Omron H3CR-F Datasheet

Omron H3CR-F Datasheet

Solid-state timer
Hide thumbs Also See for H3CR-F:

Advertisement

Quick Links

Download this manual See also: Manual
Solid-state Timer
A Wide Variety of DIN 48 x 48-mm H3CR-F Twin Timers, H3CR-G Star-delta Timers,
and H3CR-H Power OFF-delay Timers
Conforms to VDE0435/0110 and approved by UL and CSA.
Conforms to EMC standards.
Six-language instruction manual provided.
Broad Line-up of H3CR Series
H3CR-A
Multifunctional Timer
H3CR-A
11-pin model
H3CR-AS
H3CR-A8
8-pin model
H3CR-A8S
H3CR-A8E
8-pin with
H3CR-A8EL
instantaneous
contact output
model
Note: 1. H3CR-AS, H3CR-A8S: Transistor output models
2. Refer to the H3CR-A Datasheet (L84) for details.
H3CR
H3CR-F
Twin Timer
H3CR-F
H3CR-FN
11-pin model
H3CR-F-300
H3CR-FN-300
H3CR-F8
H3CR-F8N
8-pin model
H3CR-F8-300
H3CR-F8N-300
H3CR-G
Star-delta Timer
H3CR-G8L
8-pin model
H3CR-G8EL
H3CR-F/G/H
H3CR-H
Power OFF-delay Timer
11-pin model
H3CR-HRL
H3CR-H8L
8-pin model
H3CR-H8RL
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the H3CR-F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron H3CR-F

Summary of Contents for Omron H3CR-F

  • Page 1 Solid-state Timer H3CR-F/G/H A Wide Variety of DIN 48 x 48-mm H3CR-F Twin Timers, H3CR-G Star-delta Timers, and H3CR-H Power OFF-delay Timers Conforms to VDE0435/0110 and approved by UL and CSA. Conforms to EMC standards. Six-language instruction manual provided. Broad Line-up of H3CR Series...

  • Page 2: Ordering Information

    OFF- or ON-time settings are possible. Fourteen time ranges from 0.05 s to 30 h or from 1.2 s to 300 h depending on the model to be used. Models with a flicker ON start or flicker OFF start are available.

