDS1-200-3 QDS1-250-3 QDS1-280-3 QDS1-320-3 QDS1-400-3 QDS1-450-3 QDS1-500-3 1000 Ordering Users should inform the agent the information such as product type, specification, and load when ordering, for ensuring what you ordered is proper. -
Page 24: Appendix 2: Structure Size
Appendix 2: Structure Size Appearance dimension Installation dimension(mm) Sheet copper dimension(mm) (mm) Type 7.5～30KW 37～75KW φ6.5 62.5 φ8.5 90KW 110～187 KW 119.5 98.5 φ8 74.6 φ10.5 200～280 KW 137.5 103.5 φ8 φ14 320～400 KW 450～500 KW φ11 φ9 Figure 1 Figure 2... -
Page 25: Appendix 3：Keyboard Shape And Dimension
Appendix 3：Keyboard shape and Dimension... -
Page 26: Appendix 4：Qds1 Series Typical Wiring Diagram
Appendix 4：QDS1 series typical wiring diagram... -
Page 27: Appendix 5：Communicate Protocol
Appendix 5：Communicate protocol 1.Modbus communicate QDS1 series soft starter provides communication interface. The Modbus communication protocol is adopted for master-slave communication. User can PC/PLC/touch screen as upper computer to realize centralized control to meet specific application requirement. Communication protocol of QDS1 series soft starter is an asynchronous serial master-slave Modbus communication protocol. - Page 28 Respond format Receive correct response format: (2 data and 4 bytes) Rest time 3.5 Characters Slave address Slave Number Command code Byte number The first data HIGH The first data LOW The second data HIGH The second data LOW CRC LOW CRC HIGH Rest time 3.5 Characters...
- Page 29 Respond format Receive correct response format Rest time 3.5 Characters Slave address Slave Number Command code Byte number Start address HIGH Start address LOW data HIGH data LOW CRC LOW CRC HIGH Rest time 3.5 Characters For example: 01 03 02 00 01 79 84 start mode is 1.
- Page 30 3.Respond format Definition of address corresponding to the parameter (see the specification for details and scope) Address Parameter name 1000H Rated current 1001H Reserve 1002H Working current 1003H Fault(see manual) 1004H Start mode (1.ramp 2.limit.3 jog 4.heavy load) 1005H Initial voltage of ramp（5~75%） 1006H Ramp time （1~120S）...
-
Page 31: Warranty
Warranty We solemnly promises that user can enjoy the after-sale guarantee service show as following since user purchase our product. 1. All the products enjoy 24 months free warranty from the date users buy it. 2. User enjoys the paid service for life from the date you buy the products. 3. - Page 32 Jiaxing Dannahe Electronic Science&Technology Co.,Ltd Address: NO.992,gaoxin west road,Tongxiang city,Zhejiang Province,CHINA. Email：admin@dnh-drive.com Web：www.dnh-drive.com...
