Single-phase Power Controller
G3PW
High-precision Control with Easy Setup
• Precise heater burnout detection.
• Set value and present value monitoring with indicators.
• Phase control or optimum cycle control.
• RS-485 communications to set manipulated variables and
monitor load current.
• Total run time monitoring.
• Output modes for phase control: proportional to phase angle
(same as G3PX), proportional to voltage, proportional to
square voltage, and constant-current control.
• Application with various loads: constant load resistance,
variable load resistance.
• Certified for CE and pending for UL.
Model Number Structure
Model Number Legend
G3PW-A2@@E@-@-@@@
1 2 3 4 5 6 7
1. Basic model
G3PW: Power Controller
2. Degree of protection
A: Panel-mounting/Closed wallmounting
3. Voltage class
2: 200 VAC

Ordering Information

List of Models
Number of phases Control terminal block
Screwless clamp termi-
nal block
Single-phase
Terminal block with
small slotted screws
Accessories (Order Separately)
Name Resistive value
External Variable
Resistor
8
4. Maximum rated current
20: 20 A
45: 45 A
60: 60 A
5. Power supply type
E: Single-phase power supply
6. Current control
U: Standard Model (no constant-current
control)
C: Constant-current Model
Type
20 A
Standard 45 A
60 A
20 A
Constant
45 A
current
60 A
20 A
Standard 45 A
60 A
20 A
Constant
45 A
current
60 A
Display
2 kΩ 202
7. Control terminal block
8. RS-485 communications
Heater burn-
Capacity
out detection
No
Yes
100 to
240 VAC
No
Yes
Model
G32X-V2K
C: Screwless clamp terminal block
S: Terminal block with small slotted screws
Blank: Communications not supported.
FLK: Communications supported.
Communica-
Model number
tions
G3PW-A220EU-C
No G3PW-A245EU-C
G3PW-A260EU-C
G3PW-A220EC-C-FLK
Yes G3PW-A245EC-C-FLK
G3PW-A260EC-C-FLK
G3PW-A220EU-S
No G3PW-A245EU-S
G3PW-A260EU-S
G3PW-A220EC-S-FLK
Yes G3PW-A245EC-S-FLK
G3PW-A260EC-S-FLK
