SINGLE CHANNEL
WIRELESS AIR SPRING CONTROLS
Kit w/ 12 VDC 325 Series Air Compressor
20470
Kit w/ 12 VDC 90 Series Air Compressor
20472
Giving you the ability to adjust your air spring pressure from
your phone with the touch of a button. It's the perfect means
to control your vehicle's air suspension system from inside
or outside your vehicle!
L6597_REV2_04.26.2024
Advertisement
Table of Contents
Related Manuals for Pacbrake 20470
Summary of Contents for Pacbrake 20470
- Page 1 SINGLE CHANNEL WIRELESS AIR SPRING CONTROLS Kit w/ 12 VDC 325 Series Air Compressor 20470 Kit w/ 12 VDC 90 Series Air Compressor 20472 Giving you the ability to adjust your air spring pressure from your phone with the touch of a button. It’s the perfect means to control your vehicle’s air suspension system from inside...
-
Page 2: Kit Description
Thank you & congratulations on the purchase of a Single Channel Wireless Air Spring Control Kit. PLEASE NOTE: This manual is used across multiple kit variations. 20470 is used as reference through most the manual. Installation step images may vary depending on your kit but the procedure remains the same across all part numbers. - Page 3 FROM ROAD SPRAY AND DEBRIS M8685 UNAUTHORIZED DISCLOSURE, USE OR MANUFACTURE IN WHOLE OR IN PART IS PROHIBITED ELECTRONIC DESIGN AND OTHER DISCLOSURES PROPERTY OF PACBRAKE CO. SURREY, B.C., CANADA SECURE RELAY WITH P60100 C241 SELF TAPPING SCREW OR TIE...
- Page 4 THREAD FILTER INTO COMPRESSOR HAND TIGHT UNAUTHORIZED DISCLOSURE, USE OR MANUFACTURE IN WHOLE OR IN PART IS PROHIBITED ELECTRONIC DESIGN AND OTHER DISCLOSURES PROPERTY OF PACBRAKE CO. SURREY, B.C., CANADA SECURE RELAY WITH P60100 SELF TAPPING SCREW OR TIE KIT CONTENTS STRAPS 0 mm [240"]...
-
Page 5: Before Starting The Installation
Single Channel Wireless Air Spring Controls L6597 This manual is used across multiple kits - please pay close attention to important warnings listed below for a safe installation. BEFORE STARTING THE INSTALLATION: Read through this manual and ensure you can complete the installation once started. Ensure the kit you received contains all the items shown in the Kit Contents on Page 2. -
Page 6: Connect Wiring Harness
Single Channel Wireless Air Spring Controls L6597 MARK & DRILL MOUNTING HOLES Use the air compressor and controller as templates to mark the locations of the drilled holes. Place each component in the desired location/orientation and mark the centers of each hole: 4 holes on the compressor, 2 holes on the controller. - Page 7 Single Channel Wireless Air Spring Controls L6597 SECURE WIRING HARNESS RELAY Included in the wiring harness assembly is a built-in sealed relay which must be secured to prevent damage over time. When all harness connectors are attached to the compressor assembly and controller, secure the relay in the nearby area that leaves the harness unstrained.
- Page 8 • Insert the provided air compressor fuse (30 Amp for 20470 kits / 20 Amp for 20472 kits) into the 30 Amp fuse holder. PLEASE NOTE: If the negative battery terminal is not accessible, an external chassis ground may be used provided it has a...
- Page 9 Do NOT overtighten as the filter housing will break For HP325 Series compressors with remote mounted filters (Figure 8B): 20470: Remote Mounted Filter • Mount the provided air filter in a clean, dry location sheltered from road spray and debris •...
-
Page 10: Presets Tab
• Open the Wireless Air Spring Controls app. The Bluetooth toggle will illuminate to show that your device has successfully connected to the controller on the Wireless Controls kit. PLEASE NOTE: If multiple Pacbrake app controlled devices are nearby, a window will be displayed to select a controller for connection. - Page 11 Single Channel Wireless Air Spring Controls L6597 13 BLUETOOTH TOGGLE The Bluetooth Toggle illuminates when it has successfully connected to the wireless controller. Tap the Bluetooth toggle to manually connect or disconnect from the controller. PLEASE NOTE: The app automatically connects to the controller on start-up. 14 PRESSURE INDICATOR The Pressure Indicator shows the pressure of each air spring with an accuracy of ±...
-
Page 12: Warranty
Single Channel Wireless Air Spring Controls L6597 Thank you again, and congratulations on the installation of your Air Suspension kit. AFTER COMPLETING THE INSTALLATION DISCLAIMER ▪ The air spring must have clearance between itself and the surrounding components to prevent any contact when spring is Driving while distracted can result in loss of vehicle control that may lead to an accident, severe personal injury, or death. - Page 13 Single Channel Wireless Air Spring Controls L6597 LEGAL • Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc., registered in the U.S. and other countries. •...
