- Page 1 Endeavor Series Transformer User’s Manual Endeavor Series minutemanups.com | 800.238.7272...
-
Page 3: Table Of Contents
Table of Contents Introduction ………………………………………………………………… 1 Installation ………………………………………………………………….. 3 Connecting to a UPS…………………………………………………….. 7 Obtaining Service ………………………………………………………… 8 Specifications ………………………………………………………………. 9 Warranty ……………………………………………………………………… 10 Declaration of Conformity ...………………………………………… 12 minutemanups.com | 800.238.7272... -
Page 4: Introduction
Introduction Thank you for purchasing a MINUTEMAN power protection product. It has been designed and manufactured to provide many years of trouble-free service. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS! CONSIGNES DE SECURITE IMPORTANTES SAUVEGARDEZ CES CONSIGNES! Please read this manual and comply with all warnings and instructions before installing your Endeavor Series Transformer module as it provides important information that should be followed during installation and maintenance, allowing you to correctly set up your installation for the maximum safety and performance. - Page 5 temperature range for this device is 32° ~ 104°F (0° ~ 40°C). To ensure the proper ventilation and cooling of the UPS, do not block any of the ventilation cutouts in the case. Adequate space must be provided around all sides of the transformer to allow for proper air flow. Do not mount the device with its front or rear panel facing down at any angle.
-
Page 6: Installation
Life Support Policy: As a general policy, Para Systems does not recommend the use of any of our products in life support applications where failure or malfunction of the product can be reasonably expected to cause failure of the life support device or to significantly affect its safety or effectiveness. - Page 7 Receiving Inspection: Once the product arrives, it should be visually inspected for any damage that may have occurred in shipping. Immediately notify the carrier and place of purchase if any damage is found. Warranty claims for damage caused by the carrier are the responsibility of the purchaser. The product packing materials were carefully designed to meet ISTA 1A and minimize any potential shipping damage.
- Page 8 Tower Installation: Use caution as the transformer is very heavy. Two or more individuals are recommended for installation. 1. Locate the UPS to its final installation location. 2. Orient the transformer vertically with the nameplate in line with the UPS. 3.
- Page 9 Transformer Rear Panels: 3kVA 5kVA 30A AC Circuit Breakers Output Hardwire Terminal 208/240VAC Voltage Selector 20A AC Circuit Breakers NEMA 5-15/20R Receptacles Input Power Cord NEMA L5-30R Receptacles (EBMS) Ambient Temperature Port minutemanups.com | 800.238.7272...
-
Page 10: Connecting To A Ups
Terminal Block Wiring Diagram 1. Remove the terminal block cover box from the rear panel of the Transformer module (requires a Phillips screwdriver). Refer to the figure below for the output connections. 2. Before connecting to the output terminals read all of the Cautions and Warning, then observe the following: a) Ensure that the connected UPS is turned off or the transformer is disconnected from the UPS before any connections are made. -
Page 11: Obtaining Service
5) Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside. 6) Return the unit by insured, prepaid carrier to: Para Systems Inc. MINUTEMAN UPS 2425 Technical Drive Miamisburg, OH 45342 ATTN: RMA #... -
Page 12: Specifications
Specifications: Transformer Model ED-3KTF ED-5KTF General Features Topology Isolation Step-down Transformer Single (1ф 2W + G) Number of Phases VA Rating 3,000VA 5,000VA Load Capacity 2,565 Watts 4,275 Watts (2) L5-30R / (4) L5-15/20R Output Receptacles (8) 5-15/20R (1) 3-wire Terminal Block Installation Format(s) Rack or Tower Input... -
Page 13: Warranty
Warranty: Para Systems, Inc. (Para Systems) warrants this equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship for a period of three years from the date of purchase. For equipment sites within the United States and Canada, this warranty covers depot repair or replacement of defective equipment at the discretion of Para Systems. - Page 14 1455 LeMay Drive Carrollton, TX 75007 800.238.7272 www.minutemanups.com © 2023 PARA SYSTEMS, INC. Minuteman Power Technologies, Endeavor and SentryHD are owned by Para Systems, Inc. All other trademarks are property of their irrespective owners. Rev. B 20240530 minutemanups.com | 800.238.7272...
-
Page 15: Declaration Of Conformity
IEC61000-4-3: level3, IEC61000-4-4: level4, IEC61000-4-5: level4, IEC61000-4-6: level3, IEC61000-4-8: level3, IEC 62040-2: 2005, IEEE C62.41 Category A1 Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS) Manufacturer’s Address: 1455 LeMay Drive, Carrollton, Texas 75007 (USA) Type of Equipment: Uninterruptible Power Supplies (UPS)
