User Manual for Range hood
Model Name: CXW-320-W8
This product implements national standards:
GB 4706.1 2005
GB 4706.28 2008
GB 29539-2013
GB/T 17713-2011
Content
1. Safety Precautions Safety precautions.................................................. 2
2 . Important Information...........................................................................4
3. Product Information............................................................................... 4
4. Installation Instructions..........................................................................6
5.Instructions for operation..................................................................... 11
6. Maintenance..........................................................................................12
7 .Troubleshooting.................................................................................... 13
8. After-sales Service.................................................................................14
1
Advertisement
Table of Contents
Related Manuals for Macro CXW-320-W8
Summary of Contents for Macro CXW-320-W8
-
Page 1: Table Of Contents
User Manual for Range hood Model Name: CXW-320-W8 This product implements national standards: GB 4706.1 2005 GB 4706.28 2008 GB 29539-2013 GB/T 17713-2011 Content 1. Safety Precautions Safety precautions..........2 2 . Important Information................4 3. Product Information................4 4. Installation Instructions................6 5.Instructions for operation.............. -
Page 2: Safety Precautions Safety Precautions
1. Safety Precautions. In order to avoid harm and property damage to users and other personnel, please carefully read the following important safety matters, please strictly abide by, and on the basis of full understanding of the content of the correct use. Before use, please read this manual carefully and use in strict accordance with the instructions. - Page 3 run, the after-sales service personnel shall explain the use method to the user while there is no abnormal phenomenon. If you need to clean the inside of the range hood, please contact Macro after-sales personnel for professional cleaning.
-
Page 4: Important Information
2 . Important Information If the range hood is not in use for a long time, remove the power plug from the socket. When installing a new range hood, if the accessories do not conform to the instructions, contact your local dealer or service center immediately. - Page 5 Main Technical Data Name of Product Range hood Product Model Number CXW-320-W8 Rated voltage 220V~ Rated frequency 50Hz Rated input power of main motor 320W Maximum lighting power Rated input power of the device 330W Air volume 15m3/min Wind pressure...
-
Page 6: Installation Instructions
4. Installation Instructions Installation precautions ★ Special note: Macro products must be installed and maintained by our authorized installation and maintenance service providers, otherwise we will not be responsible for the accidents caused by installation and maintenance. If your kitchen is under renovation, do not expose the range hood, because construction ... - Page 7 Name of main parts Preparing for Installation The surroundings The range hood should avoid being installed in too many doors and Windows, forming too much air convection, and affecting the effect of lampblack removal. Preparing Tools Before installing a range hood, prepare the following tools: 1.
- Page 8 Mounting size drawing Installation dimensions are shown in Figure 3. Opening size of Cabinet or ceiling for chimney pipe The size of the cabinet or ceiling smoke pipe is shown in Figure 4.
- Page 9 Installation Procedure Mounting plate As shown in Figure 5, accurately determine the location of the mounting holes for the hanging plate at the corresponding positions on the wall, drill the mounting holes in the hole positions with a drill bit, firmly bury the plastic expansion tube B, and then tighten the hanging plate with the equipped wood screw B.
- Page 10 Installing a chimney pipe Insert the pipe into the check valve as shown in Figure 7, then lock it with the self-tapping screw and wrap it with the aluminum foil. Install oil cup Push the oil cup in along the oil cup hanging ear. Installation Confirmation ...
-
Page 11: Instructions For Operation
flue system in real time, and controls the fan speed to run according to the corresponding setting speed. [Speed ] button Low, high, stir-fry speed button. Under unit working condition, long press the speed button 2seconds to turn ... -
Page 12: Maintenance
keep bright, and the system will start on [AI constant suction] to run. Intelligent linkage cancellation code: in the off state, long press the [lighting] button for 3s. {Standby Status} In Standby Status, only the power button lights up; The motor and lamp of the smoke ... -
Page 13: Troubleshooting
Range hood surface 1. It is recommended to clean the surface of the range hood immediately after using it. 2. Please wipe the outer surface of the lampblack machine with a soft wet towel or a towel stained with neutral detergent, and then wipe the body with a soft dry towel to keep it clean. -
Page 14: After-Sales Service
Check whether the range hood is firmly suspended; Hang the range hood securely; There is too much oil on the Please have it professionally cleaned; impeller; Key lime screw Check whether external screws are loose Violent body vibration; Increase in noise Check whether the internal screws are loose;...