  • Page 3: Specifications

    1.2 to 12 3 to 30 30 to 300 3 to 30 Note: Instantaneous output is available at any time range. To obtain instantaneous output, set to below 0. 1.2 s to 300 h Models Time unit x10 s (10 s)
  • Page 4 Control outputs Contact output: 5 A at 250 VAC, resistive load (cos = 1) Note: A power supply with a ripple of 20% max. (single-phase power supply with full-wave rectification) can be used with each DC Model. Characteristics Accuracy of operating time 0.3% FS max.
  • Page 5 Indicator circuit Clock Output circuit Power supply Time range/unit One-chip microcomputer AC (DC) input circuit selectors I/O Functions Inputs Outputs Control output Outputs are turned ON/OFF according to the time set by the ON- and OFF-time setting knob.
  • Page 6 Flicker OFF start 0.1 s min. Power indicator Not lit indicator Not lit Output Output ON set time : OFF set time Flicker ON start 0.1 s min. Power indicator Not lit indicator Not lit Output Output ON set time...
  • Page 7 H3CR-F H3CR-F Dimensions Note: All units are in millimeters unless otherwise indicated. H3CR-F 17.4 66.6 H3CR-FN 52.3 H3CR-F-300 H3CR-FN-300 44.8 x 44.8 37 dia 14 dia. R1.3 17.4 66.6 H3CR-F8 H3CR-F8N 52.3 H3CR-F8-300 H3CR-F8N-300 44.8 x 44.8 37 dia 14 dia.
  • Page 8 200 to 240 VAC Time-limit contact and instantaneous contact 100 to 120 VAC H3CR-G8EL 200 to 240 VAC Note: Specify both the model number and supply voltage when ordering. Example: H3CR-G8L 100 to 120 VAC Supply voltage Model Number Legend: H3CR - 1.
  • Page 9 4 kV contact discharge (level 2) 8 kV air discharge (level 3) Immunity RF-interference: ENV50140: 10 V/m (80 MHz to 1 GHz) (level 3) Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3) Immunity Burst: IEC801-4: 2 kV power-line (level 3)
  • Page 10 2,000 VAC, 50/60 Hz for 1 min (between control output terminals and operating circuit) 1,000 VAC, 50/60 Hz for 1 min (between contacts not located next to each other) Impulse withstand voltage 3 kV (between power terminals) 4.5 kV (between current-carrying terminal and exposed non-current-carrying metal parts)
  • Page 11 5,000 1,000 Reference: A maximum current of 0.15 A can be switched at 125 VDC (cosf = 1) 30 VDC L/R = 7 ms and a maximum current of 0.1 A can be switched if L/R is 7 ms. In both cases, a life of 100,000 operations can be expected.
  • Page 12 I/O Functions Inputs Outputs Control output If the time reaches the value set with the time setting knob, the star operation output will be turned OFF and there will be delta operation output after the set star-delta transfer time has elapsed.
  • Page 13 Mount the Panel Cover on the Timer, set the time setting knob to 10 s (the lower limit of the setting range), and place Time Setting Ring C onto the time setting knob so that the stopper of Time Setting Ring C is on the right edge of the reset lock position of the Panel cover. Next, set the time setting knob to 20 s (the upper limit of the setting range), place Time Setting Ring B onto the time setting knob so that the stopper of Time Setting Ring B is on the left edge of the reset lock position of the Panel Cover.
  • Page 14 Limiting the setting Time Setting Ring B or C (Y92S-28), When setting a given time for the Timer, use of the Y92S-27 or range and Panel Cover (Y92P-48GL, -48GB, Y92S-28 Time Setting Ring facilitates the time setting operation and or -48GA) minimizes possible setting errors by operators.
  • Page 15 ( ~ ) ( ~ ) ( ~ ) ( ~ ) Note: Leave terminals 1, 3, and 4 open. Note: Leave terminal 4 open. Do not use Do not use them as relay terminals. them as relay terminals.
  • Page 16 200 to 240 VAC 24 VAC/DC 48 VDC 100 to 125 VDC Note: Specify both the supply voltage and time unit code (S or M) in addition to the model number when ordering. Example: H3CR-H8L 24 VAC/DC M Time unit code Supply voltage...
  • Page 17 0.5 to 6 1 to 12 Min. power ON time 0.1 sec min. 2 sec min. Note: If the above minimum power ON time is not secured, the H3CR may not operate. Be sure to secure the above minimum power ON time.
  • Page 18 Control outputs Contact output: 5 A at 250 VAC, resistive load (cos = 1) Note: A power supply with a ripple of 20% max. (single-phase power supply with full-wave rectification) can be used with each DC Model. Characteristics Accuracy of operating time 0.3% FS max.
  • Page 19 5,000 1,000 Reference: A maximum current of 0.15 A can be switched at 125 VDC (cosf = 1) 30 VDC L/R = 7 ms and a maximum current of 0.1 A can be switched if L/R is 7 ms. In both cases, a life of 100,000 operations can be expected.
  • Page 20 I/O Functions Inputs Reset Turns off the control output and resets the elapsed time. Outputs Control output Operates instantaneously when the power is turned on and time-limit resets when the set time is up after the power is turned off.
  • Page 21 Reset input Output (1 – 3) Output (1 – 4) Output (11 – 9) Output (11 – 8) Output indicator Not lit Note: t: Set time Rt: Minimum power ON time (S-series: 0.1 s min.; M-series: 2 s min.)
  • Page 22 H3CR-H H3CR-H Dimensions Note: All units are in millimeters unless otherwise indicated. H3CR-H8L 78.0 H3CR-H8RL 63.7 39 dia 44.8 x 44.8 78.0 H3CR-HRL 63.7 39 dia 44.8 x 44.8...
  • Page 23 With Reset Input (H3CR-H8RL) Reset input (–) (–) Power supply Power supply Note: Leave terminal 3 open. Do not use them as relay terminals. 11-pin Model With Reset Input (H3CR-HRL) Reset input (–)(~) (+)(~) Note: Leave terminal 6 open. Do not use them as relay terminals.
  • Page 24 Selection of Time Unit and Time Range H3CR-F Twin Timers A time range (0 to 1.2, 0 to 3, 0 to 12, or 0 to 30) is selected for ON- and OFF-time using the time range selector at the lower left corner...
  • Page 25 H3CR-F/G/H H3CR-H Power OFF-delay Timers A time range (0 to 0.6, 0 to 1.2, 0 to 6, and 0 to 12) is selected with the time range selector at the lower left corner of the front panel. No time unit selector is available. When ordering the H3CR-H, specify S (for the second unit) or M (for the minute unit) for your H3CR-H.
  • Page 26 100.7* 98.4 102.8 eg. H3CR-F 100.5 H3CR-F8 H3CR-HRL H3CR-H8L P2CF-08 P2CF-11 P2CF-08 P2CF-11 These dimensions vary with the kind of DIN track (reference value). Flush Mounting 91.4 85.4 8-pin, long 11-pin, long 8-pin, short 11-pin, body body body short body...
  • Page 27 Track Mounting/ Front Connecting Socket P2CF-08 Terminal Arrangement/ Eight, Internal Connections M3.5 x 7.5 sems (Top View) Surface Mounting Holes Two, 4.5 dia. or two, M4 70 max. 35.4 Two, 4.5 dia. 40 0.2 holes 50 max. 20.3 max. P2CF-11 Eleven, Two, 4.5 dia.
  • Page 28 Y92A-48B Y92A-48B The protective cover protects the front panel, particularly the time setting section, against dust, dirt, and water. It also prevents the set value from being altered due to accidental contact with the time set- ting knob. Note: 1. The Y92A-48B Protective Cover is made of a hard plas- tic and therefore it must be removed to change the timer set value.
  • Page 29 H3CR Operation (H3CR-H) Input An interval of 3 s minimum is required to turn on the H3CR after the Power supply terminal H3CR is turned off. If the H3CR is turned on and off repeatedly with an interval of shorter than 3 s, the internal parts of the H3CR may deteriorate and the H3CR may malfunction.
  • Page 30 Note: 1. The above figures are all approximations and should be used for reference only. 2. The inrush current is given mainly for DC models for the required power supply design specifications. For the H3CR-H, the inrush current is also given for 100/110/120-VAC and 200/220/240-VAC models because these models have higher inrush currents than...
  • Page 31 If a relay or transistor is connected to two or more Timers, the input terminals of those Timers must be wired properly so that they will not be different in phase or the terminals will be short-circuited to one another (refer to the figures below).
  • Page 32 H3CR-F/G/H H3CR-F/G/H ALL DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527. Cat. No. L86-E1-2B In the interest of product improvement, specifications are subject to change without notice.
