  • Page 1 One360 ECE R129/03, 40–150 cm...
  • Page 2: How To Use

    - 18 - Thank you for choosing our One360 infant car seat. If you need help with this product, please contact our customer service. HOW TO USE • This product is suitable for children with a height of 40 to 150 cm.
  • Page 3: Installation Direction

    - 19 - NOTE (100-150 cm): This is an optimised i-Size children’s booster seat. It is approved under Regulation no. 129 for use primarily in “i-Size vehicle seats” as specifi ed by vehicle manufacturers in the vehicle owner’s man- ual. If in doubt, contact either the manufacturer of the extended child restraint system or the dealer. The optimised i-Size booster seat can also be used on all seats in the “universal”...
  • Page 4 - 20 - WARNING • Please read through these instructions carefully before use in order to guarantee the safety of your child. Retain the manual. Non-compliance with the instructions in this manual may result in serious injuries to your child. •...
  • Page 5: Front View

    - 21 - SEAT PARTS Front view Headrest Head cushion Diagonal belt guide Seat bucket for size class 100- 150 cm Comfort insert Seatbelt buckle Shoulder pad Seatbelt buckle pads Shoulder belt Lap belt guide Central for size class belt adjustment 100-150 cm Position lever Rotation lever...
  • Page 6 - 22 - USING THE CHILD CAR SEAT Setting the child car seat tilt angle • Operate the position lever on the lower front of the seat bucket with one hand. • Hold the seat pan with the other hand and ad- just the angle.
  • Page 7 - 23 - Adjusting the belt • To loosen the belt, press the belt adjustment button in the seat area with one hand. Hold the belt buckle with the other hand and carefully loosen the attached straps. • Pull the front adjustment strap to tighten the belts.
  • Page 8: Adjusting The Head Support

    - 24 - Adjusting the head support • Release the belt and pull the lever to adjust the headrest on the back of the child car seat. Move the headrest until it engages at the cor- rect height. • Make sure the shoulder straps are positioned just above your child’s shoulders when they come out of the child car seat.
  • Page 9 - 25 - Top tether for size range 40-105 cm • Remove the top tether from the storage bag. • To release the top tether, press the grey button with one hand and pull the side of the belt anchor to the required length with the other hand.
  • Page 10 - 26 - Stowing the 5-point seat belt for size class 100-150 cm • Open the seat cover at the back of the child car seat and unthread the shoulder pads from their hooks (fi g. A). Open the shoulder pads by their press studs so that you can completely remove the shoulder pads from the child seat (Fig.
  • Page 11: Maintenance

    Regularly check the condition of the product for possible damage. In the event of damage, the child car seat must no longer be used and must be stored out of the reach of children. In case of any issues, please contact Osann customer service on +49 (0)7731 970077.
  • Page 12 - 28 - INSTALLATION OF THE CHILD CAR SEAT 1) Size class 40-105 cm, max. 18 kg, rear-facing...
  • Page 13 - 29 - 1 . Adjust the child car seat to the maximum reclining position and turn it so that it points to the R1 - 40-75 cm seating position in rear-facing orientation. If your child's height exceeds 75 cm, please change to the seat position R2 - 76-105 cm.
  • Page 14 - 30 - INSTALLATION OF THE CHILD CAR SEAT 2) Height class 76-105 cm, min. 15 months, max. 18 kg, forward-facing IMPORTANT: DO NOT USE THE CHILD CAR SEAT IN THE DIRECTION OF TRAVEL UNTIL THE CHILD IS AT LEAST 15 MONTHS OLD.
  • Page 15 - 31 - 1 . Press the two lateral Isofi x connector buttons in order to extend the length of the Isofi x con- nectors. 2 . Guide the Isofi x connectors onto the Isofi x anchor points on the seat of the vehicle and ensure that they lock into position.
  • Page 16 - 32 - INSTALLATION OF THE CHILD CAR SEAT 3) Size class 100-150 cm, forward-facing...
  • Page 17 - 33 - 1 . The 5-point seat belt and top-tether harness of the child car seat must be stowed as previ- ously described. These are not needed in this size class. 2 . Press the two lateral Isofi x connector buttons in order to extend the length of the Isofi x con- nectors.
  • Page 18 Osann GmbH Gewerbestr. 22 D-78244 Gottmadingen Tel.: +49 (0)7731 970077 Fax: +49 (0)7731 970055 E-Mail: info@osann.de...
